- Page 1 X839 Model: C83985-01, 03, 30, 55 Asbestos C83905-01, 03, 30, 55 Series C83930-01, 03, 30, 55 15, 30 & 55 Gallon Stainless Steel & Painted OPERATION SERVICE PARTS CARE Revised 6/02...
- Page 2 FOR COMMERCIAL USE ONLY IMPORTANT SAFETY INSTRUCTIONS When using an electrical appliance, basic precautions should always be followed, including the following: READ ALL INSTRUCTIONS BEFORE USING WARNING - To reduce the risk of fire, electric shock, or injury: • Do not leave appliance when plugged in. Unplug from outlet when not in use and before servicing.
-
Page 3: Electrical - 115 Volt
INSPECTION Carefully unpack and inspect your machine for shipping damage. Each unit is tested and thoroughly inspected before shipment, and any damage is the responsibility of the delivery carrier who should be notified immediately. ELECTRICAL - 115 Volt This machine is designed to operate on a standard 15 amp. 115 volt, 60 hz, AC circuit. Voltages below 105 volts AC or above 125 volts AC could cause serious damage to the motor. -
Page 4: User Maintenance Instructions
USER MAINTENANCE INSTRUCTIONS All service and repair should be performed by a qualified vacuum service representative or electrician. No user serviceable components are employed in the electrical vacuum lid head assembly. No lubrication of the motor is required. CLOTH BAG & HOSE ASSY Cloth bag and hose assy. -
Page 5: Operation And Filter Care Instructions
OPERATION AND FILTER CARE INSTRUCTIONS The Minuteman Asbestos Vacuum has been specifically designed to clean up fibrous asbestos and asbestos dust of all types. Special filters reduce the incidence of airborne dust that would be created by any other method of cleaning. - Page 6 CHANGING THE PINK IMPACTION PREFILTER Refer to Item No. 37, Page 7. The pink impaction filter should be changed, using all of the precautions previously mentioned. The impaction filter should be changed when any of the following takes place: 1. Anytime there is an indication of a filter tear during normal operation of the unit. This tear could be in any of the filters used.
-
Page 7: Parts List
PARTS LIST Item Part No. Description 801085 (85) Lid Asy Comp 801105 (105) Lid Asy Comp 801130 (130) Lid Asy Comp 805057 Cloth Bag Asy Comp 805038 Pkg Disposable Fliter Protector Pkg of 12 750220 Tank Asy Comp 15 Gallon Stainless Steel 750221 Tank Asy Comp 15 Gallon Painted 760598 Pkg... - Page 9 VAC HEAD ASSEMBLY Item Part No. Qty. Description 760899 Handle Bail 760898PLT Cap, Motor 760897PLT Cover, Motor 760902 Motor Hold Down P/V HEPA 760903 Motor Lid Assembly P/V HEPA 809754 Switch, Rocker 831543 Gasket, Diecut Switch 381020 Orange Cord Set 16-3, 50' 740600 Power Cord, International 833237...
- Page 11 Parts List Item Part No. Qty. Description 900001 Tank, PTD 15 Gal 900003POL Tank, Polished 15 Gal SS 900031 Handle, Tank Polished 900038 Clamp, Handle 390001 Trigger with Pins 761054 Latch 900037PLT Handle, Plated 711310 Nut-Hex 10-32 ST PL 711543 Washer-Helical #10 711503 Washer-Flat #10...
- Page 12 PARTS LIST Item Part No. Description 806016PTD 55 Gal. Adapter Painted 806015PTD 30 Gal. Adapter Painted 390100MCH Molded Intake MCH 15/30 900035 Deflector, Intake 761054 Latch 390087 Gasket Diecut Poron Intake 806006 Gasket, Raw 710530 SCR-MC 8-32 x .50 BR 712824 SCR-THMS 10-24 x .75 STPL 711915...
- Page 13 PARTS LIST Item Part No. Description 900078PTD Tank 30 Gal. PTD Less Handles 900015PTD Tank 55 Gal. PTD No Handles 900047 Dump Valve 900031POL Handle, Tank Polished 711203 BLT, HH 1/4-20 x .62 711591 Washer, Rubber 711505 WSR, Flat 1/4 C90007-80 Tank 30 Gal.
- Page 14 PARTS LIST Item Part No. Description 750045 Weldment dolly 30/55 900051 Weldment, handle 900052 Grip, handle 900080 Spring, torsion RH 900081 Spring LH 711642 Rollpin 761050 Caster, rigid 5" 761049 Caster, swivel 5" 711545 WSR, helical Spr Loc 5/16 711319 Nut-Hex 5/16-18 ST PL 900048 Dolly cart complete...
- Page 15 PARTS LIST Item Part No. Qty. Description 760131 Molded bag ring 750097 Bag frame 805054 Cloth bag only 805057 Bas assy. complete...
-
Page 16: Limited Warranty
Minuteman International, Inc. warrants to the original purchaser/user that this product is free from defects in workmanship and materials under normal use and service for a period of three years from date of purchase. In addition, Minuteman International, Inc. will, at its option, honor labor warranty claims for the first 12 months from date of sale, provided such claims are submitted through and approved by factory authorized repair stations.
