Introduction
The Level-Up® 5th Wheel LCD Leveling System is a hydraulic leveling system. The system includes six points
of contact utilizing aluminum jacks and a multi-valve system. A 12V DC electric motor drives a hydraulic
pump that moves fluid through a system of hoses, fittings and jacks to level and stabilize the trailer.
Mechanical portions of the Level-Up® 5th Wheel Hydraulic Leveling System are replaceable.
Components
1.
Jacks
A.
Rated at a lifting capacity for the trailer.
B.
Standard 9-inch diameter (63.5 square inch) foot pad on a ball swivel for maximum surface contact
on all surfaces.
C.
Optional 12-inch diameter - (113 square inch) foot pad also available.
D. Operational Powered from a 12V DC Motor/Pump assembly.
2.
Motor/Pump Assembly
A.
12V DC motor
B.
Hydraulic fluid reservoir tank
C.
Control valve manifold
D. Solenoid valve
3.
System Controls
A.
Touch pad can be operated in manual mode or fully automatic mode.
Contact Lippert Components, Inc. to obtain replacement parts.
Rev: 09.15.20
TABLE OF CONTENTS
Page 2
2
2
3
3
4
4
4
4
5
6
6
6
6
7
9
10
10
10
11
12
13
CCD-0001531
