Parts List - Icom AT-141 Service Manual

SECTION 5
[TUNER-1 UNIT]
REF ORDER
NO. NO.
IC2 1130007570 S.IC BU4094BCFV-E2
IC3 1130007570 S.IC BU4094BCFV-E2
IC4 1130007570 S.IC BU4094BCFV-E2
IC5 1130008411 S.IC TC74A393F (EL, F)
IC6 1130007111 S.IC TC7W04FU (TE12L, F)
IC7 1110005791 S.IC S-80841CLUA-B62T2G
IC11 1160000120 S.IC PA2004GR-E2
IC12 1160000120 S.IC PA2004GR-E2
IC13 1160000120 S.IC PA2004GR-E2
IC14 1160000120 S.IC PA2004GR-E2
IC15 1140013390 S.IC MB95F108AHSPFM-GE1
IC17 1130013080 S.IC S-24CS08AFT-TB-1
IC18 1130007261 S.IC TC7W74FU (TE12, F)
IC19 1110001591 S.IC TA75393FG (EL)
IC20 1180001071 S.IC TA7805F (TE16L, Q)
Q2 1530002691 S.TR 2SC4116-GR (TE85R, F)
Q3 1590000430 S.TR DTC144EUA T106
Q4 1530002691 S.TR 2SC4116-GR (TE85R, F)
Q5 1530002691 S.TR 2SC4116-GR (TE85R, F)
Q7 1510000771 S.TR 2SA1586-GR (TE85R,F)
Q8 1530002691 S.TR 2SC4116-GR (TE85R, F)
Q11 1530002691 S.TR 2SC4116-GR (TE85R, F)
D1 1750000950 S.DIO MA732 (TX)
D2 1790000450 S.DIO MA862 (TX)
D5 1790000491 S.DIO HSM88ASTR-E
D7 1750000950 S.DIO MA732 (TX)
D8 1750000950 S.DIO MA732 (TX)
D9 1750000271 S.DIO 1SS301 (TE85R, F)
D11 1750000950 S.DIO MA732 (TX)
D12 1750000950 S.DIO MA732 (TX)
D13 1750000950 S.DIO MA732 (TX)
D14 1750000950 S.DIO MA732 (TX)
D16 1750000271 S.DIO 1SS301 (TE85R, F)
D17 1750000271 S.DIO 1SS301 (TE85R, F)
D22 1790001250 S.DIO MA2S111-(TX)
D52 1750000271 S.DIO 1SS301 (TE85R, F)
D53 1750000271 S.DIO 1SS301 (TE85R, F)
D54 1750000271 S.DIO 1SS301 (TE85R, F)
D55 1750000271 S.DIO 1SS301 (TE85R, F)
D56 1750000271 S.DIO 1SS301 (TE85R, F)
D57 1750000271 S.DIO 1SS301 (TE85R, F)
D58 1750000271 S.DIO 1SS301 (TE85R, F)
D59 1750000271 S.DIO 1SS301 (TE85R, F)
D60 1750000271 S.DIO 1SS301 (TE85R, F)
D61 1750000271 S.DIO 1SS301 (TE85R, F)
D62 1750000271 S.DIO 1SS301 (TE85R, F)
D63 1750000271 S.DIO 1SS301 (TE85R, F)
D64 1750000271 S.DIO 1SS301 (TE85R, F)
D65 1750000271 S.DIO 1SS301 (TE85R, F)
D66 1750000271 S.DIO 1SS301 (TE85R, F)
D67 1750000271 S.DIO 1SS301 (TE85R, F)
D68 1750000271 S.DIO 1SS301 (TE85R, F)
D69 1750000271 S.DIO 1SS301 (TE85R, F)
D70 1750000271 S.DIO 1SS301 (TE85R, F)
D71 1750000271 S.DIO 1SS301 (TE85R, F)
D72 1750000271 S.DIO 1SS301 (TE85R, F)
D73 1750000271 S.DIO 1SS301 (TE85R, F)
D74 1750000271 S.DIO 1SS301 (TE85R, F)
D75 1750000271 S.DIO 1SS301 (TE85R, F)
D76 1750000271 S.DIO 1SS301 (TE85R, F)
D77 1790000491 S.DIO HSM88ASTR-E
D78 1790001250 S.DIO MA2S111-(TX)
D79 1790001250 S.DIO MA2S111-(TX)
D80 1790000491 S.DIO HSM88ASTR-E
D81 1750000431 S.DIO HSB88WSTR-E
D85 1750000271 S.DIO 1SS301 (TE85R, F)
D86 1750000950 S.DIO MA732 (TX)
X1 6050009870 S.XTL CR-567 (9.8304 MHz)
L1 6140003490 COL LR-391
L2 6140000930 COL LR-116
L3 6140000930 COL LR-116
L4 6140000070 COL LR-19
L5 6200011630 S.COL NL565050T-222J-PF
L6 6110002750 COL LA-459
L7 6110002760 COL LA-460
L8 6110002770 COL LA-461
L9 6110002780 COL LA-462
L10 6110002790 COL LA-463

PARTS LIST

DESCRIPTION M.
LOCATION
T 64.3/127.9
T 64.3/147.1
T 64.3/166.2
T 30.6/128.3
T 31.3/162.1
T 30.9/174
T 104/130
T 104/145.4
T 104/160.1
T 104/174.9
T 38.9/151
T 47.8/135.8
T 31.3/168.2
T 27.4/43.5
T 13.4/150
T 32.5/68.5
T 27.2/27.2
T 46.7/25.2
T 43.5/25.2
T 25/178.6
T 37.6/175.1
T 48.7/127.1
T 41.1/91
T 38.8/69.1
T 46/58.3
T 37.7/62.7
T 39.6/62.7
T 27.5/36.3
T 30.9/26.1
T 30.9/28
T 33.4/18.8
T 31.5/18.8
T 107.3/91.4
T 102/8.3
T 34.1/176.3
T 98.5/30.2
T 252.4/58.2
T 113/39.9
T 127.6/36.6
T 142.7/41.6
T 157.1/42.5
T 167.7/43.1
T 185/35.1
T 199.4/37.6
T 231.7/56.6
T 253.4/53.5
T 272.4/37
T 275/37
T 113/90
T 131.1/90.2
T 143.8/90.3
T 156.8/90.2
T 169.4/90.2
T 181.7/90.2
T 194/90.4
T 206.6/90.2
T 218.8/90.3
T 193.3/136.7
T 193.4/156.3
T 193.3/176.7
T 36.1/41.8
T 25/171.7
T 43.4/126.9
T 155/179.4
T 44.4/42.4
T 27.7/72.7
T 210.2/188.2
T 26.6/143.7
T
[TUNER-1 UNIT]
H/V REF ORDER
NO. NO.
L11 6110002800 COL
L12 6110002810 COL
L13 6110002820 COL
L14 6110002830 COL
L15 6110002840 COL
L16 6110002850 COL
L17 6110002860 COL
L18 6200003261 S.COL NLV32T-101J
L20 6200008820 S.COL HF70ACC 635050-T
L22 6200008820 S.COL HF70ACC 635050-T
L24 6200003261 S.COL NLV32T-101J
L25 6200003261 S.COL NLV32T-101J
L28 6200003261 S.COL NLV32T-101J
L31 6200011610 S.COL NLC453232T-100K-PF
L32 6200001831 S.COL NLV32T-100J
L33 6200011620 S.COL NLC453232T-470K-PF
L34 6200008820 S.COL HF70ACC 635050-T
L35 6140001550 COL
L36 6200003950 S.COL HF50ACC 322513-T
L37 6200003950 S.COL HF50ACC 322513-T
R1 7030003440 S.RES ERJ3GEYJ 102 V (1 k)
R2 7030007190 S.RES ERJ12YJ220U (22)
R3 7030007190 S.RES ERJ12YJ220U (22)
R8 7030003560 S.RES ERJ3GEYJ 103 V (10 k)
R9 7030003590 S.RES ERJ3GEYJ 183 V (18 k)
R10 7030003640 S.RES ERJ3GEYJ 473 V (47 k)
R11 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k)
R12 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k)
R13 7030006270 S.RES ERJ12YJ221U (220)
R14 7030003200 S.RES ERJ3GEYJ 100 V (10)
R15 7030003560 S.RES ERJ3GEYJ 103 V (10 k)
R16 7070000731 RES
R17 7070000731 RES
R18 7070000721 RES
R19 7070000291 RES
R20 7070000291 RES
R21 7070000291 RES
R22 7030011300 S.RES ERJ1TY 331U (330)
R23 7030011300 S.RES ERJ1TY 331U (330)
R24 7030011310 S.RES ERJ1TY 271U (270)
R25 7030003640 S.RES ERJ3GEYJ 473 V (47 k)
R26 7030003640 S.RES ERJ3GEYJ 473 V (47 k)
R27 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k)
R28 7030006220 S.RES ERJ12YJ470U (47)
R29 7030006220 S.RES ERJ12YJ470U (47)
R30 7030006220 S.RES ERJ12YJ470U (47)
R31 7030006220 S.RES ERJ12YJ470U (47)
R32 7030003280 S.RES ERJ3GEYJ 470 V (47)
R33 7030003720 S.RES ERJ3GEYJ 224 V (220 k)
R34 7030003720 S.RES ERJ3GEYJ 224 V (220 k)
R35 7030003650 S.RES ERJ3GEYJ 563 V (56 k)
R36 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k)
R37 7030003640 S.RES ERJ3GEYJ 473 V (47 k)
R38 7030003440 S.RES ERJ3GEYJ 102 V (1 k)
R39 7030003560 S.RES ERJ3GEYJ 103 V (10 k)
R40 7030003560 S.RES ERJ3GEYJ 103 V (10 k)
R41 7030003560 S.RES ERJ3GEYJ 103 V (10 k)
R42 7030003440 S.RES ERJ3GEYJ 102 V (1 k)
R43 7030007990 S.RES ERJ12YJ820U (82)
R44 7030003360 S.RES ERJ3GEYJ 221 V (220)
R45 7540000250 ABS
R46 7030007980 S.RES ERJ12YJ473U (47 k)
R51 7030007240 S.RES ERJ12YJ680U (68)
R52 7030007240 S.RES ERJ12YJ680U (68)
R53 7030003640 S.RES ERJ3GEYJ 473 V (47 k)
R54 7030003370 S.RES ERJ3GEYJ 271 V (270)
R55 7030010610 S.RES ERJ1TYJ 470U (47)
R56 7030003600 S.RES ERJ3GEYJ 223 V (22 k)
R57 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R58 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k)
R59 7030003580 S.RES ERJ3GEYJ 153 V (15 k)
R66 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R67 7030003640 S.RES ERJ3GEYJ 473 V (47 k)
R71 7030003440 S.RES ERJ3GEYJ 102 V (1 k)
R72 7030003440 S.RES ERJ3GEYJ 102 V (1 k)
R73 7030003440 S.RES ERJ3GEYJ 102 V (1 k)
R74 7030003440 S.RES ERJ3GEYJ 102 V (1 k)
R76 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
47/20
R77 7030003720 S.RES ERJ3GEYJ 224 V (220 k)
R78 7030005631 S.RES ERA3YKD 154V (150 k)
R84 7030003400 S.RES ERJ3GEYJ 471 V (470)
R85 7030003400 S.RES ERJ3GEYJ 471 V (470)
R86 7030003400 S.RES ERJ3GEYJ 471 V (470)
R87 7030003400 S.RES ERJ3GEYJ 471 V (470)
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
B - 5 - 1
