SECTION 6
[CHASSIS PARTS]
REF. ORDER
NO. NO.
W501 8900011380 Cable OPC-1146
W502 8900011400 Cable OPC-1164
EP501 6910000880 Sheet NC-1 (SUS)
EP502 6910000880 Sheet NC-1 (SUS)
MP501 8310006540 High voltage waring seal
MP502 8010019030 1157 U-case
MP503 8010019020 1157 L-case
MP504 8930006900 Mounting plate
MP505 8930006540 Waterproof seal
MP506 8930002800 O ring (G)
MP507 8930006550 Sealing washer (A)
MP508 8930006560 Sealing washer (C)
MP509 8930006570 Sealing washer (D)
MP510 6910000470 Pair insulator
MP512 8310066500 Caution seal (P)
MP517 8810000620 Screw PH M3 × 13 SUS
MP518 8830000230 Nut M3 SUS
MP519 8810003480 Hex head bolt M5 × 60 SUS
MP520 8860000160 Earth lug B8 (M5) AG BS
MP521 8850000500 Spring washer M5 SUS
MP522 8850000180 Flat washer M5 SUS
MP523 8830000250 Nut M5 SUS
MP524 8860000190 Earth lug (M5) AG BS
MP525 8850000600 Gear Washer M5 SUS
MP526 8830000370 Wing nut M5 SUS
MP527 8810003470 Hex head bolt M5 × 20 SUS
MP528 8860000160 Earth lug B8 (M5) AG BS
MP529 8850000500 Spring washer M5 SUS
MP530 8850000180 Flat washer M5 SUS
MP531 8830000250 Nut M5 SUS
MP532 8860000190 Earth lug D5 (M5) AG BS
MP533 8850000600 Gear Washer M5 SUS
MP534 8830000370 Wing nut M5 SUS
MP535 8810002800 Screw PH M5 × 10 SUS
MP536 8810000660 Screw PH M4 × 14 SUS
MP537 8810001480 Screw PH A M5 × 10 SUS
MP538 8810001691 Screw PH B0 3 × 8 (PL)
MP539 8830000240 Nut M4 SUS
MP541 8930006570 Sealing washer (D)
MP544 8930006570 Sealing washer (D)
MP551 8950001980 Cable tie-140
MP552 6910014570 Super ground (FGA13-08B)
MP553 6910014570 Super ground (FGA13-08B)
Screw abbreviations A,B0,B1: Self-tapping
PH: Pan head
NI: Nickel

MECHANICAL PARTS AND DISASSEMBLY

DESCRIPTION QTY.
BS: Brass
SUS: Stainless
[TUNER-1 UNIT]
REF. ORDER
NO. NO.
1 MP3 8510001101
1 MP4 8510001081
MP6 8510003500
1 MP7 8510002020
1 MP11 8510003500
MP12 8510003510
1 MP22 8510003500
1 MP23 8510003510
1
2
[ACCESSORIES]
1
2
REF. ORDER
NO. NO.
1
1
W701 8900004200
4
1
J701 6510002030
1
1
P702 6510001930
1
1
MP701 8820000440
1
MP702 8010000010
1
MP703 8830000260
1
MP704 8850000510
1
MP705 8850000190
1
MP706 8810001500
1
MP707 8810003500
1
MP708 8850000200
1
MP711 6950000010
1
1
1
1
1
MP701
1
1
4
MP702
10
2
9
MP708
10
1
MP705
1
1
MP704
1
MP703
1
W701
B - 6 - 1
DESCRIPTION
Shied case (A) cover (A)-1
Shield case (A)-1
406 shield case
MIX shield case
406 shield case
406 shield case cover
406 shield case
406 shield case cover
DESCRIPTION
Cable OPC-412
Connector 1380T
1490P1
U-bolt A SUS
U-bolt plate
Nut M6 SUS
Spring washer M6 SUS
Flat washer M6 SUS
Screw PH A M6 × 30 SUS
Hex head bolt M6 × 50 SUS
Flat washer M6 SUS
Waterproof cap
MP711
P702 J701
QTY.
1
1
1
1
1
1
1
1
QTY.
1
4
1
2
2
8
8
4
4
4
8
1
MP707
MP706
