SYSTEM DESIGN
NEMA motor ratings
All ratings are calculated at altitude of 1000 metres and ambient temperature of
50 ºC.
300%, 10 s,
6 starts per hour
A
@240
EMX4e-0024B 24
EMX4e-0042B 42
EMX4e-0052B 52
EMX4e-0064B 64
EMX4e-0069B 69
EMX4e-0105B 100
EMX4e-0115B 115
EMX4e-0135B 135
EMX4e-0184B 164
EMX4e-0200B 200
EMX4e-0229B 229
EMX4e-0250B 250
EMX4e-0352B 341
EMX4e-0397B 389
EMX4e-0410B 410
EMX4e-0550B 550
EMX4e-0580B 580
EMX4e User Manual (710-18433-00C)
10 |
Light
HP HP HP A
@480 @600
VAC VAC VAC
7.5 15 20 17
15 30 40 28
15 30 50 35
20 40 60 52
25 50 60 59
30 75 100 77
40 75 100 81
50 100 125 99
60 125 150 124
75 150 200 131
75 150 200 156
100 200 250 195
125 250 350 240
150 300 400 261
150 300 450 377
200 450 500 414
200 500 500 477
Normal
350%, 30 s,
4 starts per hour
HP HP HP
@240 @480 @600
VAC VAC VAC
5 10 15
10 20 25
10 25 30
15 40 40
20 40 50
25 60 60
30 60 75
30 75 100
40 100 100
50 100 125
60 125 150
75 150 200
75 200 200
100 200 250
150 300 350
150 350 450
200 400 500
Heavy
450%, 30 s,
4 starts per hour
A HP HP HP
@240 @480 @600
VAC VAC VAC
14 3 10 10
22 7.5 15 20
28 10 20 25
40 10 25 30
46 15 30 40
52 15 40 50
65 20 50 60
77 25 60 75
96 30 75 75
104 40 75 100
124 40 100 100
156 60 125 150
180 60 150 150
203 75 150 200
302 100 250 300
321 125 250 300
361 150 300 350
