APPENDIx I. OPERATION MODES AND TROUBLEShOOTINg gUIDE:

Modes *Red Yellow and
See Note Remote Trouble
Below
Normal Off Off
Alignment Off On
Alarm On Off
Trouble-Drift Off 3 Quick Blinks
Comp Elevated
Signal
Trouble-Drift Off 2 Quick Blinks
Comp Reduced
Signal
Trouble-Signal Off 2 Quick Blinks
Over Range
Trouble-Beam Off 4 Quick Blinks
Blockage
Response
Initialization- Off Blink until
Power on complete
Initialization- Off Blink until
alignment exit complete
Local Test On Blinks out amount
(BEAM-200S) of drift used
Pass Result
Local Test Off On until reset or
(BEAM-200S) time-out
Fail Result
Local Test Off On until reset or
(BEAM-200) time-out
Fail
Local Test On Blinks out amount
(BEAM-200) of drift used
Pass Result
Note: Green and Red LEDs are controlled by the control panel.
Blinks output by Yellow LED and Remote Trouble Output
once the device has passed a local remote test:
Percent The Detector Has Drifted
<10%
<20%
<30%
<40%
<50%
<60%
<70%
<80%
<90%
<100%
D400-74-00
*Green Remote
See Note Alarm
Output Below Output
Blink Blink
Blink Blink
Off On
Blink Blink
Blink Blink
Blink Blink
Blink Blink
Blink Blink
Blink Blink
Off On
Blink Blink
Blink Blink
Off On
Number Of Blinks Output
None
1
2
3
4
5
6
7
8
9
Dual Digital Display Initiating means
Off Successful completion
of initialization or
detector reset
On, Relative amount Alignment Switch
of signal 0-99, or – if
automatic gain resetting,
or Lo if signal is too low
Off Smoke, Test Filter,
RTS451 or RTS151
Test Stations
Off Long Term Drift
Reference Out of
Range
Off Long Term Drift
Reference Out of
Range
Off Increase of Reflected
Signal
Off Beam Blockage
Off Apply Power from
discharged state.
Off Depressing RESET
switch after alignment
Off Panel or RTS451/KEY
or RTS151/KEY
Off Panel or RTS451/KEY
or RTS151/KEY test
input
Off Panel or RTS451/KEY
or RTS151/KEY test
input
Off Panel or RTS451/KEY
or RTS151/KEY
10
Comments & Troubleshooting
Tips
• Sunlight into detector or reflector.
• Re-Align detector.
• Clean detector and reflector.
• Inspect line of sight between
detector and reflector for
reflective objects in the pathway.
• Remove blockage.
• Faulty unit.
Remains in alarm until reset or
time-out
Remains in fault until reset or
time-out
Remains in fault until reset or
time-out
Remains in alarm until reset or
time-out
I56-2289-005R
