Introduction

Features

Modes and
Resolution Table
PC VGA to TV Video Converter-Hand View III is a handed-size
The
universal VGA to TV converter box. It supports resolution up to
1280x1024. Compact size, Power from USB port, easy for carry. It is best
for PC GAME, PC DVD, Internet viewing on TV, Entertainment,
Education and Presentation.
• Pure hardware design, just Plug & Display. No software driver is required and it
is compatible with any operation system.
The PC VGA to TV Video Converter-Hand View II has two
•
model :
I. Model one (for NTSC / PAL ) :
INPUT : VGA, USB 5V
•
OUTPUT : VIDEO, S-VIDEO, VGA ( connect to PC Monitor)
•
II. Model two (for Europe ) :
INPUT : VGA, USB 5V
•
OUTPUT : VIDEO, S-VIDEO, VGA ( connect to PC Monitor),
•
( For EUROPE system RGB SCART input )
• Simultaneous display on VGA monitor and TV.
• Allows SIZE change ( overscan and underscan function ) .
• Power from USB port or PS2 port
• True 24 bit A/D converter for the true 16.7 million color conversion.
•
Supports IBM PC and MAC G4.
• Supports one of the following system: NTSC(US/Taiwan), NTSC (JAPAN), PAL,
PAL-M, PAL-N system.
This converter supports the following VGA ( IBM PC) display modes:
Resolution 640 x 480
Vertical
60,72, 75,85
Frequency(Hz)
( optional ) ( DC 5V ).
800 x 600 1024 x 768
60,72,75,85 60,70,75,85
RGB
1280x1024
60
