LISBON MINI SHOE RACK / STORAGE SEAT
ASSEMBLY INSTRUCTIONS
DO NOT
USE
PLEASE READ BEFORE YOU CONTINUE FURTHER
THE PRODUCT YOU HAVE PURCHASED WILL GIVE YOU MANY YEARS OF
SERVICE IF YOU FOLLOW THE GUIDELINES FOR ITS SAFE ASSEMBLY AND
PERIODIC MAINTENANCE AND CLEANING.
ASSEMBLE ON A SOFT CLEAN SURFACE.
DO NOT USE ANY TOOLS OTHER THAN THOSE SHOWN.
ANY SPANNERS OR ALLEN KEYS REQUIRED ARE INCLUDED WITH THE
FITTINGS KIT.
DO NOT FOR ANY REASON USE A POWER TOOL TO ASSEMBLE THIS
PRODUCT. ITS USE WILL INVALIDATE ANY CLAIM YOU MAY HAVE AND
COULD MAKE THIS PRODUCT UNSAFE.
DEPENDING ON THE AMOUNT OF USE THIS PRODUCT RECEIVES IT MAY BE
NECESSARY TO TIGHTEN UP THE FIXINGS FROM TIME TO TIME. THIS IS
COMPLETELY NORMAL FOR ANY FLAT PACK FURNITURE.
DO NOT OVERTIGHTEN FIXING.
FOR CLEANING, YOU MAY USE A DAMP CLOTH (NOT WET)
DO NOT USE POLISH, DETERGENT OR CHEMICAL CLEANERS.
THE SURFACE OF THIS ITEM IS NOT HEAT RESISTANT. ALWAYS USE A
PLACE MAT UNDER HOT OR COLD ITEMS TO PREVENT MARKING.
FOR DOMESTIC USE ONLY
IMPORTANT
SEC/SH/05/19/EU1
PAGE 1
Advertisement
Related Manuals for Seconique LISBON 100-120-018
Summary of Contents for Seconique LISBON 100-120-018
- Page 1 SEC/SH/05/19/EU1 LISBON MINI SHOE RACK / STORAGE SEAT ASSEMBLY INSTRUCTIONS DO NOT FOR DOMESTIC USE ONLY IMPORTANT PLEASE READ BEFORE YOU CONTINUE FURTHER THE PRODUCT YOU HAVE PURCHASED WILL GIVE YOU MANY YEARS OF SERVICE IF YOU FOLLOW THE GUIDELINES FOR ITS SAFE ASSEMBLY AND PERIODIC MAINTENANCE AND CLEANING.
- Page 2 SEC/SH/05/19/EU1 (SCREWDRIVER NOT PROVIDED) USE A FLAT HEAD SCREWDRIVER TO TIGHTEN THE CAM NUTS. A QUARTER TURN CLOCKWISE IS ALL THAT IS NEEDED. STEP 1 - PUSH CAM BOLT INTO INSERT STEP 2 - ALIGN THE CAM BOLT WITH THE HOLE AND PUSH TOGETHER UNTIL FLUSH. ( MAKE SURE THE ARROW OF THE CAM LOCK IS POINTING TOWARD THE EDGE OF THE PANEL.) STEP 3 - THE HEAD OF THE BOLT GOES INTO THE WIDE MOUTH OF THE CAM LOCK.
-
Page 3: Part List
SEC/SH/05/19/EU1 PART LIST PART LIST SMALL CENTRE PANEL PLEASE CHECK THAT YOU HAVE ALL THE PARTS LISTED BEFORE YOU START ASSEMBLING. IF YOU DO FIND THAT SOMETHING IS MISSING, DO NOT CONTINUE ASSEMBLY, PLEASE CONTACT MIDDLE PANEL YOUR SUPPLIER IMMEDIATELY. LARGE CENTRE PANEL BOTTOM PANEL BACK PANEL... -
Page 4: Hardware List
SEC/SH/05/19/EU1 HARDWARE LIST DOWEL 6x30MM 34 PCS SCREW M4x38MM 4 PCS BOLT M7x60MM 2 PCS SCREW M3.5x12MM 8 PCS PART (K) HAS A LEFT AND RIGHT SIDE PANEL BOLT M6x50MM 14 PCS PVC FOOT CENTRE 6 PCS HANDLE 2 PCS ALLEN KEY 1 PC CAM BOLT+CAM NUT... - Page 5 SEC/SH/05/19/EU1 STEP 1 STEP 2 HARDWARE NEEDED: HARDWARE NEEDED: 8PCS 8PCS 4PCS 2PCS 2PCS 2PCS Upper Second Hole Centre Hole BACK First Hole MAKE SURE THE Last Second Hole ARROW ON THE CAM FRONT LOCK IS POINTING SCREWS MUST BE INSERTED MAKE SURE THE TOWARD THE HOLE IN THE FIRST HOLE ON THE...
-
Page 6: Hardware Needed
SEC/SH/05/19/EU1 STEP 3 STEP 4 HARDWARE NEEDED: HARDWARE NEEDED: 4PCS 2PCS 2PCS 2PCS 2PCS STEP 3.1 STEP 4.1 STEP 3.2 THE USE OF POWER TOOLS TO ASSEMBLE THIS PRODUCT WILL INVALIDATE CAUTION : ANY CLAIM AND MAY DAMAGE THIS PRODUCT MAKING IT UNSAFE. PAGE 6... - Page 7 SEC/SH/05/19/EU1 STEP 5 STEP 6 HARDWARE NEEDED: HARDWARE NEEDED: 8PCS 2PCS 4PCS 2PCS 2PCS USE ANY PROVIDED PART TO SUPPORT PANEL 8 MAKE SURE THE ARROW ON THE CAM LOCK IS POINTING STEP 5.1 STEP 6.1 TOWARD THE HOLE ON THE EDGE OF THE PANEL.
- Page 8 SEC/SH/05/19/EU1 STEP 7 STEP 8 HARDWARE NEEDED: HARDWARE NEEDED: 4PCS 7PCS STEP 7.1 STEP 8.1 6&7 THE USE OF POWER TOOLS TO ASSEMBLE THIS PRODUCT WILL INVALIDATE CAUTION : ANY CLAIM AND MAY DAMAGE THIS PRODUCT MAKING IT UNSAFE. PAGE 8...
- Page 9 SEC/SH/05/19/EU1 STEP 9 STEP 10 HARDWARE NEEDED: HARDWARE NEEDED: 6PCS 5PCS 6PCS 18PCS STEP 9.1 STEP 10.1 THE USE OF POWER TOOLS TO ASSEMBLE THIS PRODUCT WILL INVALIDATE CAUTION : ANY CLAIM AND MAY DAMAGE THIS PRODUCT MAKING IT UNSAFE. PAGE 9...
- Page 10 SEC/SH/05/19/EU1 STEP 11 STEP 11.2 HARDWARE NEEDED: 4PCS 2SETS 2PCS 14PCS 1SETS ARROW ON LOCKING NUT MUST POINT TOWARDS HOLE IN EDGE OF PANEL STEP 11.4 STEP 11.3 16&17 STEP 11.1 16&17 STEP 11.5 THE USE OF POWER TOOLS TO ASSEMBLE THIS PRODUCT WILL INVALIDATE CAUTION : ANY CLAIM AND MAY DAMAGE THIS PRODUCT MAKING IT UNSAFE.
- Page 11 SEC/SH/05/19/EU1 STEP 12 STEP 12.2 HARDWARE NEEDED: 2PCS 6PCS 4PCS FINISHED FRONT EDGE 2PCS 4PCS STEP 12.4 LAST THIRD HOLE CENTRE HOLE STEP 12.1 STEP 12.3 THIRDHOLE THE USE OF POWER TOOLS TO ASSEMBLE THIS PRODUCT WILL INVALIDATE CAUTION : ANY CLAIM AND MAY DAMAGE THIS PRODUCT MAKING IT UNSAFE.
- Page 12 SEC/SH/05/19/EU1 STEP 13 STEP 13.2 HARDWARE NEEDED: 2PCS 2PCS 2PCS STEP 13.1 STEP 13.3 THE USE OF POWER TOOLS TO ASSEMBLE THIS PRODUCT WILL INVALIDATE CAUTION : ANY CLAIM AND MAY DAMAGE THIS PRODUCT MAKING IT UNSAFE. PAGE 12...
