- Page 1 Instruction Manual...
- Page 2 Manual Conventions CAUTION This manual uses the following symbols to help differentiate between different kinds of information. CAUTION indicates a potentially The safety symbol is used with a key word to alert hazardous situation which, if not avoided, you to potential hazards in operating and owning may result in minor or moderate injury.
-
Page 3: Safety Rules
• Rope must be controlled while recoiling to tightened per installation instructions. prevent personal injury or damage. • Never operate this KFI product with • Device contains a coiled spring under missing or damaged parts. tension. Do NOT remove nuts securing the •... - Page 4 41027 SPRING COVER ASM 41025 SPRING COVER 41026 TIGERTAIL SPRING 71206 XT SHAFT 101121 KFI TIGERTAIL ROPE ASSEMBLY 101122-15 TIGERTAIL XT ROPE 41013 7/16" WIRE ROPE THIMBLE 41011 TOW HOOK #12 ZINC CB-ZP-1024-0_63 #10-24 x 5/8" CARRIAGE BOLT, STEEL, ZINC...
-
Page 5: Installation Instructions
InsTaLLaTIon InsTrucTIons Note: TigerTail installation requires the correct mounting bracket to be installed prior to proceeding. TigerTail Mount instructions included with the purchase of a TigerTail Mount will include more detail directions for vehicle specific TigerTail installation (only use supplied bolts). 1) Place hook in hook hole and adjust tention of hook arm ,until hook does not fall out of hole, using the two nuts and bolts on right side of TigerTail. - Page 6 DIrecTIons Follow precautions as described in OEM Manual. Review TigerTail UT Operation and Maintenance Manual prior to each use. 1. Position towing vehicle and towed vehicle such that both vehicles are in line. 2. Place the parking brake on and dismount tow vehicle. Refer to the OEM manual for proper locations for attach points. 3. Rotate tow system spool to release tension on hook. 4. Pull out rope to ease hook removal from hook storage tab. 5. Attach hook to a secure point on vehicle to be towed as specified in the OEM. 6. Ensure that the vehicle to be towed is not high-centered. 7. Place the vehicle to be towed in Neutral. 8. Remount the tow vehicle and release the parking brake. 9. Extend rope by driving slowly (2 mph max) away from the vehicle to be towed.
- Page 7 Notes: Page 7...
-
Page 8: 6 Month Limited Warranty
Please register your product with Kappers Fabricating, Inc. (KFI) within fifteen (15) days of purchase to assist us in handling any warranty issues that may arise by filling out this Registration card and submitting it with a copy of your sales receipt from one of KFI’s official resellers.
