- Page 1 Window Air Conditioner Installation Manual GJC08BS-A6NRNJ1B(WIFI) GJC10BR-A6NRNJ1C(WIFI) GJC12BR-A6NRNJ1C(WIFI) IMPORTANT : Please read this manual carefully before running this unit, and save it for future reference. © Copyright, Gree Canada, 2021 042021...
-
Page 3: Table Of Contents
This instruction manual is the universal-purpose version for this product manufactured by Gree Canada. The appearance of the unit that you have purchased may differ from the ones seen in this manual, however it does not change the basic guidelines on how to operate this appliance. -
Page 4: Safety Precautions
1.0. SAFETY INSTRUCTIONS 1. SAFETY PRECAUTIONS The following symbols and labels are used throughout this manual to indicate immediate or potential hazards. It is the owner’s responsibility to read and follow all safety information and instructions accom- panying these symbols. Failure to heed safety information increases the risk of serious injury or death, property damage and/or product damage. - Page 5 1. SAFETY PRECAUTIONS Electrical Safety CAUTION : The power cord of this air conditioner contains a current sensing device designed to reduce the risk of fire. Please refer to the Operation of Current Device section below for more details. If the power cord is damaged, it cannot be repaired. It must be replaced with a power cord from the product manufacturer.
-
Page 6: Air Conditioner Overview
1.0. SAFETY INSTRUCTIONS 2. AIR CONDITIONER OVERVIEW COMPONENTS 1. Control panel 4. Bottom mounting rail 7. Air outlet 10. Air inlet 2. Exhaust air vents 5. Power cord 8. Directional flaps 11. Power plug 3. Side mounting rail 6. Top mounting rail* 9. -
Page 7: Air Conditioner Installation
3. AIR CONDITIONER INSTALLATION 3.1. PRE-INSTALLATION INFORMATION CAUTION : When handling the unit, take care to avoid cutting yourself on the sharp metal edges and aluminum fins of the front and rear coils. WARNING : ▪ Observe all electrical codes and ordinances. ▪... - Page 8 1.0. SAFETY INSTRUCTIONS 3. AIR CONDITIONER INSTALLATION Installation Location Recommendations ▪ Make sure there are no object in the vicinity of the unit that could obstruct the indoor air inlet or outlet, or the outdoor exhaust air vents. 475 mm (18.7 in) ▪...
-
Page 9: Installation Instructions
3. AIR CONDITIONER INSTALLATION 3.2. INSTALLATION INSTRUCTIONS Required Tools Phillips-head screwdriver Pencil Level Flat-head screwdriver Ruler or measuring tape Scissors or x-acto knife Peel the film from the back of the adhesive foam seal C. Top mounting rail Align the strip with the lower edge of the top mount- ing rail, then press it onto the mounting rail to seal completely. - Page 10 1.0. SAFETY INSTRUCTIONS 3. AIR CONDITIONER INSTALLATION Before fixing the flexible screen panels to the unit, Screen panel frame (right) place a piece of sponge strip along the frame on the right side of the panel marked RIGHT, as shown in the illustration.
- Page 11 3. AIR CONDITIONER INSTALLATION Place the air conditioner on the sill with the lower Window sash mounting rail against the rear edge. Center the unit and Top mounting rail close the window securely behind the top mounting rail. Inclination of The unit should be tilted slightly outwards.
- Page 12 1.0. SAFETY INSTRUCTIONS 3. AIR CONDITIONER INSTALLATION Insert the foam seal B between the glass and the win- dow sash to prevent air from seeping into the room. If Foam seal B the strip does not fit properly to your window, acquire an appropriate material from a local store to ensure a proper seal.
-
Page 13: Operation Guide
4. OPERATION GUIDE 4.1. FEATURES “I Feel” LCD Remote Control The remote control acts as a separate temperature sensor for added comfort. The mini-sensor in the remote control is able of measuring the room temperature which is then transmitted to the window unit. The unit will cool the room until the desired temperature is reached at the remote control location. -
Page 14: Control Panel Buttons And Indicators
1.0. SAFETY INSTRUCTIONS 4. OPERATION GUIDE 4.2. CONTROL PANEL BUTTONS AND INDICATORS NOTICE : On the control panel, use the keys to set the fan speed setting to Low, Med or High. Use the Auto pad to turn Auto fan speed on. -
Page 15: Remote Control Button Functions
4. OPERATION GUIDE 4.3. REMOTE CONTROL BUTTON FUNCTIONS NOTICE : ▪ The distance between the remote control and the window unit must not exceed 8 me- ters (26 ft), and there must be no obstacles in between. ▪ If you do not use the remote control for an extended period of time, please remove the batteries. -
Page 16: Airflow Direction Adjustment
1.0. SAFETY INSTRUCTIONS 2.0. OPERATING PRINCIPLE 4. OPERATION GUIDE 4.4. AIRFLOW DIRECTION ADJUSTMENT Horizontal Airflow Adjustment Adjust the vertical flaps to the left or right to direct the airflow according to your preference. Vertical flaps Vertical Airflow Adjustment Adjust the horizontal flaps up or down to direct the airflow according to your preference. -
Page 17: Care And Maintenance
3.0. MAIN COMPONENTS 5. CARE AND MAINTENANCE WARNING : ▪ Turn off the air conditioner and unplug the power cord from the outlet before cleaning to avoid electric shock. ▪ Do NOT wash the air conditioner with water to avoid electric shock. ▪... - Page 18 1.0. SAFETY INSTRUCTIONS 2.0. OPERATING PRINCIPLE 5. CARE AND MAINTENANCE Post-season Storage 1. Set the temperature at 30 °C (86 °F) and let the unit run for half a day. This is to dry the inside of the unit. 2. Turn off the air conditioner and disconnect the power cord. 3.
-
Page 19: Troubleshooting
3.0. MAIN COMPONENTS 6. TROUBLESHOOTING WARNING : If the situations below are observed, please turn off the air conditioner and immediately unplug the power cord from the outlet and contact Customer Service : ▪ Overheating or damaged power cord. ▪ Abnormal sounds during operation. ▪... -
Page 20: Common Issues
1.0. SAFETY INSTRUCTIONS 2.0. OPERATING PRINCIPLE 6. TROUBLESHOOTING 6.3. COMMON ISSUES If your appliance appears defective, please check the possible explanations for your situation in the table below, it may be that a simple solution can help solve the problem. If the problem persists, please call 1 800 686-2175 for assistance. -
Page 21: Malfunction Codes
3.0. MAIN COMPONENTS 6. TROUBLESHOOTING The remote control The distance between the appliance and Get closer to the unit so the remote control signal can does not work. the remote control is too great. reach the main unit's receiver. The remote control is not properly aligned Make sure to be facing the unit when pressing keys with the main unit’s signal receiver. -
Page 22: Warranty
Note : The compressor is covered by a 5-year limited warranty. During the warranty period, if the product fails under normal use, Gree Canada will, at its option, either repair the unit or replace it, free of charge, within a reasonable period of time after the product is returned.
