BATTERY TEST
Ranges: 1.5 V, 9 V
Accuracy: ± (3.5% rdg + 2 dgts)
NON-CONTACT VOLTAGE INDICATOR
Sense voltage 70 V to 600 VAC (50 Hz to
60 Hz) beeper chirps and bright green LED
comes on, works when meter dial is on any
range.
OVERLOAD PROTECTION:
Voltage, Resistance, Diode, Continuity:
1000 VDC or 750 VAC rms
200 mV Range: 1000 VDC / 750 VAC rms
(3 minutes)
Current: 0.315 A / 1000 V fast blow ceramic
fuse 6.3 × 32 mm
mA JACK: Input warning detects wrong
switch/input jack configuration
AUXILIARY FEATURES
DATA HOLD: Freeze the latest reading on
the display.
MIN/MAX: Record the maximum and
minimum reading in a measurement.
15XP Electrical Specifications
(at 23°C ± 5°C, < 75% R.H.)
DC VOLTS
Ranges: 200 mV, 2 V, 20 V, 200 V, 1000 V
Accuracy: ±(0.5% rdg + 1 dgt)
AC VOLTS (45 Hz to 500 Hz)
Ranges: 200 mV, 2 V, 20 V, 200 V, 750 V
Accuracy: ±(1.5% rdg + 5 dgts) 45 Hz to
100 Hz on 200 mV range ±(1.5% rdg
+ 5 dgts) on 2 V to 750 V ranges
DC CURRENT
Ranges: 200 µA, 2000 µA, 20 mA, 200 mA,
2 A
Accuracy: ±(1.0% rdg + 2 dgts) on 200 µA
to 200 mA ranges ±(2.0% rdg + 3 dgts) on
2 A range
AC CURRENT (45 Hz to 500 Hz)
Ranges: 200 µA, 2000 µA, 20 mA, 200 mA,
2 A
Accuracy: ±(1.5% rdg + 5 dgts) on 200 µA
to 200 mA ranges ±(2.5% rdg + 5 dgts) on
2 A range
RESISTANCE
Ranges: 200 Ω, 2 kΩ, 20 kΩ, 200 kΩ,
2 MΩ, 20 MΩ
Accuracy: ± (1.0% rdg + 4 dgts) on 200 to
2 MΩ ranges ± (3.0% rdg + 5 dgts) on
20 MΩ range
CONTINUITY
Audible indication: Less than 25 Ω
DIODE TEST
Test current: 1.2 mA (approximate)
Accuracy: ±(1.5% rdg + 3 dgts)
Open circuit volts: 3.0 dc typical
LOGIC TEST
Thresholds Logic 1 (Hi): 2.8 V ± 0.8 V
Thresholds Logic o (Lo): 0.8 V ± 0.5 V
Test voltage: TTL 5 VDC
NON-CONTACT VOLTAGE INDICATOR
Sense voltage 70 V to 600 VAC (50 Hz to
60 Hz) beeper chirps and bright green LED
comes on, works when meter dial is on any
range.
OVERLOAD PROTECTION:
Voltage, Resistance, Diode, Continuity,
Logic: 1000 VDC or 750 VAC rms
Current: 2 A / 1000 V fast blow ceramic
fuse 6.3 × 32 mm
A JACK: Input warning detects wrong
switch / input jack configuration
AUXILIARY FEATURES
DATA HOLD: Freeze the latest reading on
the display.
RANGE: Execute manual range mode.
AUTO Power off: After auto power off,
press (RANGE) button to restart the meter,
and the last reading of measurement will be
returned to the display.
