- Page 1 Ross Video Limited FSU-8032A Frame Synchronizer Upgrade Manual Ross Part Number: 8032ADR-204 Issue: 04...
- Page 2 The information contained in this Upgrade Manual is subject to change without notice or obligation. Copyright © 2004 Ross Video Limited. All rights reserved. Contents of this publication may not be reproduced in any form without the written permission of Ross Video Limited. Reproduction or reverse engineering of copyrighted software is prohibited. Notice The material in this manual is furnished for informational use only.
- Page 3 Along with this manual, your Frame Synchronizer Upgrade kit contains: • 1 FSU-8032A User Manual • 1 software upgrade chip • 1 firmware upgrade chip • 1 chip remover tool Frame Synchronizer Upgrade • 1-1 FSU-8032A Upgrade Manual (Iss. 04)
- Page 4 8. Align the new chip over the socket with the beveled corners together and the label facing up. Text direction may vary. 9. Gently and firmly press the chip into the socket. 10. Proceed to the Firmware Upgrade Procedure, on the following page. 1-2 • Frame Synchronizer Upgrade FSU-8032A Upgrade Manual (Iss. 04)
- Page 5 8. Refer to the ADC-8032A user manual for information on the operation of the full frame synchronizer. If you have any questions or encounter any problems, please contact Ross Video Customer Service at (613) 652-4886. Frame Synchronizer Upgrade • 1-3...
