SEC/SH/04/21/DV1 2988 LUDLOW 1+4 DINING TABLE ASSEMBLY INSTRUCTIONS IMPORTANT PLEASE READ BEFORE YOU CONTINUE FURTHER FOR DOMESTIC USE ONLY CARE AND MAINTENANCE After unpacking this product please keep the original packaging in case it needs to be returned for any reason.
SEC/SH/04/21/DV1 * Use of power tools to assemble this product will invalidate * Please check contents and read the instructions before commencing assembly. any claim and damage this product making it unsafe !!! * Assemble this product following the enclosed instructions carefully. * Please assemble on a clean soft surface to avoid damage.
SEC/SH/04/21/DV1 FITTINGS FITTINGS GLUE 4 x 35mm 7 x 70mm 7 x 90mm TOOLS REQUIRED Page 03...
Page 4
SEC/SH/04/21/DV1 STEP 1 7,0 x 90mm Glue must be added PARTS REQUIRED to Parts 02,03 and 05. 02 - TABLE LEG 7,0 x 70mm 03 - TABLE LEG 05 - LONG FRAME SIDE HARDWARE REQUIRED GLUE TOOLS REQUIRED STEP 2 STEP 2 Glue must be added 7,0 x 90mm...
Page 5
SEC/SH/04/21/DV1 STEP 3 Glue must be added 7,0 x 90mm PARTS REQUIRED to parts 04. 04 - SHORT FRAME SIDE 7,0 x 70mm HARDWARE REQUIRED GLUE TOOLS REQUIRED STEP 2 STEP 4 FOR YOUR FUTURE REFERENCE ORDER NUMBER PARTS REQUIRED SHOULD BE HERE 01 - TABLE TOP...
SEC/SH/04/21/DV1 2988 LUDLOW DINING CHAIR 1+4 ASSEMBLY INSTRUCTIONS IMPORTANT FOR DOMESTIC USE ONLY PLEASE READ BEFORE YOU CONTINUE FURTHER CARE AND MAINTENANCE After unpacking this product please keep the original packaging in case it needs to be returned for any reason. •Please ensure allfittings and parts are present before commencing with assembly.
Page 8
SEC/SH/04/21/DV1 02 02 * Use of power tools to assemble this product will invalidate * Please check contents and read the instructions before commencing assembly. any claim and damage this product making it unsafe !!! * Assemble this product following the enclosed instructions carefully. * Please assemble on a clean soft surface to avoid damage.
Page 9
SEC/SH/04/21/DV1 FITTINGS FITTINGS GLUE 7 x 70mm 4 x 35mm 7 x 60mm TOOLS REQUIRED Page 03...
Page 10
SEC/SH/04/21/DV1 STEP 1 Glue must be added 7,0 x 70mm to Parts 01,06 and 08. PARTS REQUIRED 01 - RIGHT/LEFT BACK CHAIR 7,0 x 60mm 06 - FRONT LEG RIGHT/LEFT 07 - SIDE SEAT RAIL The bolt hole on 08 - STRETCHER parts 07 should be at the bottom...
Page 11
SEC/SH/04/21/DV1 STEP 3 Glue must be added 7,0 x 70mm to Parts 01,06 and 08. PARTS REQUIRED 01 - RIGHT/LEFT BACK CHAIR 7,0 x 60mm 06 - FRONT LEG RIGHT/LEFT 07 - SIDE SEAT RAIL The bolt hole on 08 - STRETCHER parts 07 should be at the bottom...
SEC/SH/04/21/DV1 STEP 5 PARTS REQUIRED 03 - SEAT PAD HARDWARE REQUIRED TOOLS REQUIRED CENTRALIZE STEP 2 STEP 6 IMPORTANT NOTICE PARTS REQUIRED HARDWARE REQUIRED TOOLS REQUIRED Please allow at least 6 hours for the glue to dry before using your new chairs.
