OSD control pad

The on-screen display (OSD) control pad (see Figure 1) lets you manually control
the camera functions. Table 1 below lists the OSD control pad functions and
describes their use.
Table 1 Using the OSD control pad
Pad direction
Up
Left
Right
Down
Enter
4
Description
Moves the cursor upward to select an item
Moves the cursor left to select or adjust the parameters of the selected
item.
Moves the cursor to the right to select or adjust the parameters of the
selected item.
Moves the cursor downward to select an item.
Press the center of the control pad to display the Main menu. If the
selected item has its own menu, press the pad to enter a submenu.
