EEI-1794/1795
Thank you for purchasing the MODWAY ARM SECTIONAL SOFA!
Before you start, here is some helpful advice:
1.We suggest you spend a short time reading through this leaflet and then follow the simple step by step
instructions.
2.Owing to the size and weight of the arm sectional sofa, we recommend that it is assembled by two adults, on a
carpeted or padded area, in the room that it is intended for. Approximate assembly time: 30 minutes.
3.Please do not use any tools other than those provided or recommended in these instructions.
4.Please do not throw away any of the packaging or instructions until you have checked all the components and
hardware and the furniture is fully assembled.
5.Assemble all components loosely until advised to tighten. Depending on use, it may be necessary to tighten the
components from time to time, so please save the tools that have been provided.
6.Please keep all pieces out of reach of small children.
Component:
EEI-1795 Right Loveseat Carton
2
1
Right Loveseat Body x1
Customer Service 908-368-1025︱www.modwayfurniture.com
ARM SECTIONAL SOFA
EEI-1795
1
2
2
Leg x4
Hardware:
A
B
C
2
D
E
F
EEI-1794
Bolt
Spring Washer
Flat Washer
Allen Wrench
Clip
7
Screw
Page 1 of 5
x8
x8
x8
x1
x1
x4
Advertisement
Table of Contents
Related Manuals for modway Engage EEI-1794
Summary of Contents for modway Engage EEI-1794
- Page 1 EEI-1794/1795 ARM SECTIONAL SOFA Thank you for purchasing the MODWAY ARM SECTIONAL SOFA! Before you start, here is some helpful advice: 1.We suggest you spend a short time reading through this leaflet and then follow the simple step by step instructions.
- Page 2 EEI-1794/1795 ARM SECTIONAL SOFA EEI-1794 Chaise Carton Hardware: Bolt Spring Washer Flat Washer Allen Wrench Clip Post Screw Leg x4 Chaise Body x1 STEP 1: Please put the Chaise Body (3) upside down on a carpeted or padded area by two adults to make fully visible the corners. Open the Zipper on the bottom of Chaise Body (3) as shown.
- Page 3 EEI-1794/1795 ARM SECTIONAL SOFA STEP 2: Carefully turn over the chaise. STEP 3: Please put the Right Loveseat Body (1) upside down on a carpeted or padded area by two adults to make fully visible the corners. Open the Zipper on the bottom of Right Loveseat Body (1) as shown. Take out the 4pcs Sofa Legs (2) and hardware package on bottom of the Right Loveseat Body (1).
- Page 4 EEI-1794/1795 ARM SECTIONAL SOFA STEP 4: Carefully turn over the right loveseat. STEP 5: Please place the Chaise Set (2) at your desired location. Align the Clip (E) on the bottom of Right Loveseat (1) to the Clip Posts (G) on the bottom of Chaise Set (2) as shown. Push the Right Loveseat (1) close to the Chaise (2) slowly until the Clip and the Post click together tightly.
- Page 5 EEI-1794/1795 ARM SECTIONAL SOFA STEP 6: If you want to unlock the sofa. Please lift up the Chaise (3) by two people. Assembly is completed. The arm sectional sofa is ready to enjoy now! Customer Service 908-368-1025︱www.modwayfurniture.com Page 5 of 5...
