EXPLODED VIEW

14
Battery
Connector
Description
1 FAN GUARD
2 COOLING FAN
3 HANDLE ASSEMBLY
4 GAS CONTROL VALVE
5 POWER ADAPTER
6 HIGH LIMIT THERMAL SWITCH
7 SPARK PLUG
8 THERMOCOUPLE ASSEMBLY
9 PCB
POWER SWITCH
11 SPARK MODULE
OUTPUT CONTROL KNOB
BASE COVER
HOSE AND REGULATOR
WHILE CONNECTED TO A POWER SOURCE
6
3
11
12

PARTS LIST

12 Propane Forced Air Heater User's Manual
8
7
2
4
10
1
9
5
13
MH-60VBOA-GFA
ASM-00135
EL-00015
ASM-00026
EL-00036
GC-00075
01.04.71.015010129
ASM-00042
ASM-00053
EL-00048
EL-00052
EL-00054
GC-00087
GC-00017
GC-00527
