INSTRUCTION MANUAL
MX-113-EB
SIGNAL
AUX 3
PRE-AMPLIFIER MIXER MX-113-EB
0
10
...
...
...
...
...
...........................
...
.........
..............................
...
...........................
.......................................
...................................................
................................................
POWER
PEAK
8
...
...
...............
8
...
...
...
.........
9
10
...
11
12
12
12
12

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MX-113-EB and is the answer not in the manual?

Questions and answers

Related Manuals for Toa MX-113-EB

Summary of Contents for Toa MX-113-EB

  • Page 1: Table Of Contents

    ………………………………… ……………………………………………………… Accessories Rear …………………………………………… ……………………………………………………… Optional items Bottom ………………………………………… ……………………………………………………… CONNECTIONS Connection example ……………………………… ……………………… Thank you for purchasing the TOA mixer amplifier. Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment.

  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS Read these instructions. ● Keep these instructions. ● Heed all warnings. ● Follow all instructions. ● Do not use this apparatus near water. ● Clean only with dry cloth. ● Do not block any ventilation openings. Install in accordance with the manufacturer's instructions. ●...
  • Page 3 Should the following irregularity be found during use, immediately switch off the power, disconnect the power ● supply plug from the AC outlet and contact your nearest TOA dealer.Make no further attempt to operate the unit in this condition as this may cause fire or electric shock.

  • Page 4: General Description

    Clean the unit regularly ● Contact your TOA dealer as to the cleaning. If dust is allowed to accumulate in the unit over along period of time, a fire or damage to the unit may result. Clean the power supply plug ●...

  • Page 5: Features

    FEATURES Up to six microphones can be connected. Alternatively, five microphones and four AUX inputs can be used ● simultaneously. Built-in voice switch function. ● The voice switch. ● By connecting a DC power supply to this terminal, the amplifier power can be turn on/off remotely. Record output.

  • Page 6: Nomenclature And Functions

    MIC 6 / AUX 1 AUX 2 AUX 3 SIGNAL PEAK POWER PRE-AMPLIFIER MIXER MX-113-EB Microphone 6 / Auxiliary 1 Power switch volume control knob Press to turn on and press again to turn Adjusts the volume the device off the power.

  • Page 7: Connections

    AUX 1 VOICE SWITCH MIC 6 MIC 5 MIC 4 MIC 3 MIC 2 MIC 1 REMOTE SWITCH 30V 1A PRE-AMPLIFIER MIXER model MX-113-EB MIN MAX TOA Corporation DC POWER IN 0dBV 0dBV -12dBV -12dBV 10kΩ -12dBV 10kΩ -12dBV -62dBV...

  • Page 8: Operations

    AUX 1 VOICE SWITCH MIC 6 MIC 5 MIC 4 MIC 3 MIC 2 MIC 1 REMOTE SWITCH 30V 1A PRE-AMPLIFIER MIXER model MX-113-EB MIN MAX TOA Corporation DC POWER IN 0dBV 0dBV -12dBV -12dBV 10kΩ -12dBV 10kΩ -12dBV -62dBV MADE IN CHINA 600Ω...

  • Page 9: Balanced Input

    BALANCED INPUT All the input on this equipment are unbalanced inputs. By installing a separated IT-450 balanced transformer, microphone inputs 1 to 5 and Auxiliary 4 can be balanced. The following procedure below is adding IT-450 balance transformer. Please leave this work to a professional expert. WARNING There is a high voltage component inside, and opening or modifying the case may cause fire or electric shock.

  • Page 10: Setting The Voice Switch On/Off

    SETTING THE VOICE SWITCH ON/OFF The voice switch function is built into microphone 1-5 circuits, and the function is set with voice switch function ON / OFF switch. ※The factory setting is "OFF". Turn off the power switch of DC power supply equipment and remove the power plug. ARNING Please do not open the bottom plate while the power plug is plugged into the AC outlet.

  • Page 11: Circuit Diagram

    CIRCUIT DIAGRAM...

  • Page 12: External Dimensions

    MIC 6 / AUX 1 AUX 2 AUX 3 SIGNAL PEAK POWER PRE-AMPLIFIER MIXER MX-113-EB FRONT VIEW SIDE VIEW SPECIFICATIONS Power Source DC 19-33V, DC power in : M3 screw terminal, Barrier interval : 6.4mm DC jack, from an optional AD-246 AC adapter Current Consumption Max 0.2A...
