ADVENTURERDELUXE 1
ONE BURNER PORTABLE BBQ
Model No. BQ1077
Powerful 10MJ/h stainless steel burner for
true BBQ performance
Rotary ignition for easy lighting
Generous cooking area of 1600cm
Satin enamel cast iron cooking surface
2
Important: Retain these instructions for future use
Gasmate® is a registered trademark of
Sitro Group Australia Pty Ltd www.gasmate.com.au
Aber Living, N.Z. www.gasmate.co.nz
Integrated temperature gauge
Includes hose and regulator
Gas certified to Australian and
New Zealand Standards
1
5112 05/19
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Gasmate ADVENTURER DELUXE 1
Summary of Contents for Gasmate ADVENTURER DELUXE 1
- Page 1 Gas certified to Australian and Generous cooking area of 1600cm New Zealand Standards Satin enamel cast iron cooking surface Important: Retain these instructions for future use 5112 05/19 Gasmate® is a registered trademark of Sitro Group Australia Pty Ltd www.gasmate.com.au Aber Living, N.Z. www.gasmate.co.nz...
-
Page 2: Read Me First
READ ME FIRST GAS LEAK TESTING It is important that you leak test the BBQ before first use and every time the gas cylinder is refilled and reconnected to the BBQ. To Complete Leak Test • Make sure all the control knobs are OFF. •... -
Page 3: General Information
GENERAL INFORMATION Hose & Regulator Safety The regulator and hose assembly supplied with IMPORTANT the barbecue are suitable for ULPG. Read these instructions carefully prior A gas regulator adjusted to have an outlet to use. Familiarise yourself with the pressure of 2.75kPa is supplied for connection appliance before connecting it to it’s gas to the ULPG cylinder. -
Page 4: For Your Safety
GENERAL INFORMATION FOR YOUR SAFETY • Avoid twisting or kinking the flexible hose. Failure to comply with these instructions • Do not store or use petrol or other could result in a fire or explosion which flammable liquids in the vicinity of this or could cause serious bodily injury, death or any other appliance. - Page 5 Location of your Barbecue IF THERE IS A LEAK DO NOT use your barbecue in garages, porches, sheds, breezeways, or other enclosed areas. • Turn the cylinder off. Your barbecue is to be used OUTDOORS. The • Ventilate the area to disperse gas. barbecue is not intended to be installed in or on •...
-
Page 6: Parts List
PARTS LIST (FF+II) Part Description Valve Cover Hood Ignition Electrode Thermometer Gas Hose and Regulator Hood Handle Grease Cup Buckle Grease Cup Support Insulation Pad Body Side Handle Hinge Pin Top Hinge Control Knob Body Hinge Fascia Panel Cooking Plates Valve Burner... -
Page 7: Hardware List
HARDWARE LIST AA: 4 PC BB: 4 PCS CC: 4 PCS M8 × 45 Bolt M8 Nut Flat washer DD: 4 PCS EE: 6 PCS FF: 2 PCS M6 × 25 Bolt M6 Nut Lid pin GG: 6 PCS HH: 6 PCS II: 2 PCS M5 ×... - Page 8 ASSEMBLY INSTRUCTIONS Remove any transit protection material. Estimated assembly time: 20 minutes. STEP 1 Attach the hood hinges (18) to the hood (1) with two M5 x 8mm screws (GG) and nuts (HH) as shown. STEP 2 Attach the body hinges (19) to the body (16) with four M5 x 8mm screws (GG) and nuts (HH) as shown.
- Page 9 STEP 3 Attach the side handles (6) to the body (16) ensuring the 4 insulation pads (5) are inserted into the handles before securing with four M6 x 25mm screws (DD) and nuts (EE). Attach the legs (7) to the handles using four M8 x 45mm screws (AA) and nuts (BB) as shown.
- Page 10 STEP 5 Slide the fat cup (14) into position from the back. STEP 6 Attach the hood handle (3) to the hood (1) using two M6 nuts (EE) and washers (CC) as shown.
- Page 11 STEP 7 Align the hood to the body. Place the 2 hinge pins (17) through the hinges and secure with the ‘R’ clips. STEP 8 Align the ‘D’ shape and push on the control knob (8).
-
Page 12: Lighting Procedure
GENERAL INFORMATION CONNECTING & DISCONNECTING LIGHTING PROCEDURE TO GAS SOURCE Burner Operation & Ignition System Check Familiarise yourself with the general information 1. With cylinder valve in ‘OFF’ position check the and safety guidelines located at the front of this piezo igniter by pushing in and rotating the manual. -
Page 13: Operation
OPERATION BURNER OPERATION & IGNITION SYSTEM CHECK Problem Possible Reason Solution Control knob is closed Turn knob to high when lighting Piezo igniter is faulty Use a long barbecue match inserted Burner will not ignite through the hole on under side of barbecue Burner has gone out Check that the gas bottle is not empty... -
Page 14: Care And Maintenance
CARE & MAINTENANCE As with all appliances, proper care and Cleaning the Cooking Surface maintenance will keep them in top operating After cooking, turn burner control to ‘OFF’ and let condition and prolong their life. Your new gas barbecue cool before attempting to clean the grill barbecue is no exception. -
Page 15: Safe Appliance Locations
SAFE APPLIANCE LOCATIONS This appliance shall only be used in an above ground open-air situation with natural ventilation, without stagnant areas, where gas leakage and products of combustion are rapidly dispersed by wind and natural convection. Any enclosure in which the appliance is used shall comply with the following: An enclosure with walls on all sides, but at least one permanent opening at ground level and no overhead cover. - Page 16 Limited Warranty BARBECUE RANGE Aber Living warrants the purchaser of this product against defects in workmanship and material, for a period of up to 12 months from the date of purchase. The warranty is non-transferable and becomes void if used for commercial or rental purposes. Warranty and purchase receipt of this product are to be retained as proof of purchase and must be presented if making a claim under the terms of the Aber Living Warranty.
