4.9 Installing the Network Cable 4.9 Installing the Network Cable
If remote monitoring over the network is required, complete
the following steps to connect the Ethernet module with
embedded web server�
NOTE: For initial configuration, it is recommended to use a
crossover Cat 5/5e/6 UTP cable to connect a laptop directly to
the Ethernet port of the Matrix panel. If the laptop is configured
for Auto MDI-X, a straight-through cable may be used�
Step 1. Connect a Cat 5/5e/6 UTP Ethernet cable from the local
network to the Ethernet port on the rear of the panel�
Refer to "Appendix A: Mechanical Drawings" on Page
27 for exact location� Use a TIA/EIA T-568B pinout for
the network connection�
Step 2. For information on configuring the web server, see "5.6
Review System Status via the Embedded Web server"
on Page 18�
14
Figure 16. Ethernet Jack
