Electro-Voice Contractor Precision CPS2.4 Technical Specifications

Key Features:

• 2 x 600W/2 Ohms
• High Efficient Class-H Design
• 2 U Rack Space
• Detend Rear Level Controls
• Complete Protection Package
• Dynamic Limiter
• Phoenix Type Inputs
• Barrier Outputs
• Retrofit Signal Processing Kits
• Remote Power On/Off

General Description:

The Electro-Voice® CPS2.4 is from the Contractor Precision Se-
ries of professional amplifiers. The high efficient Class-H design
reduces the power dissipation significantly and allows for more
amplifier channels and output power in a given rack space.
The audio performance of the CPS2.4 is state-of-the art and
fulfills the highest sound expectations in demanding applications
from concert sound to theater. The CPS2.4 features the same
complete protection package as all EV Precision Series amplifi-
ers. Protection against: excessive HF, DC fault, high temperature,
and Back-EMF as well as turn-on delay, peak current and inrush
current limiters. In addition to the rated output power the CPS2.4
provides up to 30% percent headroom for a wide dynamic range
on music signals. The onboard dynamic limiter ensures that the
output clipping of the CPS2.4 will not exceed a THD of 1% up
to an input signal of +21dBu. Detented level controls on the rear
panel provide precise (1dB-detend) and repeatable settings.
Front panel LEDs indicate signal present, 0 dB, and limit. Female
XLRs and Phoenix type connectors for inputs and barrier strips
for outputs provide an easy rack wiring. The power on/off function
of the CPS2.4 can be remote controlled via a 24V DC source.
Optional x-over cards for biamp operation (e.g. a 2-way cinema
system) can be retrofitted.
High-Efficient, Lightweight
Two-Channel

Power Amplifier

Technical Specifications:

Load Impedance:
Maximum Midband Output Power
(THD = 1%, 1 kHz, Dual Channel):
Rated Output Power
(THD = 0,1 %, 20 Hz - 20 kHz):
Maximum Bridged Output Power
(THD = 1%, 1 kHz):
Maximum RMS Voltage Swing
(THD = 1%, 1 kHz):
Power Bandwidth
(THD = 1%, 1 kHz, Half Power @ 4 Ohms):
Voltage Gain ref. 1 kHz:
Input Sensitivity
(@ Rated Power, 8 Ohms, 1 kHz):
THD @ Rated Output Power
(<0.1%, CPS2T@100V):
IDE-SMTP (60 Hz, 7 kHz):
DIM 30 (3.15 kHz, 15 kHz):
Maximum Input Level:
Crosstalk (ref. 1 kHz, Rated Output Power):
Frequency Response (+/- 1 dB, ref. 1 kHz):
Input Impedance Active Balanced:
Damping Factor @ 1 kHz:
Slew Rate:
Signal-to-Noise Ratio (A-Weighted):
Power Requirements
Power Consumption:
Power Dissipation
(1/8 Max. Output Power @ 4 Ohms):
Protection:
Dimensions (W x H xD):
Net Weight:
Shipping Weight:
- Amplifier at rated conditions, both channels driven, 8 ohm loads, unless otherwise specified.
Factory Configured.
1
CPS2.4
2 Ohms 4 Ohms
600W 400W
- 300W
- 1240W
50V
10 Hz - 60 kHz
32.0 dB
+1.15 dBu (0.88 Vrms)
< 0.05%
<0.02%
<0.01%
+22 dBu (9.76 Vrms)
<-80 dB
15 Hz - 40 kHz
20 kOhms
>300
35 V/us
103.5 dB
240V, 230V, 220V, 120V, or
: 100V; 50 - 60 Hz
1
(Factory Configured)
600W
396W (1350 BTU/hr)
Audio Limiters, High Temperature,
DC, HF, Back-EMF, Peak Current
Limiters, Inrush Current Limiters,
Turn-On Delay
Cooling: Front-to-Rear, 3-Stage Fans
483mm x 88.1mm x 368.8mm
(19" x 3.5" x 15.22")
15.3 kg (30.8 lbs)
16.8 kg (34.1 lbs)
8 Ohms
240W
150W
800W
