SECTION 4 ADJUSTMENT PROCEDURES
4-1 PREPARATION
■ REQUIRED TEST EQUIPMENT
EQUIPMENT
DC power supply
Oscilloscope
• CONNECTION
GRADE AND RANGE
Output voltage
: Depended on connected transceiver
Current capacity
: Depended on connected transceiver
Frequency range
: DC–20 MHz
Measuring range
: 0.01–10 V
AT-141
Antenna receptacle
Control receptacle
IC-M801E
B - 4 - 1
DC power supply
+
–
