- Page 1 STBR500 & A s s e m b l y I n s t r u c t i o n s O W N E R ’ S M A N U A L V. STBR500-20190705...
- Page 2 W a r n i n g , S a f e t y & M a i n t e n a n c e ...
-
Page 3: Table Of Contents
T a b l e o f C o n t e n t s • SAFETY INSTRUCTIONS......PAGE 4 • PREPARATION..........PAGE 5 • HARDWARE ILLUSTRATION......PAGE 6 • PART / HARDWARE LIST....... PAGE 9 • ASSEMBLY INSTRUCTIONS......PAGE 10 • EXPLODED VIEW.......... -
Page 4: Safety Instructions
I m p o r t a n t S a f e t y I n s t r u c t i o n s Before beginning any fitness program, you should obtain a complete physical examination from your physician. Il est conseille de subir un examen medical complet avant d’entreprendre tout programme d’exercise. Si vous avez des etourdissements ou des faiblesses, arretez les exercices immediatement. -
Page 5: Preparation
P r e p a r a t i o n Thank you for purchasing the STBR500. This Product is part of the Body-Solid line of quality strength training machines, which lets you target specific muscle groups to achieve better muscle tone and overall body conditioning. To maximize your use of the equipment please study this Owner’s Manual thoroughly. Required Tools Assembly Tips The basic tools that you must obtain before assembling Read all “Notes” on each page before beginning each the STBR500 include but are not limited to: step. While you may be able to assemble the STBR500 using the illustrations only, important safety notes and other m Standard Wrench Set tips are included in the text. m Metric Wrench Set Some pieces may have extra holes that you will not use. -
Page 6: Hardware Illustration
S T B R 5 0 0 H a r d w a r e I l l u s t r a t i o n Part #1 HEX HEAD BOLT M12x45mm QTY. - Page 7 S T B R 5 0 0 H a r d w a r e I l l u s t r a t i o n Part #6 SOCKET HEAD CAP SCREW M10x25mm QTY.
- Page 8 S T B R 5 0 0 H a r d w a r e I l l u s t r a t i o n Part #11 NYLON LOCK NUT M12 QTY.
-
Page 9: Part / Hardware List
S T B R 5 0 0 P a r t s & H a r d w a r e L i s t Part# Description FRONT CENTER FRAME MIDDLE CENTER FRAME REAR CENTER FRAME SIDE FRAME FOOT PLATE PIVOT ARM MOUNTING BRACKET WEIGHT HORN FRAME... -
Page 10: Assembly Instructions
S T E P Be careful to assemble all components in the sequence they are presented. NOTE: Wrench tighten ALL hardware at the end of STEP 1D. Some components may be pre-assembled. Nylon lock nuts will not fully screw onto bolts, they must be wrench tighten to fully go on. - Page 11 S T E P Above shows Step 1 assembled and completed.
- Page 12 S T E P Be careful to assemble all components in the sequence they are presented. NOTE: Wrench tighten ALL hardware at the end of STEP 2A. Some components may be pre-assembled. Nylon lock nuts will not fully screw onto bolts, they must be wrench tighten to fully go on.
- Page 13 S T E P Above shows Step 2 assembled and completed. Note #2...
- Page 14 S T E P Be careful to assemble all components in the sequence they are presented. NOTE: Wrench tighten ALL hardware at the end of STEP 3C. Some components may be pre-assembled. Nylon lock nuts will not fully screw onto bolts, they must be wrench tighten to fully go on.
- Page 15 S T E P Above shows Step 3 assembled and completed.
- Page 16 N o t e s...
-
Page 17: Exploded View
S T B R 5 0 0 E x p l o d e d V i e w... -
Page 18: Contact Page
STBR500 PLEASE WRITE YOUR SERIAL NUMBER IN THE BOXES BELOW 015197-��-��-����-���� S/N # 1900 S. Des Plaines Ave. Forest Park, IL 60130 Phone:(708)427-3555 Fax:(708)427-3556 Hours: M-F 8:30 - 5:00 CST www.bodysolid.com Copyright 2009. Body-Solid. All rights reserved. Body-Solid reserves the right to change design and specifications when we feel it will improve the product. Body-Solid machines maintain several patented and patent pending features and designs.
