VIA Technologies VAB-600-B Quick Manual

VAB-600-B
Module for VAB- - - - 600 Pico Module for VAB Module for VAB Module for VAB 600 Pico 600 Pico- - - - ITX mainboard 600 Pico ITX mainboard ITX mainboard ITX mainboard
Quick Guide

Key Features:

Key Features: Key Features: Key Features:
• Install using Mini Card interface
Support four COM connectors
•
• Quick installation and easy setup
COM Connector
1
Pinouts
COM 1 connector: CN1 COM 1 connector: CN1 COM 1 connector: CN1 COM 1 connector: CN1
Pin Pin Pin Pin Signal Signal Signal Signal Pin Pin Pin Pin signal signal signal signal
1 DCD_1 6 DSR_1
2 RXD_1 7 RTS_1
3 TXD_1 8 CTS_1
4 DTR_1 9 RI_1
5 GND
The VAB-600-B is an USB connectivity module equipped with four
9-pins COM connectors, and it is specially designed to provide
additional COM ports to VAB-600-B Pico-ITX mainboard. Each COM
connector is used to attach COM cable ports (male DE-9 connec-
tor) that supports RS-232 standard. The VAB-600-B module can be
installed to VAB-600 mainboard through onboard mini-card slot.

Specifications:

Specifications: Specifications: Specifications:
PCB PCB PCB PCB Size: Size: Size: Size:
•
50.95 mm x 30 mm x 1 mm (L x W x H)
•
USB to COM Controller: USB to COM Controller: USB to COM Controller: USB to COM Controller:
•
EXAR XR21V1414 4-Ch Full-Speed USB UART
•
USB 2.0 compliant, Full-speed (12 Mbps)
•
Fully compliant with the USB 2.0 specification
•
Onboard I/O Connectors: Onboard I/O Connectors: Onboard I/O Connectors: Onboard I/O Connectors:
•
4 x COM connector
•

Package Lists:

Package Lists: Package Lists: Package Lists:
1 x VAB-600-B module
•
Note: Note: Note: Note:
Please ensure that all items in the packing list are present before
using this product. If any of the items are missing or damaged,
contact your distributor or sales representative immediately.
COM 2 connector: CN2 COM 2 connector: CN2
COM 2 connector: CN2 COM 2 connector: CN2
Pin Pin Pin Pin Signal Signal Signal Signal Pin Pin Pin Pin signal signal signal signal
1 DCD_2 6 DSR_2
2 RXD_2 7 RTS_2
3 TXD_2 8 CTS_2
4 DTR_2 9 RI_2
5 GND
Layout Diagram Layout Diagram Layout Diagram Layout Diagram
COM 3 connector: CN3 COM 3 connector: CN3 COM 3 connector: CN3 COM 3 connector: CN3
Pin Pin Pin Pin Signal Signal Signal Signal Pin Pin Pin Pin signal signal signal signal
1 DCD_3 6 DSR_3
2 RXD_3 7 RTS_3
3 TXD_3 8 CTS_3
4 DTR_3 9 RI_3
5 GND
Dimensions Dimensions Dimensions Dimensions
Top View Top View Top View Top View
Bottom View Bottom View Bottom View Bottom View
Side View Side View Side View Side View
COM 4 Connector: CN4 COM 4 Connector: CN4
COM 4 Connector: CN4 COM 4 Connector: CN4
Pin Pin Pin Pin Signal Signal Signal Signal Pin Pin Pin Pin signal signal signal signal
1 DCD_4 6 DSR_4
2 RXD_4 7 RTS_4
3 TXD_4 8 CTS_4
4 DTR_4 9 RI_4
5 GND
