Programmable
Thermostat
Owner's Manual
Read and save these
instructions.
For help please visit
honeywellhome.com
Identify System Type
This thermostat is compatible with the following systems:
Gas, oil or electric furnace
Central air conditioner
Hot water system with or without pump
Millivolt system
Central heating and cooling system
Heat pump without auxiliary/backup heat
Heat pump with auxiliary/backup heat
RTH2510/
RTH2410
Set
Hold
Run
Heat Off Cool
Series
Fan
Fan
Heat Off Cool
Auto On
Auto On

Advertisement

Chapters

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RTH2510 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Honeywell Home RTH2510 Series

  • Page 1 RTH2510/ Programmable RTH2410 Series Thermostat Owner’s Manual Hold Read and save these instructions. For help please visit Heat Off Cool Auto On Heat Off Cool Auto On honeywellhome.com Identify System Type This thermostat is compatible with the following systems: Gas, oil or electric furnace •...
  • Page 2 CAUTION: MERCURY NOTICE If this product is replacing a control that contains mercury in a sealed tube, do not place the old control in the trash. Contact your local waste management authority for instructions regarding recycling and proper disposal. CAUTION: ELECTRONIC WASTE NOTICE N O M E R C U RY The product should not be disposed of with other household waste.
  • Page 3: Table Of Contents

    Table of Contents Installation Overriding Schedule Temporarily..14 Overriding Schedule Permanently ..14 Installation ............3 Compressor Protection ......15 Advanced Installation ........9 Early Start ............15 Change Filter ..........16 About Your New Thermostat Replace Batteries ........16 Controls and Home Screen Quick Reference .........
  • Page 4 2 Remove Old Thermostat Remove old thermostat but leave wallplate with wires attached. If you have an older thermostat with a sealed mercury tube, turn to page Do not remove wallplate yet 2 for proper disposal instructions. Terminal designation MCR33823 3 Label Wires with Tags Label the wires using the supplied wire labels as you disconnect them.
  • Page 5 5 Mount Wallplate Mount the new wallplate using the included screws and anchors. Used M32714 Drill 3/16-in. holes for drywall Drill 3/32-in. holes for plaster 6 Connect Wires Simply match wire labels. If labels do not match letters on the thermostat, check “Alternate Wiring (Conventional Systems)”...
  • Page 6 Alternate Wiring (Conventional Systems) If labels do not match letters on the thermostat, check the chart below and connect to terminal as shown here (see notes, below). M32726 If wires will be connected to both R and Rc terminals, remove metal jumper.
  • Page 7 Alternate wiring (for heat pumps with auxiliary or backup heat only) If labels do not match letters on the thermostat, check the chart below and connect to terminal as shown here (see notes, below). M32728 Leave metal jumper in place, connecting &...
  • Page 8 8 Set Fan Operation Switch Move the switch to the proper setting: RTHXXXX Gas or Oil: For gas or oil heating systems, leave the fan operation switch in this factory-set position (for systems that control the fan in a call for heat). GAS OR OIL ELECTRIC OR HEAT PUMP Electric or Heat Pump: Change the switch...
  • Page 9: Advanced Installation

    If Your System Type is... If your system type is: q Single Stage Heat and Cool q Heat Only or Cool Only Congratulations, you’re done! If your system type is: q Heat Pump* with Backup Heat Continue with Advanced Installation to match your thermostat to your system type.
  • Page 10: About Your New Thermostat

    NOTE: If you do not press any button for 60 seconds while you are in the setup menu, the thermostat automatically saves any changes made and exits the menu. Description Function Press the s or t button to Setting select system type 0 Heating &...
  • Page 11: Quick Reference

    Thermostat Controls Set: Press to Temperature adjustment set time/day/ schedule. Press the up or down buttons Hold: Press until you reach to override Hold the desired programmed temperature. temperature NOTE: Make sure control. the SYSTEM switch Run: Press to Heat Off Cool Auto On is set to the system Heat Off Cool...
  • Page 12: Preset Energy-Saving Schedules

    Set the Time and Day 1. Press the SET button, then press Set Time 6 : 30 s or t to set the clock time. 2. Press the SET button, then press Hold s or t to select the day of the week.
  • Page 13: Adjusting Program Schedules

    To Adjust Program Schedules (RTH2510) 1. Press SET until Set Schedule is 6 : 30 displayed. 2. Press to set your Wake Hold time for the day displayed, then Wake press SET. Set Schedule 3. Press to set the M33600 temperature for this time period, then press SET.
  • Page 14: Overriding Schedule Temporarily

    Program Schedule Override (Temporary) Press s or t to immediately adjust Temporary 6 : 30 the temperature. This will temporarily override the temperature setting for Hold the current time period. “Temporary” will appear on the display M33602 and the current program period will flash.
  • Page 15: Compressor Protection

    Built-In Compressor Protection This feature helps prevent damage to the compressor in your air conditioning 6 : 30 or heat pump system. Damage can occur if the compressor is restarted too soon after shutdown. This Cool feature forces the compressor to wait 5 Wake minutes before restarting.
  • Page 16: Change Filter

    Change Filter If the filter reminder is turned on Change Filter – Press & Hold Run to Reset 6 : 30 during installation, the words Change Filter will flash on the screen when Hold the filter needs to be replaced. After you replace the air filter, press M33632 and hold the RUN button for 3 seconds...
  • Page 17: Troubleshooting

    Troubleshooting If you have difficulty with your thermostat, please try the following suggestions. Most problems can be corrected quickly and easily. Display is Make sure fresh AAA alkaline batteries are correctly • blank installed. Heating Set system switch to Heat. Make sure the temperature is •...
  • Page 18: Limited Warranty

    International, Inc. This product is manufactured by Resideo Technologies, Inc. and its affiliates. Todos los derechos reservados. La marca comercial Honeywell Home se utiliza bajo licencia de Honeywell International, Inc. 33-00110ES-05 Este producto es fabricado por Resideo Technologies, Inc. y sus afiliados.
  • Page 19 RTH2510/ Termostato RTH2410 Serie Programable Manual del propietario Hold Lea y guarde estas instrucciones. Para obtener ayuda, visite Heat Off Cool Auto On Heat Off Cool Auto On honeywellhome.com Identifique el tipo de sistema Este termostato es compatible con los siguientes sistemas: Calefactor a gas, aceite o eléctrico •...
  • Page 20 PRECAUCIÓN: AVISO SOBRE EL MERCURIO Si este producto está reemplazando a un equipo de control existente que contiene mercurio en un tubo sellado, no coloque dicho equipo en la basura. Contacte al organismo encargado del manejo y disposición de desechos de su localidad para obtener instrucciones sobre cómo reciclar y desechar adecuadamente.
  • Page 21: Instalación

    Índice Instalación Anulación temporal de los cronogramas ........14 Instalación ............3 Anulación permanente Guía de instalación avanzada ....9 de los cronogramas ......... 14 Protección del compresor ..... 15 Acerca de su nuevo termostato Arranque anticipado ........ 15 Referencia rápida de los controles Cambio del filtro ........
  • Page 22 2 Remueva su viejo termostato Retire el termostato existente pero deje la placa de montaje con los cables adheridos. Si el termostato existente tiene un tubo de mercurio No retirar la placa sellado, vaya a la página 2 para obtener instrucciones mural todavía sobre cómo desecharlo adecuadamente.
  • Page 23 5 Coloque la placa de montaje Monte la nueva placa de montaje utilizando los tornillos y anclajes que se suministran. Used M32714 Taladre agujeros de 3/32 in. (2,4 mm) en yeso Taladre agujeros de 3/16 in. (4,8 mm) en paneles de yeso 6 Conecte los cables Simplemente haga corresponder las etiquetas de los cables.
  • Page 24 Conexión alternativa (Sistema convencional) Si las etiquetas no corresponden con las letras del termostato, revise la tabla que sigue y conecte al terminal como se indica aquí (refiérase a las notas que siguen). Conecte MS32726 Si los cables se conectarán a los terminales R y Rc, retire el puente metálico.
  • Page 25 Cableado (para bombas de calor con calefacción auxiliar o de reserva úni- camente) Si las etiquetas no corresponden con las letras del termostato, revise la tabla que sigue y conecte al terminal como se indica aquí (refiérase a las notas que siguen).
  • Page 26 8 Configure el interruptor de funcionamiento del RTHXXXX ventilador Mueva el interruptor a la configuración adecuada: GAS OR OIL ELECTRIC OR HEAT PUMP Gas o aceite: para los sistemas de calefacción de gas o aceite, deje el interruptor del ventilador en esta posición configurada de fábrica (para sistemas que controlan el ventilador en una GAS OR OIL...
  • Page 27: Guía De Instalación Avanzada

    Si su tipo de sistema es... Si su tipo de sistema es: q Calor y frío de una sola etapa q Calefacción únicamente o Refrigeración únicamente ¡Felicitaciones, ya está listo! Si su tipo de sistema es: q Bomba de calor* con calor de respaldo Continúe con la instalación avanzada para adaptar el termostato a su tipo de sistema.
  • Page 28: Acerca De Su Nuevo Termostato

    NOTA: Si no se presiona ningún botón durante 60 segundos mientras esté abierto el menú de configuración, el termostato salvaguarda los cambios automáticamente y sale del menú. Descripción - Presione Función el botón s o t para Configuración seleccione el tipo de 0 Calefacción y refrigeración: calefacción de gas, aceite o eléctrica con aire sistema acondicionado central o bomba de calor sin calefacción auxiliar/de reserva.
  • Page 29: Referencia Rápida De Los Controles Y La Pantalla De Inicio

    Controles del termostato Ajuste de la Set (configuración): Presione este botón para temperatura configurar la hora, el día o Presione los el cronograma. botones de Hold (suspender): desplazamiento Hold Presiónelo para anular el hacia arriba o control de temperatura hacia abajo hasta programada.
  • Page 30: Cronogramas De Ahorro De Energía Predeterminados

    Configuración de la hora y el día 1. Presione el botón “SET”, luego Set Time 6 : 30 presione s o t para configurar la hora del reloj. Hold 2. Presione el botón “SET”, luego presione s o t para seleccionar el día de la semana.
  • Page 31: Ajuste De Los Cronogramas Del Programa

    Para ajustar los cronogramas del programa (RTH2510) 1. Presione SET (configurar) hasta 6 : 30 que Set Schedule (configurar el cronograma) se muestre en la Hold pantalla. Wake 2. Presione s o t para configurar la Set Schedule hora para despertarse para el día M33600 que se muestra y luego presione SET.
  • Page 32: Anulación Temporal De Los Cronogramas

    Programación de la anulación del cronograma (temporal) Presione s o t para ajustar Temporary 6 : 30 inmediatamente la temperatura. Esto anulará temporalmente la Hold configuración de la temperatura para el período actual. M33602 La palabra “Temporary” (temporalmente) aparecerá en la pantalla y el período del programa actual destellará.
  • Page 33: Protección Del Compresor

    Protección del compresor incorporada Esta función ayuda a prevenir el daño del compresor en su acondicionador 6 : 30 de aire o en su sistema de bomba de calor. El compresor puede dañarse si se Cool vuelve a iniciar inmediatamente Wake después de ser apagado.
  • Page 34: Cambio Del Filtro

    Cambio del filtro Si el recordatorio de cambio del filtro Change Filter – Press & Hold Run to Reset 6 : 30 se activa durante la instalación, las palabras Change Filter (cambie Hold el filtro) destellarán en la pantalla cuando deba cambiar el filtro. Después de que reemplace el filtro de M33632 aire, presione y sostenga presionado el botón...
  • Page 35: De Problemas

    Localización y solución de problemas Si tiene dificultades con el termostato, intente seguir las sugerencias que se indican a continuación. La mayoría de los problemas pueden corregirse rápida y fácilmente. La pantalla Asegúrese de que las baterías AAA alcalinas estén •...
  • Page 36: Garantía Limitada

    International, Inc. This product is manufactured by Resideo Technologies, Inc. and its affiliates. Todos los derechos reservados. La marca comercial Honeywell Home se utiliza bajo licencia de Honeywell International, Inc. 33-00110ES-05 Este producto es fabricado por Resideo Technologies, Inc. y sus afiliados.
