3. Do not use in the environment beyond the boundar-
ies of the temperature, and maintain good ventilation
to prevent the rain in order to reduce the risk of fire or
electric shock.
4. The installation and maintenance of this product
should be professional, please do not in any way to
remove or modify the equipment; can only use the
required accessories of manufacturers. Problems
caused by unauthorized repair are at your own risk.

5.2 Installation Tools and Information

Prepare the required engineering data and instruc-
tions. Before installation please prepare the following
tools and instrumentation: A straight or a
Phillips-head screwdriver,
needle nose pliers, tape measure, pencil and so on.
5.3 Installation Method
1. Check the equipment whether it is damaged.
2. Mounting bracket or base.
① If the cement wall, install the expansion screws
(expansion screw holes need stand or base hole), and
then mount bracket or base.
② If the wooden wall, use self-tapping screws to
mount.
6
multi-meter, scissors,
3. Mounting the camera
a. Dome Camera
Adjust the lens position and make it aim at the
monitoring points and present a clear picture, manual-
ly fix lens location and adjust the hemisphere cover.
Re-examine the screen whether the character meets
the requirement. Tighten the hemisphere cover.
b. Bullet Camera
Adjust the body so that the lens aims at the monitoring
points and presents a clear picture. Tighten the
screws, to ensure that it does not move.
Note:
The wall needs to bear at least
3X weight of bracket (base) and
camera.
