Coopersmith 4-piece deep seating set
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Item # 1001 129 744
1001 196 501
Model # FZS80406-ST
FZS80406-STN
USE AND CARE GUIDE
COOPERSMITH 4-PIECE DEEP SEATING SET
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service.
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HOMEDEPOT.CA
THANK YOU
y through the purchase of this set. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FZS80406-ST and is the answer not in the manual?

Questions and answers

Related Manuals for HAMPTON BAY FZS80406-ST

Summary of Contents for HAMPTON BAY FZS80406-ST

  • Page 1 We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs. Thank you for choosing Hampton Bay!

  • Page 2: Table Of Contents

    Table of Contents Table of Contents ............2 Pre-Assembly ..............3 Planning Assembly ..............3 Important Safety Instructions ........2 Hardware Included ..............3 Save These Instructions ............2 Club Chair Package Contents............4 Read All Instructions Before Use ..........2 Loveseat Package Contents............5 Warranty ................

  • Page 3: Warranty

    Warranty 2 YEAR FRAME AND 2 YEAR FABRIC LIMITED WARRANTY WHAT IS COVERED We warrant the frames to be free of manufacturing defects to the original purchaser for two years, and a two year limited warranty for the fabric. WHAT IS NOT COVERED It remains the customer’s responsibility for freight and packaging charges to and from our service center.

  • Page 4: Club Chair Package Contents

    Pre-Assembly (continued) CLUB CHAIR PACKAGE CONTENTS Part Description Quantity Wrench Right arm Left arm Club chair backrest Club chair seat Back cushion Seat cushion...

  • Page 5: Loveseat Package Contents

    Pre-Assembly (continued) LOVESEAT PACKAGE CONTENTS Part Description Quantity Wrench Right arm Left arm Loveseat seat Loveseat backrest Back cushion Seat cushion Pillow HOMEDEPOT.CA Please contact 1-855-HD-HAMPTON for further assistance.
  • Page 6 Pre-Assembly (continued) TABLE PACKAGE CONTENTS Part Description Quantity Wrench Table top Leg connector Table leg...

  • Page 7: Club Chair Assembly

    Club Chair Assembly ATTACHING THE CLUB CHAIR SEAT TO THE CLUB CHAIR BACKREST Place the club chair backrest (C) on a soft surface. Attach the club chair seat (D) to the club chair backrest (C) using M6x15 combination bolts (AA), as shown below. Do not fully tighten the bolts at this step.
  • Page 8 Club Chair Assembly (continued) ATTACHING THE ARMS TO THE CLUB CHAIR SEAT Attach the right arm (A) and the left arm (B) to the club chair seat (D) using M6x15 combination bolts (AA). Do not fully tighten the bolts at this step. Loosely tighten all the bolts using the NOTE: hex wrench (CC).
  • Page 9 Club Chair Assembly (continued) ATTACHING THE ARMS TO THE CLUB CHAIR BACKREST Turn the chair right side up. Attach the right arm (A) and the left arm (B) to the club chair backrest (C) using M6x15 combination bolts (AA). Do not fully tighten the bolts at this step. Loosely tighten all the bolts using the NOTE: hex wrench (CC).
  • Page 10 Club Chair Assembly (continued) TIGHTENING THE BOLTS Once all of the bolts are in place, fully tighten the bolts. Ensure all connections are secure before use.

  • Page 11: Loveseat Assembly

    Loveseat Assembly ATTACHING THE LOVESEAT SEAT TO THE LOVESEAT BACKREST Place the loveseat backrest (H) on a soft surface. Attach the loveseat seat (G) to the loveseat backrest (H) using M6x15 combination bolts (AA), as shown below. Do not fully tighten the bolts at this step. Loosely tighten all the bolts using the NOTE: hex wrench (CC).
  • Page 12 Loveseat Assembly (continued) ATTACHING THE ARMS TO THE LOVESEAT SEAT Attach the right arm (A) and the left arm (B) to the loveseat seat (G) using M6x15 combination bolts (AA), as shown below. Do not fully tighten the bolts at this step. Loosely tighten all the bolts using the NOTE: hex wrench (CC).
  • Page 13 Loveseat Assembly (continued) ATTACHING THE ARMS TO THE LOVESEAT BACKREST Turn the loveseat right side up. Attach the right arm (A) and the left arm (B) to the loveseat backrest (H) using M6x15 combination bolts (AA), as shown below. Do not fully tighten the bolts at this step. Loosely tighten all the bolts using the NOTE: hex wrench (CC).
  • Page 14 Loveseat Assembly (continued) TIGHTENING THE BOLTS Once all of the bolts are in place, fully tighten the bolts. Place the seat cushions (F) ,the back cushions (E) and the pillows (I) to finish the assembly of the loveseat. Ensure all connections are secure before use.
  • Page 15 Table Assembly ATTACHING THE TABLE LEGS TO THE TABLE TOP Place the table top (J) upside down on a soft surface. Attach the table legs (L) to the table top (J) using M6x15 combination bolts (AA). Do not fully tighten the bolts at this step. Loosely tighten all the bolts using the NOTE: hex wrench (CC).
  • Page 16 Table Assembly (continued) ATTACHING THE LEG CONNECTOR TO THE TABLE LEGS Attach the leg connector (K) to the table legs (L) using M6x30 combination bolts (BB). Do not fully tighten the bolts at this step. Loosely tighten all the bolts using the NOTE: hex wrench (CC).

  • Page 17: Care And Cleaning

    Table Assembly (continued) Table Assembly (continued) CHECKING THE TABLE Once all of the bolts are in place, fully tighten the bolts. Turn the table right side up. Ensure all connections are secure before use. Care and Cleaning For best results, clean the frame and fabric with a damp cloth and dry thoroughly. This will help prevent mildew by removing dirt particles that may accumulate.
  • Page 18 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service. 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday 1-855-HD-HAMPTON HOMEDEPOT.CA Retain this manual for future use. Factory club chair ID # FZS80406A...
