- Page 1 SUPER AD-30 Parts Manual 24 VAC Phase 5 1994 thru 2000 Telephone: (508) 678-9000 / Fax: (508) 678-9447 091701WM/mcronan MODELS: ADG-30DS ADE-30S ADS-30S American Dryer Corporation 88 Currant Road Fall River, MA 02720-4781 E-mail: techsupport@amdry.com www.amdry.com ADC Part No. 450144...
- Page 2 Retain This Manual In A Safe Place For Future Reference American Dryer Corporation products embody advanced concepts in engineering, design, and safety. If this product is properly maintained, it will provide many years of safe, efficient, and trouble-free operation. ONLY qualified technicians should service this equipment. OBSERVE ALL SAFETY PRECAUTIONS displayed on the equipment or specified in the installation/operator's manual included with the dryer.
-
Page 3: Table Of Contents
Table of Contents Control Door Assembly Without Trim ... 3 High Security Control Door Assembly ... 4 Phase 5 Coin Microprocessor Control Panel Assembly ... 5 Phase 5 OPL Microprocessor Control Panel Assembly ... 6 Phase 5 OPL and Coin Microprocessor Control Box Assembly ... 7 Coin Vault Assembly ... - Page 4 Plastic Door Front Panel Assembly ... 26 Basket (Tumbler)/Support Assemblies ... 27 Basket (Tumbler) Bearing Assembly ... 28, 29 Idler Bearing Assembly ... 30, 31 Non-Reversing Totally Enclosed, Fan-Cooled (T.E.F.C.) Motor Mount Assembly ... 32, 33 Reversing Totally Enclosed, Fan-Cooled (T.E.F.C.) Motor Mount Assembly ... 34, 35 Sensor Bracket Assemblies ...
-
Page 5: Control Door Assembly Without Trim
Control Door Assembly Without Trim For OPL (Non-Coin) Models Mfd. as of July 19, 1999 Illus. No. Part No. Qty. Description 881053 ADC Logo ONLY (with double adhesive tape) 870011 Logo Double Adhesive Tape Kit ONLY 883097* Control Door (includes illus. nos. 2 and 3) 883120 Stainless Steel Control Door (includes illus. -
Page 6: High Security Control Door Assembly
For ALL Coin Models and ONLY OPL Models Mfd. prior to July 19, 1999 Illus. No. Part No. Qty. Description 160015 High Security MK-100 Lock Assembly with Key (for Coin Models Only) 160104 MK-100 Key ONLY 160017 Special Dummy Lock ONLY (for Non-Coin Models Only) 160016 Lock Cam ONLY... -
Page 7: Phase 5 Coin Microprocessor Control Panel Assembly
Phase 5 Coin Microprocessor Control Panel Assembly Illus. No. Part No. Qty. Description 112526 Coin Keyboard Label Assembly 801213 Phase 5 Coin Control Panel Assembly (includes illus. nos. 1, 2, 4 through 6, and 11) 801229 Phase 5 Coin Control Panel Assembly with Battery Option (includes illus. -
Page 8: Phase 5 Opl Microprocessor Control Panel Assembly
Phase 5 OPL Microprocessor Control Panel Assembly Illus. No. Part No. Qty. Description 112535 OPL English Keyboard Label Assembly 112276 OPL Stick-on Labels (English Only)...Not Illustrated 112275 OPL Stick-on Labels (Spanish, Italian, and Hebrew)...Not Illustrated 112277 3-Language OPL Stick-on Labels (English, Spanish, and Hebrew)...Not Illustrated 112278 5-Language OPL Stick-on Labels... -
Page 9: Phase 5 Opl And Coin Microprocessor Control Box Assembly
Phase 5 OPL and Coin Microprocessor Control Box Assembly Illus. No. Part No. Qty. Description --------- Transformer - 24 VAC (refer to Transformer Usage Listings on page 53 and page 54) 150300 #10 x 1/2" Hex Washer TEK Screw 120715 30-Position Terminal Block 150002 #6-32 x 1"... -
Page 10: Coin Vault Assembly
Illus. No. Part No. Qty. Description 802112 Microprocessor Coin Vault Assembly Complete (includes illus. nos. 1 through 6) 802117 Microprocessor Coin Vault ONLY 802110 Non-Microprocessor Coin Vault Assembly Complete (includes illus. nos. 1 through 6) 802115 Non-Microprocessor Coin Vault ONLY 160006 Cam for 1/4 Turn Lock ONLY 875061... -
Page 11: Dual Timer "Tap Touch" Controls
Dual Timer “Tap Touch” Controls For Models Mfd. as of November 1, 2000 Illus. No. Part No. Qty. Description 824298 15 Minute Timer - 24 VAC 824299 60 Minute Timer - 24 VAC 824175 Red Pilot Light - 24 VAC 122301 “Tap Touch”... -
Page 12: Dual Timer Control Panel Assembly
Illus. No. Part No. Qty. Description 123005 Red Indicator Light - 24 VAC 122400 Rocker Heat Selector Switch 824015 Dual Timer Control Panel Assembly Complete - 24 VAC (includes illus. nos. 1 through 21) 800051 Dual Timer Control Panel ONLY 131917 Push-to-Start Relay - 24 VAC 150207... -
Page 13: Dual Timer Control Box Assembly
Dual Timer Control Box Assembly Illus. No. Part No. Qty. Description 122603 9-Pin Socket Connector 122701 Socket Terminal ONLY 122801 Pin/Socket Extraction Tool 315010 9-Pin Connector Bracket 150300 #10 x 1/2" Hex Washer TEK Screw 150300 #10 x 1/2" Hex Washer TEK Screw --------- Transformer - 24 VAC (refer to Transformer Usage Listings on page 53 and page 54) -
Page 14: Non-Microprocessor Coin Meter Control Panel Assembly
Non-Microprocessor Coin Meter Control Panel Assembly Illus. No. Part No. Qty. Description 123005 Red Indicator Light - 24 VAC 122400 Rocker Heat Selector Switch 824020 Coin Meter Control Panel Assembly Complete - 24 VAC (includes illus. nos. 1 through 6 and 8 through 12) 800054 Coin Meter Control Panel ONLY 131917... -
Page 15: Non-Microprocessor Coin Meter Control Box Assembly
Non-Microprocessor Coin Meter Control Box Assembly Illus. No. Part No. Qty. Description 122603 9-Pin Socket Connector 122701 Socket Terminal ONLY 122801 Pin/Socket Extraction Tool 315010 9-Pin Connector Bracket 150300 #10 x 1/2" Hex Washer TEK Screw 150300 #10 x 1/2" Hex Washer TEK Screw --------- Transformer - 24 VAC (refer to Transformer Usage Listings on page 53 and page 54) -
Page 16: Slide Meter Case Assembly
Illus. No. Part No. Qty. Description 160199 Key ONLY for Slide Meter Lock 160099 Lock/Key/Cam and Hardware 125908 Slide Meter Accumulator - 24 VAC 152014 1/4-20 Free Spin Wash Nut 125900 Slide Meter Case ONLY with Door Less Locks 154203 1/4"... -
Page 17: Slide Meter Control Box
Slide Meter Control Box Illus. No. Part No. Qty. Description 132451 2-Pole Contactor - 24 VAC 150299 #10 x 1" Hex Head Screw 824828 RC Network with Connectors 150300 #10 x 1/2" Hex Washer TEK Screw --------- 24 VAC Control Voltage Transformer (refer to Transformer Usage Listings on page 53 and page 54) 136057 1/2 Amp (Slo-Blo) Fuse... -
Page 18: Coin Meter Replacement Parts
Illus. No. Part No. Qty. Description 125541 1/60 RPM - 60 Hz Meter Motor - 24 VAC 125540 1/30 RPM - 50 Hz Meter Motor - 24 VAC 125500 2-Point Cam 125501 3-Point Cam 125502 4-Point Cam 125503 5-Point Cam 125504 6-Point Cam 125506... -
Page 19: Lint Trap Assembly
Lint Trap Assembly Illus. No. Part No. Qty. Description 880914 Lint Trap Assembly Complete (includes illus. nos. 1 and 3 through 5) 880913 Lint Trap ONLY 154200 5/32" Pop Rivet 150300 #10 x 1/2" Hex Washer TEK Screw 304100 Lint Screen Hold Down 800500 Lint Screen ONLY 150419... -
Page 20: Drop Lint Door Assembly Without Trim
Illus. No. Part. No. Qty. Description 800150 Knob Latch Kit Assembly (includes illus. nos. 1 and 2) 160001 AD-100 Lock Assembly with Key (for coin models Only) 160103 AD-100 Key ONLY 160003 Dummy Lock ONLY (for non-coin models) 160104 MK-100 Key ONLY (for dummy lock) 160008 Lock Cam For AD-100 and Dummy Lock... -
Page 21: Drop Lint Door Assembly
Drop Lint Door Assembly For ALL Coin Models and ONLY OPL Models Mfd. prior to July 19, 1999 Telephone: (508) 678-9000 Fax: (508) 678-9447... -
Page 22: Drop Lint Door Assembly
Illus. No. Part No. Qty. Description 160001 AD-100 Lock Assembly with Key 160103 AD-100 Key ONLY 800150 Knob Latch Kit Assembly (for non-coin models Only) (includes illus. nos. 1 and 2) 160003 Dummy Lock ONLY (for non-coin models Only) 160104 MK-100 Key ONLY 160008 Lock Cam for AD-100 Lock... -
Page 23: Main Door "Steel" Assembly
Main Door "Steel" Assembly For OPL Models ONLY Mfd. as of November 3, 2000 Illus. No. Part No. Qty. Description 881150 Black Main Door Assembly Complete (includes illus. nos. 1, 2, and 8 through 15) 102354 Door Gasket 170730 Clear Glass Adhesive (10.3 oz. cartridge) 170731 Black Glass Adhesive (10.3 oz. -
Page 24: Plastic Main Door Assembly
Illus. No. Part No. Qty. Description 881421 Gray Plastic Main Door Assembly Complete with Mechanical Fasteners (includes illus. nos. 1 and 5 through 9) 800448 12-1/2" Stainless Steel Main Door Hinge Assembly 150410 #10-24 x 3/8" Phillips Pan Head Taptite Screw 152014 1/4-20 Free Spin Wash Nut 102349... -
Page 25: Main Door Switch Assembly Cold Rolled Steel (Crs) Door
Main Door Switch Assembly Cold Rolled Steel (CRS) Door For OPL Models ONLY Mfd. as of November 3, 2000 Illus. No. Part No. Qty. Description 153566 #6-32 x 7/8" Clinch Stud 152013 #6-32 Hex Nut 1/4" ATF Zinc Plated 153010 #6 Star Washer 137005 Single-Pole Door Switch (SDS) -
Page 26: Plastic Main Door Switch Assembly
Illus. No. Part No. Qty. Description 152013 #6-32 Hex Nut 153008 #6 Lock Washer 137005 Single Pole Door Switch 121028 Insulated Female Terminal 154281 3/8" Standard Nylon Spacers 800448 12-1/2" Stainless Steel Main Door Hinge Assembly (includes illus. nos. 6 and 7) 153565 #6 Stud 881246... -
Page 27: Cold Rolled Steel (Crs) Door Front Panel
Cold Rolled Steel (CRS) Door Front Panel For OPL Models ONLY Mfd. as of November 3, 2000 Illus. No. Part No. Qty. Description 881268* Right Hand Front Panel Assembly (CRS door) (includes illus. nos. 1 through 3) 881287 Stainless Steel Front Panel Assembly (CRS door) (includes illus. -
Page 28: Plastic Door Front Panel Assembly
Illus. No. Part No. Qty. Description 875300* Right Hand Insulated Front Panel Assembly (Latch Type) Complete (includes illus. nos. 1 through 3 and 6) 875311 Stainless Steel Right Hand Insulated Front Panel Assembly (Latch Type) Complete (includes illus. nos. 1 through 3 and 5) 154215 1/8"... -
Page 29: Basket (Tumbler)/Support Assemblies
Basket (Tumbler)/Support Assemblies Illus. No. Part No. Qty. Description 800703 Basket (Tumbler) ONLY (without Felt Collar) 800803 Non-Reversing Basket (Tumbler) and Support Assembly (includes illus. nos. 1 through 10) 800813 Reversing Basket (Tumbler) and Support Assembly (includes illus. nos. 1 through 10) 150309 #10-16 x 1/2"... -
Page 30: Basket (Tumbler) Bearing Assembly
Basket (Tumbler) Bearing Assembly American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781... -
Page 31: Basket (Tumbler) Bearing Assembly
Basket (Tumbler) Bearing Assembly Illus. No. Part No. Qty. Description 880203 1-3/8" Flange Bearing 153005 3/8" Lock Washer 152005 3/8-16 Hex Nut 150508 3/8-16 x 3/4" Hex Head Machine Bolt 153005 3/8" Lock Washer 152005 3/8-16 Hex Nut 150600 3/8-16 x 1-1/2" Hex Head Machine Bolt 153004 3/8"... -
Page 32: Idler Bearing Assembly
Idler Bearing Assembly American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781... -
Page 33: Idler Bearing Assembly
Idler Bearing Assembly Illus. No. Part No. Qty. Description 100107 5L-670 V-Belt (idler to basket [tumbler]) (for Non-Reversing models Only) (for models mfd. as of November 21, 1997) 100108 5L-680 V-Belt (idler to basket [tumbler]) (for Non-Reversing models Only) (for models mfd. between October 27, 1997 and November 21, 1997) 100106 5L-690 V-Belt (idler to basket [tumbler]) (for Reversing models Only) -
Page 34: Non-Reversing Totally Enclosed, Fan-Cooled (T.e.f.c.) Motor Mount Assembly
Non-Reversing Totally Enclosed, Fan-Cooled (T.E.F.C.) Motor Mount Assembly American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781... -
Page 35: Non-Reversing Totally Enclosed, Fan-Cooled (T.e.f.c.) Motor Mount Assembly
Non-Reversing Totally Enclosed, Fan-Cooled (T.E.F.C.) Motor Mount Assembly Illus. No. Part No. Qty. Description 100110 4L-500 V-Belt (motor to idler assembly) 60 Hz ONLY 100103 4L-510 V-Belt (motor to idler assembly) 50 Hz ONLY 100701 3/16" x 3/16" x 1" Key 101132 5/8"... - Page 36 Reversing Totally Enclosed, Fan-Cooled (T.E.F.C.) Motor Mount Assembly American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781...
-
Page 37: Reversing Totally Enclosed, Fan-Cooled (T.e.f.c.) Motor Mount Assembly
Reversing Totally Enclosed, Fan-Cooled (T.E.F.C.) Motor Mount Assembly Illus. No. Part No. Qty. Description 100109 4L-650 V-Belt (motor to idler assembly) (for models mfd. as of October 27, 1997) 100117 4L-620 V-Belt (motor to idler assembly) (for models mfd. prior to October 27, 1997) 100701 3/16"... -
Page 38: Sensor Bracket Assemblies
Non-Computer Sensor Bracket Assembly Illus. No. Part No. Qty. Description 880251 1/4" Temperature Sensor Probe Assembly (includes illus. nos. 1 and 5 through 8) 130103 225° Large Automatic Reset Thermostat 153010 #6 Star Washer 152000 #6-32 Hex Nut 121028 Insulated Terminal ONLY 122701 Socket Terminal ONLY 122605... -
Page 39: Sensor Bracket Assemblies
Sensor Bracket Assemblies (continued) Illus. No. Part No. Qty. Description 130100 150° Large Thermostat (for models mfd. as of August 1, 1993) 130103 225° Large Automatic Thermostat (for models mfd. prior to August 1, 1993) 130103 225° Large Automatic Reset Thermostat (for ALL models mfd. -
Page 40: Direct Spark Ignition (Dsi) Burner Assembly
Direct Spark Ignition (DSI) Burner Assembly American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781... -
Page 41: Direct Spark Ignition (Dsi) Burner Assembly
Direct Spark Ignition (DSI) Burner Assembly Illus. No. Part No. Qty. Description 318030 DSI (Direct Spark Ignition) Burner Shield 150300 #10 x 1/2" Hex Washer TEK Screw 150309 #10-16 x 1/2" Hex Head TEK Crimptite Screw 128915 DSI Ignitor/Flame-Probe Assembly 880134 Ignitor/Flame-Probe Kit Assembly (includes illus. -
Page 42: Electric Oven Assembly
Electric Oven Assembly ELECTRIC OVEN (FRONT VIEW) ELECTRIC OVEN (REAR VIEW) American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781... -
Page 43: Electric Oven Assembly
Electric Oven Assembly Illus. No. Part No. Qty. Description 803007* Large Electric Oven Box ONLY ---------* Electric Oven Assembly Complete ---------* Electric Element 150300 #10 x 1/2" Hex Washer TEK Screw 802800 Sail Switch Box with Cover and Bracket ONLY 802801 Sail Switch Box Assembly Complete (includes illus. -
Page 44: Single-Phase (3Ø) Motor, Electric Relay Panel Assembly
Single-Phase (1ø) Motor, Electric Relay Panel Assembly Illus. No. Part No. Qty. Description 132451 2-Pole Contactor - 24 VAC 150299 #10 x 1" Hex Head Screw 824828 RC Network with Connectors (for microprocessor [computer] controlled models Only) 322809 Back Electrical Box Cover...Not Illustrated 150301 #8-18 x 7/16"... -
Page 45: 3-Phase (3Ø) Motor, Electric Relay Panel Assembly
3-Phase (3ø) Motor, Electric Relay Panel Assembly Illus. No. Part No. Qty. Description 322812 Back Electrical Box Component Plate 132430 Impellor Contactor - 24 VAC (208/230/240v - 50/60 Hz ) 132432 Impellor Contactor Replacement Coil - 24 VAC (208/230/240v - 50/60 Hz) 150103 #8-32 x 3/4"... -
Page 46: Microprocessor Reversing Rear Control Box Assembly
Microprocessor Reversing Rear Control Box Assembly Illus. No. Part No. Qty. Description 322812 Back Electrical Box Component Plate 137060 Arc Suppressor (A.S.) Board 137013 Nylon Standoff 132431 Reversing Contactor - 24 VAC (208/230/240v - 50/60 Hz) 132432 Reversing Contactor Replacement Coil - 24 VAC (208/230/240v - 50/60 Hz) 150103 #8-32 x 3/4"... -
Page 47: Dual Timer Reversing Rear Control Box Assembly
Dual Timer Reversing Rear Control Box Assembly Illus. No. Part No. Qty. Description 322812 Back Electrical Box Component Plate 132198 Reversing Timer - 24 VAC (50/60 Hz) 150301 #8-18 x 7/16" Phillips Pan Head TEK Screw 132431 Reversing Contactor - 24 VAC (208/230/240v - 50/60 Hz) 132432 Reversing Contactor Replacement Coil - 24 VAC... -
Page 48: Steam Coil/Air Operated Steam Damper Assembly
Steam Coil/Air Operated Steam Damper Assembly American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781... -
Page 49: Steam Coil/Air Operated Steam Damper Assembly
Steam Coil/Air Operated Steam Damper Assembly Illus. No. Part No. Qty. Description 165008 Steam Coil Assembly 153002 5/16" Lock Washer 152004 5/16-18 Hex Nut 152002 1/4-20 Hex Nut 153007 1/4" Lock Washer 820321 Steam Damper Hinge Assembly 803416 Steam Damper Assembly (includes illus. - Page 50 Steam Coil/Mechanical Steam Damper Assembly American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781...
-
Page 51: Steam Coil/Mechanical Steam Damper Assembly
Steam Coil/Mechanical Steam Damper Assembly Illus. No. Part No. Qty. Description 165008 Steam Coil Assembly 153002 5/16" Lock Washer 152004 5/16-18 Hex Nut 152002 1/4-20 Hex Nut 153007 1/4" Lock Washer 820321 Steam Damper Hinge Assembly 880780 Steam Damper Assembly (includes illus. -
Page 52: Sail Switch/Hi-Limit Assembly
Illus. No. Part No. Qty. Description 154004 Twin Speed Nut 150309 #10-16 x 1/2" Hex Head TEK Crimptite Screw 802799 Sail Switch Box Cover and Bracket ONLY 150303 #4 x 3/4" Pan Head "A" Machine Screw 122200 Sail Switch ONLY 105500 Sail Switch Actuator Rod 319202... -
Page 53: Outer Top/Back Guard Assembly
Outer Top/Back Guard Assembly Illus. No. Part No. Qty. Description 322809 Back Electrical Box Cover 150301 #8-18 x 7/16" Phillips Pan Head TEK Screw 330077 Top Back Guard (No Top Back Guard on Steam Models) 150301 #8-18 x 7/16" Phillips Pan Head TEK Screw 150301 #8-18 x 7/16"... -
Page 54: Coin Acceptor Listing
NOTE: Coin Acceptors listed included Optical Switch (ADC Part No. 137056). ADC Part No. Nation 125100 U.S. and Canada 125101 United Kingdom 125114 United Kingdom 125120 France 125124 France 125107 Australia 125130 Australia 125123 New Zealand 881604 Japan 125103 125121 125129 125132 Singapore... -
Page 55: Step Down Transformer Usage Listing For Gas/Steam Dryers
Step Down Transformer Usage Listing for Gas/Steam Dryers OLTAGE 208-240 Steam 460/480 460/480 NOTE: Information not listed was not available at time of printing contact factory. Telephone: (508) 678-9000 RANSFORMER ERVICE 3or 4 -------- 132059 132059 132062 132062 132053 132053 132050 ONTROL OLTAGE... -
Page 56: Transformer Usage Listing For Electric Dryers
OLTAGE HASE 3ø 3ø 3ø 3ø 460/480 3ø 3ø 3ø 3ø 3ø 460/480 3ø 3ø 3ø 3ø 3ø 460/480 3ø 3ø 3ø 3ø 3ø 460/480 3ø 3ø 3ø 3ø 3ø 3ø NOTE: Information not listed was not available at time of printing contact factory. American Dryer Corporation Transformer Usage Listing for Electric Dryers RANSFORMER... -
Page 57: Electric Oven Component Application Chart
Electric Oven Component Application Chart HASE 3ø 3 or 4 881624 3ø 3ø 3 or 4 3ø 3 or 4 460/480 3ø 3 or 4 825079 3ø 881625 3ø 3 or 4 3ø 3ø 3 or 4 3ø 3 or 4 460/480 3ø... -
Page 58: Additional Parts Available
Part Number Description 112027 "Water Washed Fabrics" Label 112039 "Black / White / Green Ground" Label 112280 "Clean Lint Screen" Label 112041 "CAUTION - Exhaust/Lint Screen" Label 112534 "Phase 5 OPL Program Location Summary" Label 112533 "Phase 5 Coin Program Location Summary" Label 120100 3/8"... - Page 59 ADC 450144 1 - 10/11/94-100 4 * 12/28/98-50 2 * 10/30/95-100 3 * 08/07/97-50 5 * 03/02/00-50 6 * 10/12/01-25...
