Summary of Contents for Sunjoy L-GZ120PST-9D
- Page 1 Assembly Instructions Item#: L-GZ120PST-9D 前四位销季2018， 后四位填工厂代码 Production Number:xxxxxxxx 0 / 11...
-
Page 2: Safety Information
Thank you for your purchase! We are pleased that you have chosen Sunjoy for your outdoor furniture purchase. Our clear, easy to follow, step by step instructions will guide you through the project from start to finish. Safety information •Keep all children and pets away from assembly area. Children and pets should be supervised when they are in the area of the production construction. - Page 3 Keep this manual for future reference. • Keep the original packaging to store the product. •Before beginning assembly of product, make sure all parts are present. Do not attempt to assemble the product if any parts are missing. •For technical assistance on assembly or replacement parts please call our customer service department at 1-866-578-6569 for help.
-
Page 4: Parts List
Parts List Description Part# Label Image Big screen GZ0120X9D01 Left screen GZ0120X9D02 Right screen GZ0120X9D03 Long Bar GZ0120X9D04 Short Bar GZ0120X9D05 Larger Roof Connector GZ0120X9D06 Top Roof Supporter GZ0120X9D07 Arch bar 1 GZ0120X9D08 Arch bar 2 GZ0120X9D09 Arch bar connector GZ0120X9D10 Side Supporting Bar-Short... -
Page 5: Hardware Pack
Hardware Pack 1 Image Description Part# Label M6x20 Bolt BM06020C M6 Flat washer UD06C M6 Wrench W10D Step1: Insert the left screen (B1) into the big screen (A1), pull it down to attach them, then use screw (AA), washer (CC) to secure left screen (B1) and big screen (A1). Do the same for right screen (C1) and big screen (A1). - Page 6 Hardware Pack 2 Image Description Part# Label M6x15 Bolt BM06015C M6 Flat washer UD06C Step2: Connect long bar (A2) and left screen (B1), long bar (A2) and right screen (C1) with bolt (BB) and washer (CC). Connect short bar (A5) and left screen (B1), short bar (A5) and right screen (C1) in the same way.
- Page 7 Hardware Pack 3 Image Description Part# Label M6 Flat washer UD06C M6x30 Bolt SM06030C M6x15 Bolt BM06015C M6 Nut LM06C Step3: Attach (F3) to Step4: Insert (B3) into center hook top roof supporter larger roof (A3). (A3). larger roof connector connector C3&C4 Step6: Insert arch bar 1(C3) and arch bar 2...
- Page 8 Step7: Insert arch bar connector (C5) into big screen (A1). 7 / 11...
- Page 9 D2 &D3 A2&A5 Step8: Insert side supporting bar-Short (D2) and Step9: Connect Side Supporting Bar (D3&D2) side supporting bar-Long (D3) into larger roof and bar (A2&A5) with bolt (FF), washer (CC) and connector (A3). nut (GG). Step10: Put Larger Canopy (G3) on to the top frame.
- Page 10 Hardware Pack 4 Description Part# Label Image Dia.6x180 stake DD06180C plastic ring R40U Step11: Attach Mosquito netting (A4) onto bar (A2, A5) with Plastic ring (EE). Step12: Secure the completely assembled gazebo by stake (DD). 9 / 11...
-
Page 11: Limited Warranty
Please do not return this product to the store. For technical assistance or replacement parts, please call Sunjoy Group at 1 (866) 578-6569 between 8:00 AM EST and 8:00 PM PST. You may fax your replacement parts form (which is included in the packaging) to 1 (740) 283-3549 or email to customer.care@sunjoygroup.com...
