Kraus Sellette KPF-1680 Installation Instructions Manual
Single handlepull-down kitchen faucet
Hide thumbs
Also See for Sellette KPF-1680:
- Installation manual (16 pages) ,
- Manual (16 pages) ,
- Installation manual (16 pages)
Related Manuals for Kraus Sellette KPF-1680
Summary of Contents for Kraus Sellette KPF-1680
- Page 1 INSTALLATION MANUAL Sellette Single Handle Pull-Down Kitchen Faucet KPF-1680 www.kraususa.com Toll Free: 1.800.775.0703 © 2018 Kraus USA Inc. REV. June 17, 2021...
- Page 2 Congratulations on the purchase of your new Kraus plumbing fixture! Please keep the box and packaging materials until your product is completely installed. If you have any questions, require technical assistance or have any problems with your product: STOP DO NOT RETURN TO STORE Please contact our Customer Service Team 1-800-775-0703 / customerservice@kraususa.com...
- Page 3 Prior to Installation: · Make sure you have all necessary parts by checking the diagram and parts list. If any part is missing or damaged, please contact Kraus Customer Service at 800-775-0703 for a replacement. · Turn off the hot and cold water supply at the angle stops and turn on the old faucet to release any built up pressure.
- Page 4 Diagram and Parts List...
-
Page 5: Tools You Will Need
Diagram and Parts List Tools you will need Spray Head Faucet Body Deck Plate Assembly A. Deck Plate Adjustable Wrench B. Base Plate Mounting Hardware A. Rubber & Metal Washer B. Mounting Nut C. Mounting Screws Spray Hose Silicone Sealant (optional) Weight Quick Connector... - Page 6 Faucet Installation Procedure 4 1/2" (114mm) 11 1/8" (283mm) 9 1/8" (232mm) 2 1/8" (65mm) 2 1/4" (57mm) 2 1/2" (65mm) 2X G 1/2" Ø 1 1/2" (37mm) 2 1/2" (64mm) 10 3/8" (265mm) 1/2" (13mm) * Optional Deck Plate Installer Tip: Shut off main water supply before installing new faucet.
- Page 7 Step 1A. Faucet installation - with deck plate For three-hole installation: Deck plate (3A), base plate (3B), and silicone sealant (optional) are required. Step 1B. Faucet installation - without deck plate For single-hole installation: Deck plate (3A), base plate (3B) and silicone sealant are NOT required.
- Page 8 Step 2. Install faucet and mounting hardware Insert faucet body (2) into hole in countertop or deck plate assembly (3). Install mounting hardware (4A, B & C) from underneath the countertop. NOTE: Make sure the Rubber O-ring (12) is installed before installing the faucet.
- Page 9 Step 4. Attach spray hose and counterweight Connect spray hose (5) to quick connector (7) attached to supply line. Install weight (6) on lowest vertical point on spray hose (5). Step 5. Connect waterlines Connect waterlines to hot and cold copper lines (8). Connect waterlines (11) to angle stops.
- Page 10 Step 6. Flush spray hose Remove spray head (1) from spray hose (5). Hold tip of spray hose (5). Turn faucet on and let the water run for 60 seconds to flush any debris. NOTE: Please make sure washer (10) is installed attaching spray head to hose.
- Page 11 Replacement Parts Replacement Parts List Finish/Color Part # KP06092 Spray Head CH,SFS,ORB* KP06105 Check Valve KP06098 Spray Hose CH,SFS,ORB* KP06045 Hose Guide KP06072 Plastic Clip BL,GR* KP06030 CH,SFS,ORB* Handle Button KP06055 Set Screw KP06043 Metal Handle CH,SFS,ORB* KP06021 Cartridge Cover CH,SFS,ORB* KP06018 10.
-
Page 12: Troubleshooting
Troubleshooting If you have followed the instructions carefully and your faucet still does not work properly, take the following corrective steps: PROBLEM CAUSE ACTION Leakage under faucet handle Locking nut has come loose or Remove button located at top of handle. cartridge needs to be reseated. - Page 13 Maintenance - Cartridge Replacement Step 1: Remove button located at the top of the handle. Loosen the set screw with a hex wrench. Remove the handle and unscrew cartridge cover by hand. Step 2: Unscrew the locking nut with an adjustable wrench. Remove ceramic disc cartridge.
- Page 14 Any product reported to the authorized dealer or to Kraus as being defective within the warranty period will be repaired or replaced with a product of equal value at the option of Kraus. This warranty extends to the original owner or end-user, and is not transferable to a subsequent owner.
- Page 15 This warranty gives you specific legal rights, and you may also have other rights which vary from state to state. KRAUS USA has the right to change, modify, and/or update the warranty policy at any time. For the latest, most up to date comprehensive warranty, go to www.kraususa.com/warranty...
- Page 16 IMPORTANT Register Your Kraus Product Activate Your Warranty Access Premium Customer Support Get Product Information REGISTER TODAY http://www.kraususa.com/registration www.kraususa.com...
- Page 17 INSTALLATION GUIDE Kraus Kitchen Soap Dispenser KSD-80 www.kraususa.com I Toll Free: 1.800.775.0703 I © 2018 Kraus USA Inc. I REV. August 13, 2019...
- Page 18 Congratulations on the purchase of your new Kraus plumbing fixture! Please keep the box and packaging materials until your product is completely installed. If you have any questions, require technical assistance, or have any problems with your product: STOP DO NOT RETURN TO STORE Please contact our Customer Service Team 1-800-775-0703 / customerservice@kraususa.com...
-
Page 19: Prior To Installation
Toll-Free: 800.775.0703 or customerservice@kraususa.com The step-by-step guidelines in the installation instructions are a general reference for installing a Kraus Sink. Should there be any discrepancies, Kraus cannot be held liable. It is recommended to install all Kraus products by hiring a licensed professional. - Page 20 Diagram and Parts List: Replacement Parts List Finish/Color Part # Pump KP06150 CH,SFS,ORB KP06151 Dispenser Base CH,SFS,ORB Washer KP06152 Mounting Nut KP06153 e. Dispenser Bottle KP06154...
- Page 21 Step 1 Disassemble soap dispenser.
- Page 22 Step 2 Install dispenser base (b) with washer attached into the hole in the countertop. Re-install washer (c) and mounting nut (d) on the dispenser base (b) from underneath the countertop. Tighten mounting nut (d) by hand.
- Page 23 Step 3 Screw the dispenser bottle (e) to the dispenser base (b) from underneath the countertop. Tighten as required. Fill the dispenser bottle (e) from the top with up to 17 ounces of soap.
- Page 24 Step 4 Reinsert pump (a) into dispenser base (b) from the top. Press the pump several times to make sure soap is evenly distributed. Press...
- Page 25 The warranty commences from the initial date of purchase by the owner or trade professional, from an authorized Kraus dealer, through the one (1) year term of the original owner or end-user. Any product reported to the authorized dealer or to Kraus as being defective within the warranty period will be repaired or replaced with a product of equal value at the option of Kraus.
- Page 26 (HI, AK, and Puerto Rico shipping charges may apply). International shipping fees are not included. Commercial Warranty Kraus extends the above warranty for a period of one (1) year to purchasers of products for industrial, commercial, and business use. All incidental or consequential damages are specifically excluded. No additional warranties, express or implied are given, including but not limited to, any implied warranty of merchantability or fitness for a particular purpose.
- Page 27 Kraus USA, Inc. 12 Harbor Park Drive Port Washington, NY 11050 Toll-free 800-775-0703 Customerservice@kraususa.com If you are a PLUMBING CONTRACTOR OR TRADE PROFESSIONAL please contact a Kraus Pro Representative at: Kraus USA, Inc. 12 Harbor Park Drive Port Washington, NY 11050 516-801-8955 Proservice@kraususa.com...
- Page 28 IMPORTANT Register Your Kraus Product Activate Your Warranty Access Premium Customer Support Get Product Information REGISTER TODAY http://www.kraususa.com/registration...
