NETWORK PAIRING -
1
Ensure the Hub and all CX Flex
or Freedom Micro II positions
are powered up. Once powered,
the staus light will illuminate (see
page 3 for LED Status Indicators).
Network
System Status stem Stat
Power Reset
4
Remove the IntelliKey (blue LED
will stay flashing on Hub for up to
15 minutes).
Network
System Status m Sta ta tat tat a a tu a
Power Reset
7
After connecting to the network,
the LED indicator will flash white
slowly if disarmed or solid white if
armed.
www.mtigs.com | T:800.426.6844
RFID ASSET PROTECTION
2
Plug Connect IntelliKey into
the USB port on the top of the
Hub. When the IntelliKey LED
lights green, it has been added
to the system whitelist. Remove
and repeat for all other Connect
IntelliKeys.
5
Activate user keys in the MTI
Connect web portal. This function
is only available to Managers or
higher level personnel.
8
Touch an activated user key to the
device. A double beep indicates
that the key will now control the
device.
MTI CONNECT™ HUB PRODUCT MANUAL
3
Plug in any Connect IntelliKey in
for 10 seconds. After 10 seconds,
the Hub status indicator will flash
blue, indicating the Hub is in
network pairing mode.
6
Touch the pairing card to the
RFID device. The LED indicator
will flash blue for up to 90
seconds.
9
