Cleaning The Impeller; Offseason Storage - Maytronics Swash CLX User Instructions

6.4. Cleaning the impeller

If you notice debris trapped in the impeller open the impeller and remove the debris.
A
A

7. OFFSEASON STORAGE

If the Pool Cleaner will not be in use for an extended period, perform the following storage steps:
• Disconnect the Pool Cleaner from mains
• Make sure that no water is left in the Pool Cleaner
• Thoroughly clean the filter bag or cartridges and insert in place
• Roll up the cable so that it has no kinks and place on the Caddy
• Store the Pool Cleaner upright on the Caddy or simply upside down in a protected area
out of direct sun / rain / snow at a temperature of between 5°-45°C / 41°-113°F
10
B
B
Replace the screws.
Unplug the power supply.
CAUTION
Using a screwdriver, remove
the two screws on the impeller
cover and remove it.
Clear any debris that may
be in the impeller.
Robotic Pool Swash CLX / TCX | User Instructions
