  • Page 1 50 0 40 0 30 0 OPERATION AND MAINTENANCE INSTRUCTION atomizzatori e impolveratori...
  • Page 2 Our first goal, is to get our Customers happy for having met us! The “ Spare parts catalogue” of this sprayer/sprayhead is available in the ‘“restricted area” on website www.cima.it. In order to accede, use: User name: sprayer Password: 844719KE...
  • Page 3 MAINTENANCE INSTRUCTIONS © CIMA S.P.A. - 1996-2007 Private property. Any reproduction, even if partial, is forbidden if not preventively authorized in writing by the Cima S.p.A. company. CIMA S.p.A. - 27040 Montù Beccaria - Loc. Molino Quaroni - (PV) - ITALIA Tel.
  • Page 5 Blitz 45 - 50 - 55 LISTING OF VALID PAGES This publication consists of 80 pages, subdivided as follows: N° OF PAGE REVISION BASE from I to VI October 2007 from 1 to 74 October 2007 ADDITIONAL RECORDS AND VARIANTS...
  • Page 6 Blitz 45 - 50 - 55 GENERAL INDEX FOREWORD ..........................1 PUBLICATION IDENTIFICATION ....................1 ATTACHED PUBLICATIONS ....................1 PURPOSE OF PUBLICATION ....................1 REFERENCE TO REGULATIONS ..................... 1 USING THE MANUAL ......................1 UPDATES ..........................2 GLOSSARY ..........................3 TERMINOLOGY ........................
  • Page 7 Blitz 45 - 50 - 55 COUPLING MODALITIES ....................31 HITCHING TO THE TRACTOR ....................31 5.1.1 Sprayers with standard drawbar ..................31 5.1.2 Sprayer with steering drawbar ................... 32 MOUNTING OF THE TRANSMISSION SHAFT ................ 33 5.2.1 Cardan transmission shafts ....................33 5.2.2 Transmission with a single homocynetic joint...
  • Page 8 Blitz 45 - 50 - 55 TANK AND HYDRAULIC CIRCUIT DRAINING ..............53 LIFTING AND TRANSPORT ....................54 MAINTENANCE OPERATIONS .................... 55 13.1 LUBRICATION ........................55 13.2 FAN SHAFT SUPPORT OIL LEVEL CHECK ................56 13.3 FAN SHAFT SUPPORT OIL REPLACEMENT ................. 57 13.4...
  • Page 9 Blitz 45 - 50 - 55 FOREWORD 1.1 - PUBLICATION IDENTIFICATION The “OPERATION AND MAINTENANCE INSTRUCTIONS” manual is an integrative part of the sprayers. It is identified by a Publication No. located on the frontispiece, and through which the document can be identified, traced and/or subsequently referred to.
  • Page 10 Blitz 45 - 50 - 55 The following “symbols “ are used within the text in order to highlight and visually identify the importance of the various types of information: Indicates important additional information. Non observance can result in permanent damage to the sprayer.
  • Page 11 Blitz 45 - 50 - 55 GLOSSARY 2.1 - TERMINOLOGY The terms FRONT, REAR, RIGHT and LEFT utilised in this publication refer to the sprayer as seen by an operator from behind the operative unit along the drive line and facing it: the rear part of the machine is that closest to the operator, and is where the distribution device (Head) is mounted - and the front part is the one that gets attached to the tractor.
  • Page 12 Blitz 45 - 50 - 55 3 - 95005 - DANGER, PARTS IN MOTION. BEFORE REMOVING PROTECTION GUARDS, STOP THE TRACTOR, REMOVE THE KEY FROM THE TRACTOR’S CONTROL PANEL AND ENSURE THAT ALL MOVING PARTS HAVE STOPPED - Positioned on the tank front section, behind the fan casing.
  • Page 13 Blitz 45 - 50 - 55 Posizionamento adesivi di sicurezza, uso e manutenzione NOTE: The numbers with the asterisk (*) indicate the adhesives relevant either to optional components or accessories applied ONLY models and versions on which this is foreseen.
  • Page 14 Blitz 45 - 50 - 55 * Adesivi per la sicurezza 95001 95004 95005 95010 95007 95006 95015 95077 95009 95008 * Adesivi per l'uso e la manutenzione CONTROLLARE CHECK CONTRÔLER CONTROLAR 95054 95079 11 95059 95056 95057 95065 95060...

  • Page 15: General Information

    Blitz 45 - 50 - 55 GENERAL INFORMATION 3.1 - MACHINE IDENTIFICATION 00070 Identification nameplate 00620 3.2 - TECHNICAL ASSISTANCE C.I.M.A. S.p.A. is at the complete disposal of customers for any type of intervention. The names and addresses of its service network, both in Italy and in foreign countries, can be requested from: C.I.M.A.

  • Page 16: Safety Systems

    Blitz 45 - 50 - 55 - All maintenance and repair operations must be carried out only after having rinsed the tank and flushed the system. - Before operating within the tank it is necessary to wash it thoroughly with clean water.
  • Page 17 Blitz 45 - 50 - 55 THE OWNER AND/OR THE OPERATOR OF THE SPRAYER ARE NOT PERMITTED TO MODIFY THE STRUCTURE OR THE SPECIFIC OPERATION OF THE SPRAYER ITSELF. ANY REPAIR- ING INTERVENTION HAS TO BE CARRIED OUT EITHER AT THE DEALERS’ OR AT THE C.I.M.A.
  • Page 18 Blitz 45 - 50 - 55 3.5.3 - Disposal of empty containers and agro-chemicals residues Agro-chemicals are classified as “special” waste and their disposal must take place separately from “urban” wastes. Empty packaging and contaminated containers to be done away with cannot be dispersed, burned or buried.
  • Page 19 Blitz 45 - 50 - 55 MACHINE’S STRUCTURAL ANALYSIS The pictures indicate the position of the main components of the sprayer. CENTRIFUGAL MAIN TANK PRESSURE GAUGE HAND WASHING TANK TANK LEVEL INDICATOR PROTECTION CASING MAIN FILLER (BP) AXLE 00619 DRAWBAR...
  • Page 20 — Adjustable in height for 13 cm (16 cm for the 1500-2000 litres BLITZ 55 models). — Adjustable in length, with displacements of 8 – 16 – 24 –...
  • Page 21 Blitz 45 - 50 - 55 — The height with respect to the ground can be regulated. (The misalignment between the axle shaft and the wheels’ hub allows a variation of 12 cm). It is enough to turn the axle shafts.
  • Page 22 Blitz 45 - 50 - 55 The figure shows the support foot three possible positions Position A Position B Position C 00250 ONLY with the sprayer is linked to the tractor During the sprayer operation, the support foot has ALWAYS to be positioned on “C”.
  • Page 23 Blitz 45 - 50 - 55 SUPPORT BRACKET mounted on the drawbar, in order to house the transmission shaft when the machine isn’t hitched to the tractor. When the transmission shaft is mounted on the 2 PTO, the bracket has always to be lowered.
  • Page 24 Blitz 45 - 50 - 55 4.2 - STEERING DRAWBAR (on demand) IT IS NECESSARY TO USE THE HOMOCYNETIC CARDAN SHAFT. TRACTOR SIDE. The steering drawbar has to be mounted instead of the standard drawbar. It has to be fixed to the frame by a through screw provided with a a self-locking nut and locked by means of the two lateral screws.
  • Page 25 Blitz 45 - 50 - 55 4.3 - FAN SERVO AMPLIFIER It is positioned in the unit front section and protected by a plastic casing. Servo amplifier It is equipped with an automatic tensioner of the RELEASE AUTOMATIC driving poly-V belts that keeps the belt tension BELT constant, avoiding slipping and wear.
  • Page 26 Blitz 45 - 50 - 55 4.4 - HYDRAULIC CIRCUIT COMPONENTS Version prepared in order to mount the spray-line rinsing tank LEGEND: P - E = elements of the circuit T = piping * = For versions in which this is envisaged...
  • Page 27 Blitz 45 - 50 - 55 Versions with rinsing tank LEGEND: P - E = elements of the circuit T = piping * = For versions in which this is envisaged TO THE DISTRIBUTION HEAD POWDER MIXER TANK P2 P18 ®...
  • Page 28 Blitz 45 - 50 - 55 MAIN TANK Polyethylene tanks of 600, 800, 1000, 1500 and 2000 litre capacity Each tank is made up of: — tank main filler, (BP) with a 355 mm. diam.hinged cover (on 600 ltr. tank) or with a 400 mm diam.hinged cover (on 800, 1000, 1500 and 2000...
  • Page 29 Blitz 45 - 50 - 55 3-WAY LEVER TAP A WITH DISCHARGE FITTING Positioned on the pipe (T1), between the tank (P1) and the pump (P4), it is equipped with a closing plug of the discharge fitting, with the relevant safety chain.

  • Page 30: Centrifugal Pump

    Blitz 45 - 50 - 55 CENTRIFUGAL PUMP Fastened on the unit left front section, it is connected with the 3-way cock (P2) and with the pressure regulator (P5) and it is equipped with a filter on the suction. TO THE DISTRIBU-...
  • Page 31 Blitz 45 - 50 - 55 PRESSURE CONTROL ELECTRO-VALVE (for the version where foreseen) It is connected to the delivery filter (P6) and to the tank (P1), through the pipe (T3). It adjusts the operating pressure checking the backflow into the tank.

  • Page 32: Control Unit

    Blitz 45 - 50 - 55 E10. CONTROL UNIT It is electrically connected to the distributor with 2 motorised solenoid valves (E9) and to the main socket of the tractor (Lighter tap). The 2 lever switches, controlling the solenoid valves (E9), have to be set to “ON” for opening and to “OFF”...
  • Page 33 Blitz 45 - 50 - 55 P11. CALIBRATION DISC (Patent N° 23238) It selects the flow rates necessary to the treatment and is mounted on the distribution devices. It is made up of 2 flanges, held in position by two butterfly nuts, locking a disc with calibrated holes numbered from 1 to 15.
  • Page 34 Blitz 45 - 50 - 55 E20. PRESSURE SENSOR OF THE ADDITIONAL AGITATION PUMP The sensor of the pressure pump, placed on the delivery cone of the additional pump sends the pump pressure control signal to the control gearbox. CAUTION: at starting the RED low pressure warning light is “ON” ( CHECK LAMP function ) and it switches “OFF”...
  • Page 35 Blitz 45 - 50 - 55 P12. POWDER MIXER LEVER TAP (For versions in which his envisaged) Positioned on the pipe (T6), between the main tank (P1) and the centrifugal pump (P4), it can assume the following positions: a - Open From the centrifugal pump (P4), the liquid is sent to the mixer positioned on the bottom of the cup-like filter of the main filler (BP).
  • Page 36 Blitz 45 - 50 - 55 P15. UNIT-WASHING 3-WAY LEVER TAP (for versions in which thi envisaged) Positioned on the pipe (T1), between the tank (P1) and the pump (P4), it connects the unit-washing tank (P17) to the main pump (P4) suction.

  • Page 37: Technical Data

    Blitz 45 - 50 - 55 P13. POWDER MIXER It makes the mixing of the powdery products during the filling of the tank. It is mounted on the basket filter of the main filler (BP) and it is connected to the pump (P4) by the pipe (T6).
  • Page 38 Blitz 45 - 50 - 55 4.5.2 - Wheels: dimensions and operating pressures MODEL MEASURE WHEEL HUB PRESSURE BLITZ 45 600 - BLITTZ 50 600 7,00-12-6PR atm. 2,5 BLITZ 45 800 - BLITZ 50 800 7,00-12-6PR atm. 2,5 BLITZ 45 1000 - BLITZ 50 1000 10/80.12-6PR...

  • Page 39: Hitching To The Tractor

    Blitz 45 - 50 - 55 COUPLING MODALITIES 5.1 - HITCHING TO THE TRACTOR Check that the tractor “permissible trailed weight” is compatible with the sprayer weight, when this is fully loaded and complete with the equipments mounted for the treatment (see the Paragraphs “3.1” - “4.5.1” as well as the jointed documents).
  • Page 40 Blitz 45 - 50 - 55 12. Fasten the support foot to the frame, on stowage position (Position C). After every regulation, carefully tighten the screws and the bolt involved in the carried out operation. 13. After having properly fastened the fastening bracket supplied with the equipment,...
  • Page 41 Blitz 45 - 50 - 55 3. Screw the tie rod and put it under tension N.B:: lock the tie rod of the third point by the locking nut. 4. Lock the coupling by the chains of the arms of the mechanical power-lift.
  • Page 42 Blitz 45 - 50 - 55 DEFINITION OF THE TRANSMISSION SHAFT LENGTH. 1. After having hitched the sprayer to the tractor, set the operative unit to the maximum steering position allowed. 2. Measure the distance “D” between the grooves of the two PTOs.
  • Page 43 Blitz 45 - 50 - 55 5.3 - INSTALLATION OF REMOTE CONTROLS 5.3.1 - Electrical control panel - E10 1 - Fix the fastening bracket near to the driver (if not already available on the tractor). 2 - Insert the bayonet support of the control panel in the securing clamp.
  • Page 44 Blitz 45 - 50 - 55 5.3.2 - Manual 2-tap distributor - P9 (for the versions where foreseen) 1 - Mount the fastening bracket on the tractor MANUAL within the driver’s reach (if this is not already DISTRIBUTOR present on the tractor).

  • Page 45: Distribution Devices

    Blitz 45 - 50 - 55 DISTRIBUTION DEVICES Every distribution device is supplied with its own USE AND MAINTENANCE booklet that is, or will have to be, attached to this publication and will constitute one of its integral parts. The “Distribution devices –Operatio and maintenance instructions” manual both shows and describes the wide range of the distribution devices (heads), to be employed on each sprayer in order to assure a perfect covering, always answering to the real requirements of the culture to be treated.
  • Page 46 The connection elbows are being supplied with the trailed sprayers Series BLITZ 45 and BLITZ 50, while for the trailed sprayers Series BLITZ 55, the connection elbows are being supplied with the distribution sprayhead. COMPLETE...
  • Page 47 Blitz 45 - 50 - 55 ACCESSORIES 7.1 - FILLER PIPE The pipe is provided with a coupling elbow fitting and with a bottom-drawing valve. This is used for the filling of the tank. It must be connected to the pump suction (P4) instead of the chain-held stopper.
  • Page 48 Blitz 45 - 50 - 55 7.3 - VANE-TYPE MECHANICAL AGITATOR (Patent n° 1295858) (for the version where foreseen) The mixer consists of a header, to which some oriented feed openings, equipped with mixing paddles, are applied. The mixer is mounted inside the tank through two hollow supports, a front and a rear one, which are equipped with bushes allowing it to rotate.
  • Page 49 Blitz 45 - 50 - 55 7.6 - E.P.A. Kit - DELIVERY PROPORTIONAL ADVANCEMENT (for the version where foreseen) The computerized E.P.A. system executes the monitoring of the distribution parameters for the active automatic control of the distribution proportional to the feed.
  • Page 50 Blitz 45 - 50 - 55 FILLING FILLING MUST BE CARRIED OUT WITH THE MACHINE ON A FLAT SURFACE. ON THE SITE, BEFORE THE OPERATION, THE DOSES OR THE MIXTURES TO BE POURED INTO THE TANK MUST BE PREDISPOSED. IT IS NECESSARY TO ALWAYS MAKE USE OF PERSONAL PROTECTION.
  • Page 51 Blitz 45 - 50 - 55 8.1.b Fan engagement to perform the treatment EXECUTION: 1. Disengage the power take off (PTO) Stop the tractor, remove the key from the control panel and check that the fan is stopped. Unscrew the nuts that fix the protection mobile cover and remove it to enter the release.
  • Page 52 Blitz 45 - 50 - 55 9b. WITH POWDER PRODUCTS, WHEN USING THE MIXER (IF FORESEEN) 9b1. Pour the powder medicine dose into the cup-like filter of the main filler (BP). 9b2. Close the main filler (BP) of the tank.
  • Page 53 Blitz 45 - 50 - 55 The filter must always be below the level of the water to be loaded. The piping must never be above the pump’s suction point and must never be excessively bent in the vertical direction.
  • Page 54 Blitz 45 - 50 - 55 00211 00619 00628 00578 00630 00628 * for the version where foreseen ® Remote Control Spin Press. Pump 00240 00105 00093 00094 10-2007...

  • Page 55: Operating Procedures

    Blitz 45 - 50 - 55 MIXTURE AGITATION The hydraulic and the pneumatic circuits mounted inside the tank, allow to realize a double agitation system: with the pump water and with the fan air, at the same time. The pneumatic circuit can be excluded, when the products used have a quite strong foaming effect, by closing the pneumatic agitator cock.
  • Page 56 Blitz 45 - 50 - 55 e . Carefully calculate the exact quantity of the product necessary for the treatment and establish the volume of water to be used for the intervention. Check that the product is available in a quantity sufficient to complete the intervention.
  • Page 57 Blitz 45 - 50 - 55 g. Wash and rinse the just emptied product containers with clean water – collect the washing water and pour it in the tank before carrying out the filling – place the empty packaging in the specific container or in the collection area.
  • Page 58 Blitz 45 - 50 - 55 wash immediately all the elements that might have become contaminated during the treatment, promptly remove the polluted garments and interrupt the work if these cannot be immedia- tely replaced. g. Keep to the preliminary operations already indicated (11.1.c), in case of wind conditions prevailing.
  • Page 59 Blitz 45 - 50 - 55 LAVORO TRAVAIL WORKING TRABAJO 00631 LAVAGGIO NETTOYAGE CLEANING LIMPIEZA 00576 00632 10.5 - END OF TREATMENT - STORAGE 10.5.1 - Daily • The operator must: a. Wash the machine’s exterior before cleaning out the hydraulic circuit. The operative sequence will permit the elimination of possible water residues from the fan casing and piping conveying the air flow to the heads.
  • Page 60 Blitz 45 - 50 - 55 10.5.2 - End of seasonal cycle • L'operatore deve: a. Take the utmost care in carrying out the operations envisaged at the end of the daily treatments: the cleaning of the hydraulic circuit must be done at least twice. Check that no product residues are left in any part of the circuit.
  • Page 61 Blitz 45 - 50 - 55 TANK AND HYDRAULIC CIRCUIT DRAINING 11 - Stop the tractor and remove the key from the control panel. - Wear suitable protective clothing and accessories in order to avoid contamination by contact or inhalation of the mixture.

  • Page 62: Lifting And Transport

    Blitz 45 - 50 - 55 LIFTING AND TRANSPORT THE FOLLOWING ACTIONS ARE NOT ALLOWED: • Transporting or lifting the sprayer with residual quantities of mixture in the tank for purposes differing from its destined usage. • The transporting of people, animals or things.

  • Page 63: Maintenance Operations

    Blitz 45 - 50 - 55 MAINTENANCE OPERATIONS ALL OPERATIONS MUST BE CARRIED OUT WITH THE ENGINE SWITCHED OFF AND WITH THE IGNITION KEY REMOVED FROM THE CONTROL PANEL. 13.1 - LUBRICATION Maintenance Point Action Materiale di consumo Periodicità Fan shaft belt support...
  • Page 64 Blitz 45 - 50 - 55 STEERING DRAWBAR (*) (2 lubrication points) 00635 for the version where foreseen 00925 13.2 - FAN SHAFT SUPPORT OIL LEVEL CHECK 1. Unscrew and remove the oil filling plug with the dipstick. 2. Clean the dipstick and introduce it again.
  • Page 65 Blitz 45 - 50 - 55 13.3 - FAN SHAFT SUPPORT OIL REPLACEMENT Let the fan support oil replacement intervention be carried out at a C.I.M.A. customers’ service centre, or observe the regulations in force for the disposal of the used oil.
  • Page 66 Blitz 45 - 50 - 55 4. Remove the two collar (5) fastening bolts, fixing the fan casing to the rear cover. 5. Extract the fan casing (2). The impeller hasn’t to be disassem- bled. 7. Clean the impeller, by avoiding to use high...
  • Page 67 Blitz 45 - 50 - 55 13.7 - PUMP BELT TENSIONER Check length “L” of the spring (refer to picture): it should be in tension between 4 and 5 cm. L = 4 ÷ 5 cm 00231 00631 If the value measured exceeds 5 cm, tighten the belt tightener screw, up to get the minimum length (4 cm).
  • Page 68 Blitz 45 - 50 - 55 13.9 - TABLE OF MAINTENANCE OPERATIONS Check Fan belt-tensioner spring: YES YES CHECK LENGHT 9-12cm. Pump belt tensioner spring: YES YES CHECK LENGHT 4-5cm. Fan shaft support: CHECK OIL LEVEL YES YES hours Fan shaft support: REPLACE OIL...
  • Page 69 Blitz 45 - 50 - 55 FAULTS FINDING A. FAULT: By utilising the filler piping the pump doesn’t operate (suction) It is necessary to disengage the drive outlet (PTO) and wait for it to stop rotating before repeating the filling operation.
  • Page 70 Blitz 45 - 50 - 55 3. CAUSE: Wrong positioning of the circuit-washer faucet (P15) with the circuit-washer tank empty. REMEDY: Position the lever of the faucet correctly (P15 - pos”. 1") and fill the circuit- washer tank. 4. CAUSE: Lack of seal of the O-Ring gasket of the pump suction connection (cone).
  • Page 71 Blitz 45 - 50 - 55 J. FAULT: No spraying action delivered: totally or only on the one side of the distribu- tion device 1. CAUSE: Manual distributor (P8) taps dirty or clogged, or pump suction piping clogged by hardened product deposits.
  • Page 72 Blitz 45 - 50 - 55 REPAIRS ALLOWED THE OWNER AND/OR THE OPERATOR OF THE SPRAYER ARE NOT PERMITTED TO MODIFY THE STRUCTURE OR THE SPECIFIC OPERATION OF THE SPRAYER ITSELF. ANY REPAIR- ING INTERVENTION HAS TO BE CARRIED OUT EITHER AT THE DEALERS’ OR AT THE C.I.M.A.

  • Page 73: Pressure Gauge Replacement

    Blitz 45 - 50 - 55 15.2. - REPLACEMENT OF ELECTRICAL PANEL’S FUSES Stop the engine and remove ELECTRICAL the ignition key from the CONTROL tractor’s control panel. PANEL Replace the faulty fuse and screw back the cover. · Fuse: 10 A, delayed.
  • Page 74 Blitz 45 - 50 - 55 15.4 - TANK REMOVAL OR REPLACEMENT This operation has to be carried out by a C.I.M.A. service point The operation has to be carried out by complete absence of liquid residuals both inside the tank and in the hydraulic circuit.
  • Page 75 Blitz 45 - 50 - 55 INTEGRATIVE DIAGRAMS 16.1 - HYDRO-PNEUMATIC DIAGRAM PLUNGER DISTRIBUTION DEVICE DELIVERY DELIVERY FLOW MAIN TANK ROTATING WASHING DISC TANK REGULATORS PRESSURE GAUGE E20 * P20 * ELECTRICAL DISTRIBUTOR Wire W1 ADDITIONAL PUMP ELECTRICAL ® Remote Control Spin Press.

  • Page 76: Wiring Diagram

    Blitz 45 - 50 - 55 16.2 - WIRING DIAGRAM 00001 10-2007...

  • Page 77: Noise Level

    Blitz 45 - 50 - 55 NOISE LEVEL Observed equivalent average Sprayer model level L qA - dB(A) BLITZ 45T 92,0 ± 0,2 BLITZ 50T 93,0 ± 0,2 BLITZ 55T 95,4 ± 0,2 BLITZ 55TS 95,4 ± 0,2 BLITZ 55TE 95,4 ±...
  • Page 78 Blitz 45 - 50 - 55 ATTACHMENT : DECLARATON OF CONFORMITY 10-2007...

  • Page 79: Warranty

    The products which have been modified, repaired, assembled or tampered with by a third party, consumption materials and the parts subject to wear and tear are excluded from the warranty. The replacements will be made free CIMA S.p.A. works and the buyer will be responsible for all shipping and return expenses.
  • Page 80 Blitz 45 - 50 - 55 NOTES ........................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................10-2007...
  • Page 81 Blitz 45 - 50 - 55 NOTES ........................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................10-2007...
  • Page 82 Blitz 45 - 50 - 55 NOTES ........................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................10-2007...
  • Page 83 Blitz 45 - 50 - 55 CERTIFICATE OF WARRANTY Copy for the owner (to be kept in the manual “Instructions for the use and maintenance) Last name, Name or NAME OF THE FIRM ......................ADDRESS .......................... Place ..............PROVINCE ..... ZIP ....
  • Page 84 The replacements will be made free CIMA S.p.A. works and the buyer will be responsible for all shipping and return expenses. The buyer will be responsible for the costs of the labour needed to replace the parts considered defective.

  • Page 85: Certificate Of Warranty

    Atomizzatori - Impolveratori Blitz 45 - 50 - 55 CERTIFICATE OF WARRANTY The warranty will not be considered valid if this coupon, with every part of it filled in, is not mailed to the following address: C.I.M.A. S.p.A. - 27040 Montù Beccaria, Loc. Molino Quaroni - (PV) - Italy), or sent by fax to the following number: +39.0385.246637, within 30 days from the date of purchase.
  • Page 86 The replacements will be made free CIMA S.p.A. works and the buyer will be responsible for all shipping and return expenses. The buyer will be responsible for the costs of the labour needed to replace the parts considered defective.
  • Page 88 S.p.A. 27040 Montù Beccaria - Loc. Molino Quaroni - (PV) - ITALIA Tel. +39.0385.246636 r.a. - Fax +39.0385.246637 http://www.cimaitalia.com...
