2.2 Product Features

● Dual Coaxial cable with BNC connenctors
● AHD/TVI/CVI/CVBS Output
● True WDR@30fps(Not Available for Analog Output)
● Motorized 2.8-12mm Vari-Focal Auto Focus Lens
● Auto Day/Night (ICR)
● Defog, HBLC, BLC
● 2D/3D Noise Reduction
● Motion Detection, Privacy Mask

3 OSD Controller

3.1 OSD Control:
Center: Enter OSD/ Enter
Up: Navigate OSD up
Down: Navigate OSD Down
Left: adjust OSD Menu values
Right: adjust OSD Menu values
3.2 Lens Cotrol:
Zoom-In: Press UP continuously
Zoom-Out: Press Down continuously
Focus-: Press Left continuously
Focus+: Press Right continuously
4

3.3 Output adjustment:

AHD: press center for 3 Second and then Right
TVI: press center for 3 Second and then Left
CVI: press center for 3 Second and then Up

4 Control Over Coaxial(CoC)

4.1 AHD/TVI:

Click on "Iris+" button from the DVR's PTZ interface to
call the OSD Menu. Use the PTZ interface to scroll
through the menu and "Iris+" to confirm.

4.2 CVI:

Click " ►" button from the DVR's PTZ interface, then
click " " and press "Enter" to call the OSD Menu.

5 Product Installation

5.1 General Notes

1. Make sure the unit is powered off before installation.
2. Check power supply voltage consistent with the
electric voltage to prevent voltage unworthy, resulting
in damage to the device.
