Summary of Contents for Skywalk SCOTCH.HY
- Page 1 GmbH & Co. KG Bahnhofstraße 110 83224 GRASSAU Fon: +49 (0) 8641 - 69 48 40 www.skywalk.info GERMANY Fax: +49 (0) 8641 - 69 48 11 info@skywalk.info...
- Page 2 Manual/Service...
-
Page 3: Table Of Contents
cOntent Introduction page 35 Description page 36 line system page 37 technical data page 39 acceleration System page 40 Harness page 42 Winch tow page 42 riser Main System page 42 Pre Flight check and Service page 43 Flight decent assitance page 48 Materials page 55 Service page 56 2-Year-check / certification page 58 a few closing words page 59 line Plans page 60 risers page 61 test Protocols page 62... -
Page 4: Introduction
Congratulations for you choosing to buy the new SCOTCH.HY and placing your trust in skywalk. We are sure you will enjoy every minute of your flying time. In order to fully understand how to begin flying your new wing, and increase the enjoyment, we recommend that you read the instruction book in full. -
Page 5: Description
Trimmer can be used to counter balance or offset the torque of the motor and also increase the trim speed of the wing in flight. The SCOTCH.HY is also certified to 130 kg/150 kg dependent on the size of total weight under the DULV certification. -
Page 6: Line System
The SCOTCH.HY uses a 5 riser system. Both of the inner A-Main lines risers lead to the forward A Gurt, the outer A Lines lead to the back A Gurt, the B Lines to the B Gurt, the C lines and Stabilator line lead to the C Gurt and the D lines to the D Gurt. - Page 7 (Paragliding Wing and Motorsystem) is in proper flight maintenance and condition and is serviced maintained. The skywalk SCOTCH.HY is only permitted to be flown where permission is granted from the legal authorities governing each country. Your skywalk SCOTCH.HY has already under gone many careful Quality Control checks.
-
Page 8: Technical Data
Speed Trimmer closed Speed Trimmer open Speed Max Trimmer closed 90-110kg DHV 1-2 GH 105-130kg DHV 1-2 GH jet flap Technology DULV homologation DULV DULV Weight range DULV [kg] 90-130 105-150 caUtIOn tHe WInG tYPe laBel IS lOcateD On tHe InSIDe OF tHe StaBIlOS. tHe DHv certIFIcatIOn laBel IS lOcateD In tHe WInG POcKet OF tHe MIDDle PrOFIle rIB. tHe DUlv certIFIcatIOn laBel IS lOcateD DIrectlY Over tHe DHv laBel. Date OF USerS 1St FlIGHt SHOUlD Be PrInteD In tHe laBel. tHe DHv cerItIFIcatIOn laBel MUSt Be vISaBle anD lOcateD On tHe WInG FOr USe In GerManY anD aUStrIa. In cOUntrIeS WHere nO certIFIcatIOn laBel IS reqUIreD, tHe SKYWalK certIFIcate anD laBel MUSt Be vISaBle, tO cOnFIrM tHat tHe WInG cOnFOrMS tO tHe DHv certIFIcatIOn StanDarDS. -
Page 9: Acceleration System
If the Speed System is activated then the A,B, and C-riser systems are shortened: In that way, we allow for flight in the most accelerated speed range. The SCOTCH.HY has a Trimmer and Speed System. Using the ScOtcH.HY in non motorized flight. Free Flight mode. From starts from a mountain, the trimmer can be connected into the main carabine lock. - Page 10 The Pilot activates the speed system using his foot and extending it, thus the A-B-C Riser is shortened lowering the angle of attack. Motorised Flight The SCOTCH.HY is certified for Motorised flight to the upper speed range of the Trimmer as registered under DULV. Speedbar is not allowed to use for Motorised flight. assembly The Motor Riser which is attached to the Motor system, has roller attachments for the speed system.
-
Page 11: Harness
The SCOTCH.HY is comprised of 5 main Riser Extentions. Both the A Main Line Extensions lead to the front A-riser, the outer A Lines lead to the back A-riser, the B Lines to the B-... -
Page 12: Pre Flight Check And Service
Motor Hangpoints. That way the optimal point of reaching the steering and brake system and lines is maintained. Also the SCOTCH.HY has an additional Trimmer System which increases the overal speed of the wing plus corrects for the torque motion in flight. - Page 13 Start your SCOTCH.HY wing with your Motor first on your local flight park and in low wind or optimal weather conditions.
- Page 14 Using a nice homogeneous surge to start the skywalk SCOTCH.HY, the wings leading edge should fill itself quickly and reliably. By normal wind conditions, making sure the wind is coming optimally from the front, your SCOTCH.HY should climb upward and over you in a continual patch.
- Page 15 Flying in curves (Motor and near mountains) The SCOTCH.HY has a direct handling response when flying in curves. The wing has a high level of safety reserves, however this wing should not be flown by complete beginners. The SCOTCH.HY has a high level of precision handling, and it great fun when using a motor.
- Page 16 The skywalk SCOTCH.HY is simple to land. When making your final approach against the wind, let the wing glide out in combination with light braking. When the wing has reached a level of 1 meter over ground, increase your braking as this will decrease the angle of attack of the wing and will slow the wing.
-
Page 17: Flight Decent Assitance
The steep spiral manuever is best performed when the SCOTCH.HY enters a sharp axilar curve and starts to fly in a quicker steeper curve. This sharp axilar curve and sinking speed is controlled using a measured dose of increased or decrease of the brakes on the curve inner side. - Page 18 necessary to always allow for sufficient safe altitude. In order to avoid a strong pendulum movement during the ending phase of the steep spiral, you should slowly release the curve inside brake, while holding tension on the outer brake. If the wing starts to react and dive into a stronger asymettrisch spiral caused by some bad factors, (for instance by having the harness cross straps pulled to tight), you must actively stop the spiral by placing your body weight on the curve outside side, and substancially increase the brake pressure on the outside wing side.
- Page 19 Manuever is used when an area of danger exists and you want to change your direction horizontally and fly out of the danger area quickly. To perform this „Big Ear“ manuever pull down both outside A-risers. Now you can easily lose altitude without any danger, by decreasing the wing surface and causing the wing to fly only from the mid section of the wing.
- Page 20 When applying brake pressure on the good side, you may experience some roll down of the wing tip but that should not have any real relevance on safety. The SCOTCH.HY should perform extremely well when reopening and not have any negative tendency in direction control.
- Page 21 The Pilot can try and correct this flying condition by lightly pulling forward on the A Gurt at the height of the line locks, or through apply pressure on his speed bar. The skywalk SCOTCH.HY normally should correct itself automatically to get out of this backstall condition.
- Page 22 Through a symettric holding of the brakes, you will hinder or minimalize the tendency of the wing to shoot forward. In the event that the Pilot does not apply the brakes, the skywalk SCOTCH.HY will shoot forward marginally, where a possible front stall collapse of the wing could happen.
- Page 23 inner wingspan. After a longer held negative curve, it may be that the wing will shoot forward considerably on one side, after release. This may lead to a one sided wing collapse. A cross over stabilizing harness strap will increase the tendency of spin in all wings.
-
Page 24: Materials
MaterIalS The skywalk SCOTCH.HY is made of the highest quality of materials. Skywalk has selected the best possible combinations of materials to use, in consideration of material longevity, load, stress, and performance. The highest life expectancy of your wing is a goal of skywalk as we only want satisfied customers. -
Page 25: Service
The line system of the skywalk SCOTCH.HY is made of a Technora or Dyneema Core with a polyester outer covering . Excessive stress, over weight, or strain on the materials is to be avoided, as this could... - Page 26 Every form of visual damage to the lines, even when the damage is only to the outer sheaf, requires that you replace that line. Replacing a line requires that you contact a skywalk authorized service center to make sure you the proper exchange.
-
Page 27: 2-Year-Check / Certification
Therefore an air certification is not garanteed. changes or alterations to your Paragliding wing The skywalk SCOTCH.HY is garanteed to be in the required manufacturing tolerances when leaving the factory. This tolerance range is very exact and should never be changed. The correct balance of performance, handling, and safety is garanteed. -
Page 28: A Few Closing Words
The skywalk SCOTCH.HY is at the pinnacle of the development standards in Hybrid Wing technology. This Wing will offer you years of satisfaction and joy, if you handle your wing proper- ly. Take into account the demands of flying and respect the dangers involved, that is the basic requirement for successful and problem free flying. -
Page 29: Line Plans
The displayed line plan of the skywalk SCOTCH.HY is only for demonstration purposes of the line configuration. Plans for other sizes can be aquired via flight schools, importers or directly from skywalk. Riser... -
Page 30: Risers
rISer... -
Page 31: Test Protocols
teSt PrOtOcOl test Protocol Date: Customer, Name: Adress: Phone: Glider: Size: Serial number: Gütesiegelnr. Date of last check: Date of first flight: Year of construction: accomplished checking: Results: [ +/– ] Description of failure Suggested repairs Identification: – visual check of canopy: – Upper surface: –... - Page 32 examinations of the lines: Firmness of main lines: – visual check of trimming: checkflight necessary? – Gütesiegel plaque? – – Identification plate? condition: Very good condition Good condition Well used Heavily used, but within gütesiegel standards, frequent checks required No longer airworthy, outside of the limit values. repairs made? Signature of tester: Date:...
- Page 33 teSt PrOtOcOl test Protocol Date: Customer, Name: Adress: Phone: Glider: Size: Serial number: Gütesiegelnr. Date of last check: Date of first flight: Year of construction: accomplished checking: Results: [ +/– ] Description of failure Suggested repairs – Identification: visual check of canopy: – Upper surface: –...
- Page 34 examinations of the lines: Firmness of main lines: – visual check of trimming: – checkflight necessary? Gütesiegel plaque? – Identification plate? – condition: Very good condition Good condition Well used Heavily used, but within gütesiegel standards, frequent checks required No longer airworthy, outside of the limit values. repairs made? Signature of tester: Date:...
