Requirements for the Operators ..........................8 Accident Prevention ..............................9 General Safety Regulations ............................. 9 Machine Description ............................... 9 About the BSB 400 - 900 Series ..........................10 Standard Equipment ............................. 10 Available Accessories ............................10 Safety ................................11 Basic Safety Instructions ............................11 4.1.1...
Page 3
Installing the Machine............................22 Temporary Storage ............................... 22 Lashing on a Transport Vehicle ..........................22 6.6.1 Lashing Models BSB 400 / 500 / 600 ......................23 6.6.2 Lashing Models BSB 700 / 800 / 900 ......................23 Connecting the Extraction Unit ..........................24 Electrical Connections ............................
Introduction This operating manual covers all bandsaw machines of the BSB 400 to 900 series. The purpose of this document is to acquaint the user with the machine and en- able him to use it to the full extent of its intended capabilities.
Symbols in Safety Instructions Symbol Safety Instruction General danger symbol, which requires the highest attention! Failure to observe may result in damage to the equipment, serious injury or even death. Warning of possible danger from forklift traffic! Non-observance may result in life-threatening injuries. Warning indicates a possible hazard under suspended loads! Non-observance may result in life-threatening injuries.
General This Bandsaw machine was produced by HOKUBEMA Maschinenbau GmbH according to the current state of the art and placed on the market as a complete machine. All legal and normative regulations were observed. Structure of the Machine • Wheel diameter, cutting height, cutting width and blade speed vary depending on the model. The exact values for your machine can be found in the section ...
3.6 Machine Description The bandsaws of the PANHANS BSB 400 - 900 series are modern and spacious bandsaws suitable for cutting (cross-cutting and splitting) wood and similar materials. The tool is a toothed steel band to which the cutting movement is transmitted by two band rollers.
Blade tension indicator with viewing window for setting the recommended tension • Upper and lower precision bandsaw guide APA 2, size 1 (BSB 400/500) and size 2 (BSB 600 - 900) • Mechanical height adjustment of saw blade guard by hand wheel with locking pinion •...
4.1.1 Application Area and Intended Use The bandsaws BSB 400 - 900 are designed exclusively for cutting (coping and splitting) ma- terials for which the respective bandsaw blade used is suitable (e.g. wood or other materi- als with the same physical and technical properties).
4.1.4 Residual Risks The machine is built according to the latest state of the art and the recognised safety rules. Nevertheless, the use of the machine may cause danger to life and limb of the user or third parties or damage to the machine and other equipment.
The emergency stop buttons must always be freely accessible. They must not be moved, e.g. with hopper boxes. Check the function of the emergency stop buttons daily (before starting work). Laser warning: The machine can be optionally equipped with a laser cut position indicator. Looking directly into the laser beam will cause serious eye injury! Fire hazard due to wood dust in connection with flying sparks and/or open fire! 4.1.5 Observe the Environmental Protection Regulations...
4.1.7 Personnel Selection and Qualification - Basic Duties The machine design and operation is intended for right-handers. Work on and with the machine may only be carried out by reliable personnel. Observe the legal minimum age! Only use trained or instructed personnel. Clearly define the responsibilities of the personnel for operating, setting up, maintaining and repairing! Ensure that only authorised personnel work on the machine! If personnel to be trained or apprenticed have to work on the machine, this may only be done under the...
Machine condition: Check the machine for externally visible damage and defects at least once per shift! Any changes that have occurred (including those in the operating behaviour) must be reported immedi- ately to the responsible office or person! If necessary, stop and secure the machine immediately! Extraction: The machine must be connected to an effective extraction system.
4.2.4 Safe Working Practices Whenever possible, a push stick or a comparable aid must be used to feed the workpiece. It is essential to avoid working with the hands near the saw blade. When cutting narrow workpieces, generally use a push stick. Use aids such as auxiliary fence and push handle for concealed cuts.
Danger Zones on the Bandsaw 4.3.1 Danger Zone Bandsaw Blade • The area 120 mm around the saw blade is a danger zone. • Make sure that your hands are at least 10 cm away from the saw blade. Danger Zone •...
BSB 500 BSB 600 BSB 700 BSB 800 BSB 900 Figure 5: Series BSB 400 - 900 Expandability: The machine is designed for the later expansion of op- tional accessories (see chapter 17) from the extensive Figure 4: Nameplate manufacturer's range.
The permissible workplace values can also vary from country to country. However, this information should enable the user to make a better assessment of hazard and risk. 5.4.2 Noise Emission Values Bandsaw Model Unit BSB 400 BSB 500 BSB 600 BSB 700 BSB 800...
Pre-Assembly 6.3.1 Pre-Assembly of Models BSB 400 - 700 The bandsaw models BSB 400 - BSB 700 are delivered completely assembled. Pre-assembly is not necessary. 6.3.2 Pre-Assembly of Models BSB 800 and 900 • For the models BSB 800 and BSB 900. the upper protective cover must still be fitted and fastened via the holes (B) with the three screws supplied.
Installing the Machine The machine must be placed level on the floor. To do this, level the machine with a spirit level using the 4 grub screws in the machine base. There are four additional holes at the bottom of the machine base, which can be used to secure the machine against tipping with screws.
• Additionally secure the machine against tipping over! Figure 10: Lashing models BSB 400 / 500 / 600 6.6.2 Lashing Models BSB 700 / 800 / 900 • For transport in a vehicle, the ma-...
On most models, 2 signal generator lines can be connected to the terminals of the contactor for automatic switching of the extraction system: Model Contactor Terminal Model Contactor Terminal BSB 400 unavailable BSB 700 163 + 164 of contactor K1 BSB 500* 1 + 2 of rotary cam switch S2...
Electrical Connections The connection must be carried out by an authorised electrician! The circuit diagrams are located behind the main control panel or (optionally) in the control cabinet. Please observe the specified nominal voltage 400 VAC / 50 Hz (3 phases / N / PE)! •...
Components and Controls Figure 15: Components and controls Pos. Description Pos. Description Terminal box (control cabinet optionally) APA bandsaw guide Control panel and emergency stop Adjusting wheel for saw blade tension Height adjustment lever for upper saw blade guide Indicator for saw blade tension Clamping wheel for height adjustment lever (3a) Wheel for upper wheel inclination Fence...
Commissioning Read the operating manual and the chapter 4 “Safety” carefully before commissioning and observe them. Before switching on, check that • the floor around the machine is clean and free of interfering parts and workpieces, • there are no loose parts on the machine table and all tools have been removed, •...
8.1.2.1 3.0 - 7.5 kW Models with Push-Switch Unit (Option) • Check saw blade tension (tighten if necessary). • Make sure that there are no objects on the machine, the doors are closed and the safety switches (refer to section 9.2) are locked. •...
8.1.4 Switching on with Variable Sawblade Speed Control (Option) • Check saw blade tension (tighten if necessary). • Make sure that there are no objects on the machine, the doors are closed and the safety switches (refer to section 9.2) are locked. •...
↺ until the grub screw (G) disappears completely into the knurled nut again. → Only then can the machine be started again. Figure 24: Safety switch - door locked The version BSB 400 has only one safety switch that secures both doors simultaneously. BA_PH_BSB-400-900_EN_44-21.docx...
Inserting and Tensioning a Bandsaw Blade To ensure safe working without incidents, the bandsaw blade must be placed and adjusted properly. For wide blades, at least two persons are required for this purpose. Caution: Danger of cutting! Put on protective gloves when changing the bandsaw blade! •...
Note: Optionally, a table swivelling device is available, which can be adjusted via a hand crank (for more details see section 13.3). Figure 28: Adjust table inclination The model BSB 400 has a handwheel instead of the 3-arm lever. BA_PH_BSB-400-900_EN_44-21.docx...
APA 2 - Saw Blade Guides 9.7.1 Structure and Components The adjustment of the two saw blade guides is necessary when starting up the machine as well as when changing the bandsaw blade. The structure is identical for the upper and lower saw blade guide.
9.7.3 Basic Setting of the Back and Side Rollers (Overview) The two saw blade guides must be aligned with the saw blade as follows: • The Figure 31 shows on the far right the optimal setting of the back and side rollers. On the left and in the middle, it is shown which settings are wrong and must be avoided.
9.7.5 Saw Blade Guides - Troubleshooting Fault Possible Cause Remedy → Clean bearings and oil Insufficient or incorrect lubrication according to section 15.3. The side rollers or back rollers Incorrect basic adjustment of the guide → Check basic adjustment do not rotate (...
Using the Rip Fence The fence is inserted into the guide rail (F) on the side of the machine table and clamped in the desired position with the clamping wheel (K). The mechanical holding device (V) can be converted in a few easy steps so that the fence is also suitable for left-handers.
General Instructions for Use 12.1 Bandsaw Blades Bandsaw blades must be handled carefully so that they are not damaged. Untensioned bandsaw blades must be folded into a multiple circle without kinks and secured while not in use. They are to be kept stored in a safe and dry area.
Danger of cutting if the workpiece is tilted! The saw blade can tear and cause cutting injuries. Large and long workpieces For large or long workpieces, an appropriate table extension must be used, see Figure (A). Table extensions are available as an option (see ...
Instruction of the operators It is essential that all operators are regularly and adequately instructed in the use and adjustment of safety equip- ment such as guards, pushers, templates and table extensions. Push devices The push block including its handle or the push stick must be replaced if damaged. Generally •...
Optional Components The available optional components and accessories vary according to the bandsaw model. Please refer to the tables in chapter 17 to see which options and accessories are available for your machine. 13.1 Variable Sawblade Speed Control Bandsaws equipped with this option have a special control panel with an additional potentiometer for speed adjustment from approx.
13.4 Mitre Fence “Top” The mitre fence with round rod guide makes work easier when sawing angles and mitres. It can be folded down by 90° so that even flat workpieces (at the prescribed distance of max. 5 mm from the saw blade guard) can be processed safely.
13.8 Laser Cut Position Indicator (Option for BSB 600 - 900) As an option, the bandsaw models BSB 600 to BSB 900 can be equipped with a laser cut position indicator (laser class 1M). This provides optical support during cutting by projecting the cutting edge onto the workpiece. The workpiece can thus be optimally aligned before cutting in order to keep waste as low as possible.
Troubleshooting Proceed systematically when searching for the cause of a malfunction. If you are unable to find the fault or to remedy the malfunction, contact our customer service department (phone number: 0049 7571 / 755 - 0). Before you call us, please follow these steps: •...
Page 44
Troubleshooting - Continuation Fault Possible Cause Remedy → Replace saw blade Bad weld → Use a saw blade that is Too sharp edges at the tooth base suitable for the intended use → Readjust saw blade guide Saw blade guide badly adjusted, the according to section ...
To remove or install the ball bearings, use a suitable device (e.g. puller / mounting tube) to avoid damaging the bearings. Please refer to the following table for the ball bearing type suitable for your machine: Model Ball Bearing Type Model Ball Bearing Type BSB 400 6204 2RS BSB 700 6306 2RS BSB 500 6205 2RS...
If required, you can also contact our wheel repair service (phone: 0049 7571 / 755 - 0| email: service@hokubema-panhans.de). • The running surfaces must always be kept clean and free of incrustations.
15.7 Replacing the V-belt(s) Model V-belt Type eff. Length Quantity Model V-belt Type eff. Length Quantity BSB 400 SPZ 912 LP / SPZ 912 LW 912 mm BSB 700 13 1450 Li (A57) 1430 mm BSB 500 13 1100 Li (A43) 1130 mm...
15.8 Readjusting the Main Motor Brake (2.2 - 3.0 kW) Switch off the machine during maintenance and repair work and secure it against being switched on again unexpectedly! Lock the main switch with a padlock! If the machine does not come to a standstill within 10 sec- onds when braking, the motor brake must be readjusted.
Disassembly and Scrapping When dismantling and scrapping the machine, the current EU regulations or the respective regulations and laws of the country of operation, which are prescribed for proper dismantling and disposal, must be observed. The aim is to dismantle the machine and its various materials and components properly, to recycle all possible parts and to dispose of non-recyclable components in the most environmentally friendly way.
3300 mm 0.45 mm 1002 3783.15G 3300 mm 0.40 mm 1002 3783.10G 17.2 BSB 400 - Options & Accessories Article Description Art.-No. MOVING TROLLEY With 2 swivel castors with brakes and 2 fixed castors. 5270 FOLDABLE MITRE Only for column-left version.
17.7 BSB 700 - Bandsaw Blades Blade Length Width Thickness Span Width Quality Art.-No. 5140 mm 0.80 mm 1000 3780.35F 5140 mm 0.80 mm 1000 3780.30F 5140 mm 0.70 mm 1000 3780.25F 5140 mm 0.70 mm 1000 3780.20F 5140 mm 0.70 mm 1000 3780.15F...
17.9 BSB 800 - Bandsaw Blades Blade Length Width Thickness Span Width Quality Art.-No. 5775 mm 0.80 mm 1001 3781.40I 5775 mm 0.80 mm 1000 3780.35I 5775 mm 0.80 mm 1000 3780.30I 5775 mm 0.70 mm 1000 3780.25I 5775 mm 0.70 mm 1000 3780.20I...
17.11 BSB 900 - Bandsaw Blades Blade Length Width Thickness Span Width Quality Art.-No. 6260 mm 0.80 mm 1001 3781.40L 6260 mm 0.80 mm 1000 3780.35L 6260 mm 0.80 mm 1000 3780.30L 6260 mm 0.70 mm 1000 3780.25L 6260 mm 0.70 mm 1001 3781.20L...
