- Page 1 Air Conditioner User Manual GJC15BY-A6NRNC5A IMPORTANT : Please read this manual carefully before running this unit, and save it for future reference. © Copyright, Gree Canada, 2021 042021...
-
Page 3: Table Of Contents
This instruction manual is the universal-purpose version for this product manufactured by Gree Canada. The appearance of the unit that you have purchased may differ from the ones seen in this manual, however it does not change the basic guidelines on how to operate this appliance. -
Page 4: Safety Instructions
SAFETY INSTRUCTIONS WARNINGS AND CAUTIONS Read the following safety instructions before installing the unit or doing service work. This symbol indicates an imminently hazardous situation that, DANGER if not avoided, will cause severe personal injury, death, or substantial property damage. This symbol indicates a potentially hazardous situation that, if not WARNING avoided, can cause severe personal injury, death, or substantial... - Page 5 SAFETY INSTRUCTIONS Do not, under any Do not use an extension cord or Do not remove the power plug circumstances, cut, remove, or an adapter. or move the unit by yanking the bypass the grounding prong. cord. It may cause failure of the product. It may cause failure of the product It may cause failure of the product or electric shock.
-
Page 6: Electrical Informations
SAFETY INSTRUCTIONS ELECTRICAL INFORMATIONS The complete electrical rating of your new room air conditioner is stated on the serial plate. Refer to the rating when checking the electrical requirements. To minimize the risk of electric shock, make sure the air conditioner is properly grounded. The power cord of the unit is equipped with a 3-prong grounding plug that must be plugged into a matching grounded outlet. -
Page 7: Main Components
MAIN COMPONENTS FRONT VIEW Outdoor air vents Air outlet Air inlet Control panel Swinging louvers Power cord and plug Bottom mounting rail Directional airflow adjustment knob V-frame bracket (2) Sill bracket (2) Sash lock (2) Side mounting rail (2) Top mounting rail Non-adhesive foam Adhesive foam Adhesive foam... -
Page 8: Installation Guide
INSTALLATION GUIDE LOCATION RECOMMENDATIONS Proper installation is your responsibility, therefore make sure the location where you have chosen to install your new room air conditioner satisfies the following conditions : ▪ A grounded electrical outlet within 4 ft (122 cm) of where the power cord exits the air conditioner. ▪... -
Page 9: Installation Procedure
INSTALLATION GUIDE INSTALLATION PROCEDURE NOTES : ▪ Installation of this appliance requires basic mechanical skills. ▪ Completion time : approximately 1 hour. We recommend that two people install this product. ▪ Proper installation is the responsibility of the installer. ▪ Product malfunction due to improper installation is not covered under the warranty. ▪... - Page 10 INSTALLATION GUIDE 2. Unfasten the four screws securing the front case. Pull out the bottom of the front case, then lift it upwards to remove it. Screws Front case FIG. 7 – Unfastening the front case FIG. 8 – Removing the front case 3.
- Page 11 INSTALLATION GUIDE 5. Tear off the strap holding the protective foam and remove both pieces. Protective foam Strap FIG. 12 – Removing the foam and strap ► STEP 2 : Installing the Top Mounting Rail 1. Making sure both pieces are aligned, firmly stick the sponge strip under the top mounting rail. 2.
- Page 12 INSTALLATION GUIDE 2. Stick a short adhesive foam weatherstripping to the side of the flexible panel frame that will be meeting the window frame. Repeat this same step for the other panel. FIG. 16 – Sticking foam weatherstripping to the flexible side panels 3.
- Page 13 INSTALLATION GUIDE ► STEP 4 : Window Preparation Stick a long adhesive type foam weatherstripping to the bottom of the window frame and another piece under the window sash. Adhesive foam weatherstripping FIG. 20 – Sticking foam weatherstrippings ► STEP 5 : Installing the Outer Case in the Window 1.
- Page 14 INSTALLATION GUIDE OUTDOOR REAR SECTION Outer case Type E bolt and nut V-frame bracket FIG. 23 – Fixing the V-frame brackets to the outer case 3. Adjust the vertical position v-frame brackets in order to obtain a slight inclination of the outer case. Tighten the bolt once you are done with adjustments.
- Page 15 INSTALLATION GUIDE ► STEP 6 : Finalizating the Installation in the Window 1. Fasten the sash locks to the window sash and frame (or upper sash). Window frame Window sash FIG. 26 – Fixing the sash locks to the window sash 2.
- Page 16 INSTALLATION GUIDE 2. Fasten the grounding screws on the sides of the outer case. Also fix the screws of the control panel. FIG. 29 – Fastening the grounding screws and control panel screws 3. Reinstall the front case by first fastening the upper part to the outer case, and then pushing in the bottom part.
- Page 17 INSTALLATION GUIDE ► STEP 8 : Installing the Insulation Foam Boards 1. Measure the width between the outer case of air conditioner and the window frame. FIG. 33 – Measuring the needed length 2. Take one the the foam insulation board. Cut the board to the length previously measured. Repeat this same step for the second board.
-
Page 18: Operation Guide
OPERATION GUIDE CONTROL PANEL OVERVIEW Control Panel Buttons Power Set timer Mode selection Filter reminder reset Fan speed selection Increase / Decrease Control Panel Indicators Display screen Setting mode Filter cleaning reminder Operation modes Timer Fan speeds... -
Page 19: Remote Control Overview
OPERATION GUIDE REMOTE CONTROL OVERVIEW ˚F OPER ˚C AUTO Remote Control Buttons Power ON / OFF Mode selection Increase / Decrease Fan speed selection Sleep mode I Feel function Set timer Remote Control Indicators Operation modes Switch-on timer Switch-off timer ˚F I Feel function OPER... -
Page 20: Button Functions
OPERATION GUIDE BUTTON FUNCTIONS Functions are the same when using the remote control and control panel, unless otherwise stated. CONTROL REMOTE PANEL CONTROL POWER ON / OFF Press this button to turn the air conditioner on or off. TIP : When turned on, the unit will operate in Energy Saving mode. If the unit is powered on after a power failure, the unit will resume operation according to the settings used prior to the power failure. - Page 21 OPERATION GUIDE CONTROL REMOTE PANEL CONTROL SET TIMER To set a Switch-Off Timer, press this button while the unit is running. To set a Switch-On Timer, press this button while the unit is turned off. Use the the the ▲ or ▼ buttons to select the desired time value. The timer can be set within 1 to 24 hours and is adjusted by increments 1 hour.
-
Page 22: Battery Replacement
OPERATION GUIDE BATTERY REPLACEMENT Batteries (AAA) Rear of the 1. Remove the cover of the battery compartment batteries. remote control 2. Remove the used batteries, then place two new “AAA” Cover 1.5 V batteries into the compartment. Make sure the “+” and “–”... -
Page 23: Care & Maintenance
CARE AND MAINTENANCE CLEANING THE APPLIANCE WARNING ▪ Before cleaning, turn off the air conditioner and disconnect the power cord. Failing to do so may lead to electric shock. ▪ Do not wash the appliance with water, it may lead to electric shock. ▪... -
Page 24: Post-Season Storage
CARE AND MAINTENANCE POST-SEASON STORAGE 1. Set the temperature at 30 °C (86 °F) and let the unit run for half a day. This is to dry the inside of the unit. 2. Turn off the air conditioner and disconnect the power cord. 3. -
Page 25: Troubleshooting
TROUBLESHOOTING COMMON ISSUES If your appliance appears defective, please check the possible explanations for your situation in the table below, it may be that a simple solution can help solve the problem. If the problem persists, contact your local dealer or a qualified technician. SITUATION POSSIBLE CAUSES SOLUTIONS... -
Page 26: Malfunction Codes
TROUBLESHOOTING There is no airflow The air vents are obstructed. Clear objects or furniture that could be blocking the coming out of the air vents of the unit. conditioner. The set temperature The unit is operating in Automatic The temperature cannot be adjusted in Automatic cannot be adjusted. -
Page 27: Warranty
Note : The compressor is covered by a 5-year limited warranty. During the warranty period, if the product fails under normal use, Gree Canada will, at its option, either repair the unit or replace it, free of charge, within a reasonable period of time after the product is returned.As a condition to any warranty service obligation, the customer must present this warranty... - Page 28 NOTES...
