5. USING THE POOL CLEANER

The Pool Cleaner is very easy to use. Just follow the simple steps to get started, and your Pool Cleaner
is ready to go.

5.1. Setup

Before using the Pool Cleaner for the first time perform the following steps:
Unwind the cable and stretch it out
completely so that it has no kinks.
Position the power supply so that it
is approximately in the middle of the
long side of the pool at a distance of
3m/10ft.
2
Attach the floating cable to the power supply
by inserting it with the notch on the connector (1)
lined up with the groove in the socket on the
power supply and turning clockwise (2).
4
3m/10ft
Some models arrive with plastic coverings on the brushes.
Remove them before use.
1
Plug in the power supply and leave it in the
OFF position.
