Ellington Collection
Spring Chair
style # FSS60639R
sku # 2721067
>>assembly instructions

Advertisement

loading
Need help?

Need help?

Do you have a question about the Ellington FSS60639R and is the answer not in the manual?

Questions and answers

Summary of Contents for Backyard Creations Ellington FSS60639R

  • Page 1 Ellington Collection Spring Chair style # FSS60639R sku # 2721067 >>assembly instructions...
  • Page 2: Before You Begin

    IMPORTANT WARNING: Unpack the box on a clean soft level surface and make sure all parts have been included. If you have any questions or concerns, please visit our website at: www.yotrioint.com or toll free at: 1-866-905-4107 Monday-Friday 8:30 am to 5:00 am pacific standard time / 11:30 am to 8:00 pm eastern standard time. or email us at: customerservice@yotrious.com ATTENTION: This Chair is not intended for use during any kind of inclement weather and the manufacturer is not...
  • Page 3 table of contents introduction hardware parts list assembly QUESTIONS? Please call 1-866-905-4107 parts and service. For faster service, have the style nember and SKU number ready when calling.
  • Page 4 hardware (Part E)×4 (Part F)×8 (Part G)×4 (Part H)×1 allen wrench M6*45mm bolt with washer M6*20mm bolt with washer M6*25mm bolt ATTENTION: THE HARDWARE KIT IS FOR 2 CHAIRS...
  • Page 5: Description Quantity

    ITEM DESCRIPTION QUANTITY leg 1 leg 2 chair frame connect bar...
  • Page 6 step 01: (Part E)×1 (Part F)×2 M6*45mm bolt with washer M6*20mm bolt with washer (Part H)×1 allen wrench ATTENTION: To avoid damage to your new patio furniture, please use either the carton or another soft surface such as carpet as a working surface to prevent product damage during assembly.
  • Page 7 step 02: (Part E)×1 (Part F)×2 M6*45mm bolt with washer M6*20mm bolt with washer (Part H)×1 allen wrench 1. Attach the chair frame (C) to the leg2 (B) by lining up the bolt holes. 2. Secure with M6*45mm bolt with washer (E) and M6*20mm bolt with washer (F) using allen wrench (H).
  • Page 8 step 03 (Part H)×1 (Part G)×2 M6*25mm bolt allen wrench Turn the chair to upright position onto a flat level surface. 2. Fasten the connect bar (D), leg1 (A) and leg2 (B) by using M6*25mm bolt (G). Do not completely tighten screws until all screws are in place.
  • Page 9 step 04 1. Tighten all the bolts. 2. Put the seat cushion and back cushion on the chair. You are now ready to enjoy your new spring chair.
