Summary of Contents for Totem Mini Trooper

  • Page 2 Scan QR code to watch the Mini Trooper assembly video. Or search for Mini Trooper assembly video in YouTube. Tricky steps are indicated with a special sign. We recommend watching those tricky steps in the Mini Trooper assembly video, at the given time stamps.
  • Page 3 Use Beam/Bolt ruler to few extra nuts. We apolo- driver to push in the nuts. sert the nut all the way in. determine length gize for the inconvenience. beams bolts. For more tips, please visit the link below: https://totemmaker.net/blog/totem-mechanics-for-beginners/...

  • Page 4: Mechanical Part List

    2x Nylon Spacer 2x Nylon Standoff 4x Zip Tie 2x Steel Ball 2x Ball Holder 1x Flipper Part 1 1x Flipper Part 2 2x Wheel 2x N20 Motor 1x Mini Trooper Puck 1x Mini Trooper Battery 1x Mini Trooper Battery Charger...

  • Page 5: How To Control

    App Store or Google Play. Search for: Totemmaker Mini Trooper PCB - motor driver board with Bluetooth connectivity. It can control up to 4 DC motors and 2 Servo motors. up to 4 DC motors and 2 Servo motors.
  • Page 6 1x Beam 90 mm 3x Nut M3 6x10 2x 2-Hole 90 Bracket 1x 45x90 Bracket 3x Bolt M3x6...
  • Page 7 1x Beam 90 mm 5x Nut M3 6x10 3x 2-Hole 90 Bracket 3x Bolt M3x6...
  • Page 8 1x Beam 90 mm 2x Nut M3 6x10 2x Nut M3 5.5x5.5 2x 2-Hole Simple Bracket 2x 2-Hole 90 Bracket 2x Nylon Standoff 2x Bolt M3x8 Do not use much force when tightening Nylon Standoff s.
  • Page 9 1x Beam 90 mm 5x Nut M3 6x10 3x 2-Hole Simple 3x Bolt M3x6 Bracket Use Mini Screwdriver for 1x N20 Motor 1x N20 Motor Bracket these bolts. 2x Bolt M1.6x3...
  • Page 10 Step 4 assembly 2x Nut M3 6x10 2x Bolt M3x6 Mind the position of wires.
  • Page 11 1x Beam 90 mm 5x Nut M3 6x10 3x 2-Hole Simple 3x Bolt M3x6 Bracket Use the Mini Screwdriver 1x N20 Motor 1x N20 Motor Bracket for these bolts. 2x Bolt M1.6x3...
  • Page 12 Step 7 assembly 2x Nut M3 6x10 2x Bolt M3x6 Mind the position of wires.
  • Page 13 4x Bolt M3x6 Use the Hex Key for this step. Use the Hex Key for this step.
  • Page 14 Beams’ edges should align nicely. TRICKY STEP 00:14:24 To do so, loosen these 6 bolts. See the next page...
  • Page 15 After adjusting the beams’ edges, fasten the bolts again.
  • Page 16 2x Beam 40 mm 4x Nut M3 6x10 2x Bolt M3x6...
  • Page 17 2x Beam 40 mm 5x Nut M3 6x10 2x 2-Hole 90 Bracket 1x L-Twisted Bracket 5x Bolt M3x6 Mind the position of beams. Edges of beams should align nicely. Loosen the bolts and readjust brackets to do so.
  • Page 18 2x Beam 40 mm 5x Nut M3 6x10 2x 2-Hole 90 Bracket 1x L-Twisted Mirror Bracket 5x Bolt M3x6 Mind the position of beams. Edges of beams should align nicely. Loosen the bolts and readjust brackets to do so.
  • Page 19 2x Bolt M3x8 2x Nut M3 6x10...
  • Page 20 2x Bolt M3x6 2x Nut M3 6x10 1x Mini Servo Motor with Arm Make sure Servo motor arm looks up.
  • Page 21 1x Beam 90 mm 6x Nut M3 6x10 2x L-Twisted Mirror 2x L-Twisted Bracket Bracket 4x Bolt M3x6...
  • Page 22 1x Beam 90 mm 2x Nut M3 6x10 2x 2-Hole 45 Bracket 4x Bolt M3x6...
  • Page 23 2x Bolt M3x6...
  • Page 24 1x Mini Trooper Battery 1x Zip Tie...
  • Page 25 1x Mini Trooper PCB 2x Bolt M3x6...
  • Page 26 1x Flipper Part 1 1x Flipper Part 2 2x Lock Nut M3 2x Bolt M3x16 Tighten the Lock nuts just enough to get a smooth hinge rotation movement. TRICKY STEP 00:31:56...
  • Page 27 1x Beam 90 mm 4x Nut M3 6x10 2x 2-Hole Simple 2x Bolt M3x6 Bracket 1x Beam 90 mm 4x Nut M3 6x10 2x 2-Hole Simple 2x Bolt M3x6 Bracket...
  • Page 28 2x Bolt M3x8...
  • Page 29 1x Board 30x100 1x Bolt M3x6 1x L-Twisted Mirror 1x Nut M3 5.5x5.5 Bracket...
  • Page 30 4x Bolt M3x6 4x Nut M3 5.5x5.5...
  • Page 31 1x L-Twisted Bracket 1x L-Twisted Mirror Bracket 2x Bolt M3x6 Brackets hit the nuts.
  • Page 32 TRICKY STEP 2x Bolt M3x8 2x Lock Nut M3 00:41:04 Tighten the Lock Nuts just enough to get a smooth hinge rotation movement.
  • Page 33 TRICKY STEP 00:42:37 2x Bolt M3x10 2x Lock Nut M3 1x Strip Bracket Tighten the Lock Nuts just enough to get a smooth hinge rotation movement.
  • Page 34 2x Wheels 2x Nylon Spacer 2x Ball Holder 2x Steel Balls 2x Bolt M3x12...
  • Page 35 Make sure Flipper can be closed all the way down (it should be touching the bottom beam). If that is not the case, you can fi x this by adjusting this bracket. TRICKY STEP 00:46:54 Make sure Flipper is straight and equally in between the front bumpers.
  • Page 36 MINI TROOPER PCB Light Bar – to indicate the battery charge level. Changes lights when successfully connected to the app. Up to 4 DC motor channels.
  • Page 37 Suggestion how to tie the wires with Zip Tie so they do not hang messy.
  • Page 38 Leave this area empty of wires so Mini Servo Motor Arm can move here freely. Wires should go in the positions as showed.

  • Page 39: Troubleshoot

    None of the LEDs are flashing when battery is mobile application. connected. • Check if Mini Trooper PCB is powered on (LEDs should Battery voltage is low. Charge the battery. blink). • Only one device can be connected to the PCB at a time.
  • Page 40 GAMES Congratulations on fi nishing the assembly of Mini Trooper! Time to test it out. Looking for game ideas? Try these: Flipper Sumo Make a fi eld with the tape. Objective of the game is to fl ip your Try to push your opponent out of bounds.
  • Page 41 Before each game please inspect your Mini Trooper to see if everything works properly. Most common issues: • Bolts become loose because of intense usage - tighten them periodically. • Frame loses shape because of heavy contact - adjust brackets’ positions periodically.

  • Page 42: Consumer Information

    PRECAUTIONS: ELECTRONICALLY OPERATED PRODUCT Do not give this product to children aged 8 or below. As with all electronic products, precautions should be observed during handling and use to prevent electric chock. Adult supervision required. CONSUMER INFORMATION Note to adults: to ensure that the child’s play is both safe and fun, please review all operating instructions and safety rules with your child. SAFETY WARNINGS: •...

  • Page 43: Battery Charging

    KEEP THIS INTRUCTION MANUAL AND THE PRODUCT BOX AS IT CONTAIN IMPORTANT INFORMATION FOR FUTURE REFERENCE. Due to the continuous product improvement, the pictures on this manual may diff er slightly from the actual product. Please adhere to actual product instead. Totem Maker names and logos are registered trademarks. All rights reserved. www.totemmaker.net Aldrea fi...
