Tumble Dryer
AD-35i / AD-50i / AD-80i
EN – Installation/Operator Manual
GB, IE
To avoid errors and damage to the dryer,
please read these instructions carefully
before attempting to install or operate
American Dryer Corporation
88 Currant Road
Fall River MA 02720-4781 USA
Telephone: +1 (508) 678-9000 / Fax: +1 (508) 678-9447
e-mail: techsupport@amdry.com
www.adclaundry.com
ADC Part No. 113576- 1
Advertisement
Table of Contents
Related Manuals for American Dryer Corp. AD-35i
Summary of Contents for American Dryer Corp. AD-35i
- Page 1 Tumble Dryer AD-35i / AD-50i / AD-80i EN – Installation/Operator Manual GB, IE To avoid errors and damage to the dryer, please read these instructions carefully before attempting to install or operate American Dryer Corporation 88 Currant Road Fall River MA 02720-4781 USA Telephone: +1 (508) 678-9000 / Fax: +1 (508) 678-9447 e-mail: techsupport@amdry.com...
-
Page 2: Table Of Contents
Safety Precautions ______________ Do not store or use gasoline or other flammable liquids or vapors in the vicinity of this appliance. Only qualified personnel should install, service, A qualified technician must be called if any high-limit thermostat or adjust this equipment. trips to investigate, and resolve, the issue. - Page 3 This Page Is Intentionally Left Blank 113576 - 1 www.adclaundry.com...
-
Page 4: Technical Specifications
Technical Specifications AD-35i AD-50i AD-80i Maximum Capacity (Dry Weight) 15.9 22.7 36.3 Tumbler Volume liters Tumbler (Diameter x Depth) 76.2 x 74.6 83.2 x 95.3 94.0 x 90.0 Door Opening (Diameter) 54.6 68.6 79.7 Airflow (50Hz) 22.9 24.9 Heat Rate (Gas) 20.5... - Page 5 113576 - 1 www.adclaundry.com...
-
Page 6: Installation Procedures
Installation Procedures __________________ Clearance to nearest obstacle Location Requirements Open door: AD-35i: 84 cm, AD-50i: 91 cm, AD-80i: 102 cm The temperature of the installation location must remain between 4° C and 55° C. 2.5 cm (To allow control door to open) The dryer must not be installed or stored in an area where it 2.5 cm... - Page 7 Single Dryer Venting (50Hz) Multiple Dryer Venting AD-35i AD-50i AD-80i A (mm) B (mm) Multiple Dryer Venting - Through an End Wall C (mm) D (mm) E (mm) F (mm) L1+L2 (m) Multiple Dryer Venting - Through Roof or Rear Wall...
-
Page 8: Electrical Information (50Hz)
Multiple Dryer Venting – Through Roof or Rear Wall (5x 90° Turns) Electrical Information (50Hz) ___ Gas and Steam Heated Dryers Single-Phase Connection Electric installation must be performed by qualified personnel in accordance with national and local safety regulations. The dryer must be electrically earthed (grounded) in accordance with national and local codes. - Page 9 Three-Phase Connection Electrical Specifications (50Hz) – Gas and Steam Models AD-35i AD-50i AD-80i —— —— —— 220-240V 1~ 220-240V 3~ 380-416V 3~ Electrical Specifications (50Hz) – Electric Models Oven AD-35i Amps —— (kW) 220V 1~ 11.3 58.0 230V 1~ 12.4 60.5...
-
Page 10: Gas Information
Gas Information _________________ • Disconnect electrical power to the dryer. • Close all external gas supply shutoff valves. Gas installation should be performed by qualified personnel in accordance with national and local • Disconnect the gas supply line. safety regulations. •... -
Page 11: Gas Type Conversion
AU and NZ Gas Specifications * ADG-35i * ADG-50i * ADG-80i Characteristics 1 Injector 1 Injector 1 Injector Supply Burner Injector Burner Injector Burner Injector Pressure Pressure Rate Size Pressure Rate Size Pressure Rate Size Type 1.7 - 3.2 0.90 1.98 3.988 0.83... -
Page 12: Steam Information
3. Back out the miniature screw inside the outlet pressure The steam supply connection into the main supply line must tap (“out P”) (G). be made with a minimum 25 cm riser. This will prevent any condensate from draining towards the dryer. 4. - Page 13 AD-50i 1. Steam Coil 8. Drop 2. Vacuum Breaker 9. Dirt Leg 3. Solenoid Valve 10. Drip Trap 4. Flexible Hose or Coupling 11. Check Valve 5. Riser 12. Inverted Bucket Steam Trap 13. Return Main 6. Strainer 7. Manual Shutoff Valve 14.
-
Page 14: Water Information
Water Information _______________ Start-Up ___________________________________ Water installation should be performed by qualified Check: personnel in accordance with national and local • Gas dryers – All shutoff valves should be open. safety regulations. • All back panels (guards) should be in position. If the water system activates then you must have the dryer •... -
Page 15: Routine Maintenance
Data Label Information ___________________ Routine Maintenance _____________________ A schedule should be established for the periodic inspection, When contacting ADC, certain information is required to ensure cleaning, and lint removal. The frequency of cleaning can best proper service/parts information from ADC. This information is be determined from experience at each location. -
Page 16: Non-Coin Programming
Non-Coin Programming ___________________ SAIL SWITCH OPEN FAULT – Sail switch remained open after the cycle started. Should have closed. BURNER HIGH LIMIT FAULT – Burner temp. disk has opened. BURNER IGNITION CONTROL – No signal to gas valve from (DSI) module during trial for ignition time. DSI module is bad. IGNITION FAULT –... -
Page 17: Coin Programming
Coin Programming ________________________ Accessing and Clearing Coin Vault Total Enter program mode by switching program switch (up) while Enter Programming Mode By Placing no cycle is in progress. The Programming Switch On The Phase 7 Board Up While No Cycle Is In Progress. Press HI –... -
Page 18: Warranty Information
Warranty Information _____________________ This product embodies advanced concepts in engineering, design, and safety. If this product is properly maintained, it will For any warranty-related issues, please contact our Warranty provide many years of safe, efficient, and trouble-free operation. Department at +1 (508) 678-9000. We have tried to make this manual as complete as possible If you need a copy of the warranty covering your dryer please and hope that you will find it useful.
