• Keep informed about current disposal options from your dealer or from your Local Council.
• Before scrapping the appliance, cut the power cord and make it useless.

3. TECHNICAL SPECIFICATIONS

WIDTH
DEPTH
HEIGHT
BIOETHANOL TANK CAPACITY
NET WEIGHT
GROSS WEIGHT
FUEL
NOMINAL OUTPUT
AUTONOMY RANGE
MAXIMUM CONSUPTION
MINIMUM CONSUMPTION
ADJUSTABLE FEET
RATED POWER
SUPPLY VOLTAGE
NOMINAL FREQUENCY
ELECTRIC INSULATION CLASS
INTERNATIONAL PROTECTION
WARRANTY

4. INSTALLATION

UNPACKING
• Open the carton being careful do not damage the appliance with sharp tools,
•gently pull up the stove out from the packing, beware the glass,
•remove all protections and packing materials before using the stove and make sure that you have removed
all the accessories inside: pump, lighter WP18, essence holder, feet, booklet instructions, elettrical tools, all of
the stickers and the internal packagings parts of the stove.
INSTALLATION
After unpacking the appliance, place it in a secure and stable place that has been awarded, making sure that
there is enough space for the preliminaries.
Make sure to place the stove in a right position to avoid possible impacts.
Be shore to leave the fan air intake grid always free.
The stove do not requires chimney, anyway the room must be ventilated for a few minutes each hour of use.
The stove must be installed in compliance with the following safety conditions:
-Keep a minimum distance on the sides, in front of an above of 50 cm and 10 cm on the back by an average
of flammable materials;
pag. 25 di 40
COMPACT
mm 486
mm 350
mm 820
litri 5
kg 36
kg 40
BIOETHANOL ECOFIRE
Kw 3,8
ore 25
LT/h 0,5
LT/h 0,2
kg SI
W 60
V~ 220
Hz 50
1
IP 20
2 years
