- Page 1 I n t e g r a t e d W a s h i n g M a c h i n e I n s t r u c t i o n M a n u a l W MI 40 01 Contact Caple on 0117 938 7420 for spare parts or www.caple.co.uk...
-
Page 2: Table Of Contents
Environmental Protection Warranty Product Overview Installation Built In Installation Operation Quick User Guide Control Panel Washing Programmes Table Of Programmes Cleaning And Maintenance Troubleshooting Care Symbols Caple Contact Details Instruction manual WMi4001 Please keep this instruction manual for future reference... -
Page 3: Warnings
- Only use the hose-sets supplied with the appliance for the water supply connection (do not reuse old hose-sets). Instruction manual WMi4001 Please keep this instruction manual for future reference... - Page 4 - Please check whether the water inside the drum has been drained before opening its door. Please do not open the door if there is any water visible. Instruction manual WMi4001 Please keep this instruction manual for future reference...
- Page 5 - Before operating this machine, all packages and transport bolts must be removed. Otherwise the washing machine may be seriously damaged while washing the clothes. Instruction manual WMi4001 Please keep this instruction manual for future reference...
- Page 6 - Please remember to disconnect water and power supply immediately after the clothes are washed. - Do not climb up and sit on top cover of the machine. - Do not lean against machine door. Instruction manual WMi4001 Please keep this instruction manual for future reference...
- Page 7 - In the event of fault and / or malfunction, turn off the washing machine, close the water tap and do not tamper with the appliance. Immediately contact Caple service and only use original spare parts. Failure to observe these instructions may jeopardise appliance safety.
-
Page 8: Environmental Protection
(placed on the inside of the appliance storage drawer). Registration can also be completed online by visiting www.caple.co.uk. Ensure you keep your warranty card safe, you may need to show it to Caple Service together with proof of purchase. -
Page 9: Product Overview
Outlet Hose Outlet Hose Detergent Box Detergent Box A C C E S S O R I E S Transport Inlet pipe Corrugated sound proofing sheet Transport Inlet pipe Instruction manual WMi4001 Please keep this instruction manual for future reference... -
Page 10: Installation
During the removal of the bolts, spacer tubes fall inside the product. These can be removed by tilting the product forward and recovering them from the floor or inside the base of the machine. 10 Instruction manual WMi4001 Please keep this instruction manual for future reference... - Page 11 Plug in the appliance. ！ WA R N I N G : Contact Caple Service should the power cord need replacement. Installation faults are not covered by the manufacturers warranty. Instruction manual WMi4001 Please keep this instruction manual for future reference...
-
Page 12: Built In Installation
Contact Caple Service should the power cord need replacement. Installation faults are not covered by the manufacturers warranty. WARNING: Contact Caple Service should the power cord need replacement. Installation faults are not covered by the manufacturers warranty. B U I LT I N I N S T A L L A T I O N... - Page 13 5mm nuts supplied. Raise the feet to your desired height and then fully tighten the tighten lock nut to the base of the washer. Instruction manual WMI4000 Please keep this instruction manual for future reference Instruction manual WMi4001 Please Please keep this instruction manual for future reference...
-
Page 14: Operation
(e.g. buttons) are protected from cleaning agent. Chemical (solvent-based) cleaning agents can cause severe damage to the washing machine. Do not use solvent-based cleaning agents in the machine. 14 Instruction manual WMi4001 Please keep this instruction manual for future reference... - Page 15 Normal powders are suitable for “white” or colour fast fabrics with high soiling, while liquid detergents or “colour protecting” powders are suitable for coloured fabrics with light levels of soiling. Instruction manual WMi4001 Please keep this instruction manual for future reference...
- Page 16 WA R N I N G : Some detergents are not designed for use in the dispenser drawer but are supplied with their own dispenser that is placed in the drum directly. 16 Instruction manual WMi4001 Please keep this instruction manual for future reference...
-
Page 17: Quick User Guide
› Wait until the DOOR LOCKED light has gone out before opening the door. › Turn off the washing machine. › For any type of wash, see the programme table and follow the operating sequence as indicated. Instruction manual WMi4001 Please keep this instruction manual for future reference... -
Page 18: Control Panel
Do not touch the display while inserting the plug. The machine calibrates the systems during the first few seconds: touching the display could cause the machine to not work property. In this case, remove the plug and repeat the operation. 18 Instruction manual WMi4001 Please keep this instruction manual for future reference... - Page 19 PA U S I N G T H E M A C H I N E Keep the button pressed for about (some light indicators and the START/PAUSE 2 SECONDS residual time display will flash, showing that the machine is paused). Instruction manual WMi4001 Please keep this instruction manual for future reference...
- Page 20 This button allows you to choose between three different functions: P R E - W A S H I N G This function provides a prewash and is particularly useful for heavily soiled loads. 20 Instruction manual WMi4001 Please keep this instruction manual for future reference...
- Page 21 This function allows you to choose between 3 levels of wash intensity modifying the length of the programme, depending on how much the fabrics are soiled (can only be used on some programmes as shown in the table of programmes). Instruction manual WMi4001 Please keep this instruction manual for future reference...
- Page 22 Deselect the option to end the cycle with a spin dry (which may be reduced or cancelled using the appropriate button). Due to the electronic control, the water in the intermediate phases is emptied silently, making this option very useful for washing at night. 22 Instruction manual WMi4001 Please keep this instruction manual for future reference...
- Page 23 This shows the spin speed of the selected programme, you can reduce or omit by the fore opening the door. At the end of the cycle turn the programme selector to relevant button. Instruction manual WMi4001 Please keep this instruction manual for future reference...
- Page 24 Through every wash phase, allows you to monitor information on the wash load “KG LOAD” in the drum. In the first minutes of the wash it: 24 Instruction manual WMi4001 Please keep this instruction manual for future reference...
- Page 25 › Recognises the presence of too much soap suds, and if necessary, adjust the amount of rinse water. › Adjusts the spin speed according to the load, thus avoiding any imbalance. Instruction manual WMi4001 Please keep this instruction manual for future reference...
-
Page 26: Washing Programmes
This programme performs 3 rinses with an intermediate spin (which can be reduced or excluded by using the appropriate button). It is used for rinsing any type of fabric, for example after a wash carried out by hand. 26 Instruction manual WMi4001 Please keep this instruction manual for future reference... - Page 27 This programme performs a wash cycle dedicated to the wool fabrics that can be washed in a washing machine. H A N D W A S H A gentle programme for hand wash only fabrics with a slow spin. Instruction manual WMi4001 Please keep this instruction manual for future reference...
-
Page 28: Table Of Programmes
• • • S I L K 30˚C • • W O O L 40˚C • • H A N D W A S H 30˚C • • 28 Instruction manual WMi4001 Please keep this instruction manual for future reference... - Page 29 Selecting the RAPID programme on the knob, it will be possible to select with the RAPID button, one of the three rapid programmes available among 14’, 30’ and 44’. STANDARD PROGRAMME ACCORDING TO (EU) NO 2019/2023 PROGRAMME ECO 40-60 Instruction manual WMi4001 Please keep this instruction manual for future reference...
-
Page 30: Cleaning And Maintenance
Applying a small amount of liquid soap on the filter seal will help refitting. Repeat the previous steps in reverse order to reassemble all parts. 30 Instruction manual WMi4001 Please keep this instruction manual for future reference... - Page 31 The manufacturers warranty only covers faults within the product of a mechanical or electrical nature. Faults caused by handling, installation or misuse are not covered and may incur a charge for any repair visit to resolve. Instruction manual WMi4001 Please keep this instruction manual for future reference...
-
Page 32: Troubleshooting
Turn off and unplug the washing machine, wait a minute. Turn on the Any other code machine and restart a programme. If the error occurs again contact an Authorised Customer Service Centre directly. 32 Instruction manual WMi4001 Please keep this instruction manual for future reference... - Page 33 Make sure transport screws, rubber bungs and spacer tubes were removed. during the spin cycle Make sure there are no foreign objects inside the drum (coins, hinges, buttons, etc). Instruction manual WMi4001 Please keep this instruction manual for future reference...
- Page 34 In this case, do not re-rinse to eliminate these effects: it will not help at all. We suggest conducting a maintenance wash using a proprietary cleaner. If the problem persists or more help is required, please contact our Caple service team on or via email 0117 938 7420 SERVICE@CAPLE.CO.UK.
-
Page 35: Care Symbols
C A R E S Y M B O L S The label and sign on the fabric can help you to choose the best way to launder your clothes. Instruction manual WMi4001 Please keep this instruction manual for future reference... -
Page 36: Caple Contact Details
Caple Service Fourth Way Avonmouth T: 0117 938 1900 Bristol E: service@caple.co.uk BS11 8DW www.caple.co.uk...
