W41Pc And W41Usb - Wavecom W40PC Manual

Input
Connector
Frequency range
Bandwidth
Frequency raster DDS
Signal level
Input impedance

W41PC and W41USB

Input
Connector
Frequency range
Bandwidth
Frequency raster DDS
Signal level
Input impedance
Note:
The W41PC MK-II hardware utilizes four signal inputs, i.e. an EXT-DEM (EXTernal
DEModulator) input is additionally available.
Input
Connector
Signal level
Input impedance
Remarks
WAVECOM Decoders v6.15 W40PC, W41PC, W51PC
AF HF
BNC female
0.6 kHz to 20 kHz for
HF-signals
0.6 kHz to 24 kHz for
VHF/UHF-signals
4 kHz for HF-signals
24 kHz for VHF/UHF-
signals
1.0 Hz
5 mVrms to 2.5 Vrms
> 10.0 kOhm
AF HF
BNC female
0.6 kHz to 20 kHz for
HF-signals
0.6 kHz to 24 kHz for
VHF/UHF-signals
4 kHz for HF-signals
24 kHz for VHF/UHF-
signals
1.0 Hz
1 mVrms to 2 Vrms
> 10.0 kOhm
EXT-DEM
BNC female
TTL up to RS-232C
[0 V, +5 V] to [-12 V, +12 V]
>100 kOhm
Max. 12 kBit/s
V1 Data
Internal Synchronization
DIS
BNC female BNC female
14 kHz to 1.5 MHz 0 to 20 kHz
4 kHz for HF-signals 4 kHz for HF-signals
24 kHz for VHF/UHF- 24 kHz for VHF/UHF-
signals signals
1.0 Hz 1.0 Hz
1 mVrms to 0.5 Vrms 1 mVrms to 0.5 Vrms
> 1.5 kOhm > 1.5 kOhm
IF
BNC female BNC female
14 kHz to 1.5 MHz 10.685 MHz to 10.715
MHz
(or 21.385 MHz to
21.415 MHz)
4 kHz for HF-signals 4 kHz for HF-signals
24 kHz for VHF/UHF- 24 kHz for VHF/UHF-
signals signals
1.0 Hz 1.0 Hz
1 mVrms to 0.5 Vrms 1 mVrms to 0.5 Vrms
> 1.5 kOhm > 50 Ohm
Technical Data • 201
