Additional Installation Tips
When experiencing communication problems in for example noisy environments
or when operating close to temperature limits, the following recommendations
are to be noticed.
7.1
Grounding the Operator Panel
Door
Operator panel
1
Ferrite core
6
The operator panel's mounting clamps do not provide a secure grounding
connection between the panel and the device cabinet, see 1 in drawing above.
1. Connect a 2.5 mm
and the panel's chassis, see 2 in drawing above.
2. Connect a 6 mm
panel's chassis and the closest grounding point on the door, see 3 in drawing
above.
3. Connect a strong but short grounding braid between the door and the device
cabinet, see 4 in drawing above.
4. Twist the cables onto the 24 V DC feed, see 5 in drawing above. Minimum
cross-section of the cable is 2.5 mm
2 turns around the ferrite core provide 4 times the suppression of 1 turn.
3 turns around the ferrite core provide 9 times the suppression of 1 turn.
A ferrite core suppresses disturbances to the 24 V feed, see 6 in drawing above.
Beijer Electronics, MAEN083D
Mounting plate in the cabinet
3
2
Power supply
24 V DC
5
4
2
wire between the operator panel's quick-connect plinth
2
2
or 4 mm
wire or grounding braid between the operator
2
.
Additional Installation Tips
5350
