Specifications

Display:
5XP and 15XP:
3 ½ digit liquid crystal
display (LCD) with a maximum reading of
1999.
35XP:
3 ¾ digit liquid crystal display
(LCD) with a maximum reading of 3999.
Polarity: Automatic, positive implied,
negative polarity indication.
Overrange: 0o or -0o is displayed.
Low battery indication: The
symbol is displayed when the battery
voltage drops below the operating level.
Operating environment: 0 °C to 50 °C
at <70 % R.H.
Power: Single standard 9 V battery,
NEDA 1604, JIS 006P, IEC 6F22.
Dimensions: 155 mm (H) ×72 mm (W)
×32 mm (D)
Weight: Approximately 210 g including
battery.
Overload protection: 1000 V dc or
750 V ac
One pair test leads TL245,
Accessories:
9 V battery (installed),holster, magnet
strap, Users Manual.
Altitude: 6561.7 Feet (2000 M)
Safety: Conforms to EN61010-1, Rev-2;
CAT I 1000V, CAT II 600V, CAT III 300V,
class 2 and pollution deg.2;
CSA 22.2 -1010-1.
EMC: Conforms to EN61326-1. This
product complies with requirements of the
following European Community Directives:
89/ 336/ EEC (Electromagnetic
Compatibility) and 73/ 23/ EEC (Low
Voltage) as amended by 93/ 68/ EEC (CE
Marking). However, electrical noise or
intense electromagnetic fields in the vicinity
of the equipment may disturb the
measurement circuit. Measuring
instruments will also respond to unwanted
signals that may be present within the
measurement circuit. Users should exercise
care and take appropriate precautions to
avoid misleading results when making
measurements in the presence of electronic
interference.
Replacement Parts
TL36
TL245 Test Lead Set
FP200 Fuse – 2 A / 1000 V (15XP and
FP300 Fuse – 0.315A / 1000V (5XP)
H2-XR Magne-Grip
M
XR-TA Input Adapter for K-type
TP255 K type thermocouple
See www.metermantesttools.com for
detailed specifications of the Meterman
XP digital multimeters.
5XP Electrical Specifications
(at 23°C ± 5°C, < 75% R.H.)
DC VOLTS
Ranges: 200 mV, 2 V, 20 V, 200 V, 1000 V
Accuracy: ± (1.0% rdg + 1 dgt)
AC VOLTS (45 Hz to 500 Hz)
Ranges: 200 mV, 2V, 20 V, 200 V, 750 V
Accuracy: ± (1.5% rdg + 5 dgts)
DC CURRENT
Ranges: 200 µA, 2 mA, 20 mA, 200 mA,
± (1.5% rdg + 1 dgt)
AC CURRENT (45 Hz to 500 Hz)
Ranges: 200 µA, 2 mA, 20 mA, 200 mA,
± (2.0% rdg + 5 dgts)
RESISTANCE
Ranges: 200 Ω, 2 kΩ, 20 kΩ, 200 kΩ,
2 MΩ, 20 MΩ
Accuracy: ± (1.0% rdg + 4 dgts) on 200 to
200 kΩ ranges ± (1.5% rdg + 4 dgts) on
2 MΩ range ± (3.0% rdg + 5 dgts) on
20 MΩ range
CONTINUITY
Audible indication: 75 ± 25 Ω
DIODE TEST
Test current: 1.0 mA (approximate)
Accuracy: ± (1.5% rdg + 3 dgts)
Open circuit volts: 3.0 dc typical
10
Test Lead Set
35XP)
®
Holster, clip, magnet,
and strap
thermocouple
