Summary of Contents for Lippert Components Stabilizer Jack

  • Page 1 Electric Stabilizer Jack OWNER'S MANUAL Page 1 Rev: 10.09.2017 Electric Stabilizer Jack Owners Manual...
  • Page 2: Table Of Contents

    Failure to act in accordance with the following may result in death or serious injury. The Lippert Electric Stabilizer Jack is intended for the purpose of stabilizing the coach. The use of this system for any reason other than which it is intended is prohibited by Lippert's Limited Warranty and may result in serious personal injury or death.
  • Page 3: System Description

    If the reset circuit breaker trips, retract the Electric Stabilizer until the foot pads no longer contact the ground and start again. If the ground is unlevel to the point that the stabilizer jack is being used to compensate, the coach will most likely need to be moved to accommodate the intended use of the stabilizer.
  • Page 4: System Maintenance

    Do not work on the stabilizer jack unless the battery is disconnected. Failure to act in accordance with the following may result in death or serious injury.
  • Page 5: Troubleshooting

    Disconnect one of the wire leads from the motor to prevent backfeeding the motor. Next, insert the 1/2” dia. crank handle (Fig. 3) over the coupler and pin at the end of the stabilizer jack (Fig. 2A). The slot in the end of the crank handle (Fig. 3A) accommodates the pin on the coupler (Fig.
  • Page 6 Ultra Lite Assembly with Single Spacer - Part #300625 Motor Foot Assembly Support Arm Single Spacer (Not replaceable) Ultra Lite Assembly with 2" Spacer - Part #300626 Motor Foot Assembly Support Arm 2" Spacer (Not replaceable) Page 6 Rev: 10.09.2017 Electric Stabilizer Jack Owners Manual...
  • Page 7: Electric Stabilizer Jack Components

    Callout Part # Description 387874 Waterproof Electric Stabilizer Jack Switch with Harness Waterproof Electric Stabilizer Jack Switch with Harness (OBSOLETE - Use 387874) 344484* Waterproof Electric Stabilizer Jack Switch with Harness (OBSOLETE - Use 387874) 242409* 144214 Non-Waterproof Electric Stabilizer Jack Switch with Bezel and Harness...
  • Page 8: Electric Stabilizer Jack Components

    Klauber C800 Motor 352338 Electric Stabilizer Jack Motor 119226 Jack Crank Handle 134025* Hatch Cover NOTE: (*) This part can be purchased as black or white using the same part number. Page 8 Rev: 10.09.2017 Electric Stabilizer Jack Owners Manual...
