2

Installation

2.1

Space Requirements

Maximum installation plate thickness: 8 mm
Space requirements in millimeters when installing the operator panel:
50 mm
Note:
The dimensions on the drawing are not proportional.
Caution:
The openings on the enclosure are for air convection. Do not cover these openings.
Beijer Electronics, MAEN083D
100 mm
50 mm
100 mm
410 mm
Installation
100 mm
6
