9.0 Models and Accessories

Models and Accessories
Table 8. Model Configurations
DESCRIPTION
Matrix C16 Panel; Single Input; -48VDC; (16) Connectorized Breaker Positions;
SmartSwitch Supervisory Controller; Ethernet
Matrix C16 Panel; Dual Input; -48VDC; (16) Connectorized Breaker Positions; SmartSwitch
Supervisory Controller; Ethernet
Matrix C16 Panel; Single Input; -48VDC; (16) Connectorized Breaker Positions; Standard
LED Indicators; w/o Ethernet
Matrix C16 Panel; Dual Input; -48VDC; (16) Connectorized Breaker Positions; Standard
LED Indicators; w/o Ethernet
Table 9. Accessories
DESCRIPTION
Output Connector Kit (#6-8 AWG);
Includes (6) C545-187-10 #6-8 AWG 100A Connectors
Output Connector Kit (#10-14 AWG);
Includes (6) C545-187-10 #10-14 AWG 100A Connectors
90 Degree Input Lug Bracket Connection Kit - Dual Input
Matrix C16 Rear Mount Support Kit w/Adjustable Lacing Bar
Table 10. Replacement Parts
DESCRIPTION
SmartSwitch Supervisory Controller
(C016-1621-10 and C016-1622-10 models only)
Circuit Breaker Puller/Extractor Tool
Embedded Ethernet Module Option for Remote Monitoring
(C016-1621-10 and C016-1622-10 models only)
Matrix C16 Mounting Kit;
Includes Mounting Ears/Hardware for 19" and 23" Rack Configurations
Table 11. Compatible Circuit Breakers
DESCRIPTION
2A Slimline Circuit Breaker
3A Slimline Circuit Breaker
5A Slimline Circuit Breaker
10A Slimline Circuit Breaker
20A Slimline Circuit Breaker
30A Slimline Circuit Breaker
40A Slimline Circuit Breaker
50A Slimline Circuit Breaker
60A Slimline Circuit Breaker
70A Slimline Circuit Breaker
80A Slimline Circuit Breaker
100A Slimline Circuit Breaker
25
PART NUMBER
C016-1621-10
C016-1622-10
C016-1623-10
C016-1624-10
PART NUMBER
C016-1262-10
C016-1264-10
C750-171-10
C750-284-10
PART NUMBER
C740-413-40
C016-1318-10
C740-558-40
C750-175-10-B
(Black Powdercoat)
C750-175-10-W
(White Powdercoat)
PART NUMBER
C470-711-10
C470-700-10
C470-701-10
C470-702-10
C470-703-10
C470-704-10
C470-705-10
C470-706-10
C470-707-10
C470-728-10
C470-729-10
C470-730-10
C048-725-30 Rev. B (01/2020)
