Zaxcom ZMT3-X

Group Code Set

REMOTE CONTROL
GROUP CODE = 1
This menu is where the ZMT3 -X is assigned to a group. The group code allows transmitters to be grouped
together so they can be controlled via ZaxNet without affecting others.
So for example a ZMT3 -X set to Group 1 will be controlled by a ZaxNet transmitter set to Group 1 and a
ZMT3-X assigned to group 2 will be controlled by a Group 2 ZaxNet transmitter. This is helpful if two or more
people on set are sending ZaxNet commands. Therefore the different group codes allow each person to be
independent and not interfere with each other. Most users leave the group set to 1 on all of their Zaxcom
products. Group codes can be set from 1 to 99.

Unit Code Set

REMOTE CONTROL
UNIT CODE = 001
This menu is where the ZMT3-X is assigned a unit code. The unit code is a unique number used to identify each
ZMT3-X within a particular group. This allows individual transmitters within the same group to be independently
controlled. Each transmitter should have a different unit code.
Unit codes can be assigned any number from 1 to 200.

ZaxNet Voting Enable

This menu will only appear if ZaxNet is set to receive (RX) mode
ZAXNET VOTING:
NORMAL (OFF)
The purpose of voting is to allow the ZaxNet receiver in the ZMT3-X to choose, and switch to, the stronger
signal from two different ZaxNet transmitters. One purpose of this is if on a large set a second IFB transmitter
can be placed at a different location so the ZaxNet receiver in the ZMT3-X can choose the stronger signal.
Please note that the second ZaxNet transmitting frequency must be set 2MHz higher than the first ZaxNet
transmitter.
15
ZaxNet Menu
