Summary of Contents for American Dryer Corp. AD-360X2
- Page 1 AD-360X2 Parts Manual Phase 5 / Coin American Dryer Corporation 88 Currant Road Fall River, MA 02720-4781 Telephone: (508) 678-9000 / Fax: (508) 678-9447 E-mail: techsupport@amdry.com www.amdry.com ADC Part No. 450558 - 3...
- Page 2 POUR VOTRE SÉCURITÉ Ne pas entreposer ni utiliser d’essence ni d’autres vapeurs ou liquides inflammables à proximité de cet appareil ou de tout autre appareil. Important AD-360X2 MODEL NO. ________________...
-
Page 3: Table Of Contents
Table of Contents Front Panel Assembly ... 4 Right Coin Computer Panel Type II ... 5 Left Coin Computer Panel Type II... 6 Coin Chute Assembly ... 7 Coin Box / Vault Assembly (Left and Right)... 8 Main Door “Steel” Assembly ... 9 Main Door Switch Assembly ... -
Page 4: Front Panel Assembly
Front Panel Assembly Illus. No. Part No. Qty. Description 883144 White Right Hand Front Panel Assembly (includes illus. nos. 1, 2, 3, and 7) 883149 Bisque Right Hand Front Panel Assembly (includes illus. nos. 1, 2, 3, and 7) 883159 Stainless Steel Right Hand Front Panel Assembly (includes illus. -
Page 5: Right Coin Computer Panel Type Ii
Illus. No. Part No. Qty. Description 112574 Keypad 137251 Computer Board with Display 883134 25¢ U.S. Hanke Coin Acceptor with Optic Switch 151001 #8-32 Pal Nut 354192 Optic Switch Protector 354260 Computer Cover 150201 #10-32 x 1/4” Phillips Pan Head Tap Screw 150102 Hanke Acceptor M3 Metric Hex Nut 883067... -
Page 6: Left Coin Computer Panel Type Ii
Left Coin Computer Panel Type II Illus. No. Part No. Qty. Description 112574 Keypad 883134 25¢ U.S. Hanke Coin Acceptor with Optic Switch 354192 Optic Switch Protector 151001 #8-32 Pal Nut 137251 Computer Board with Display 354260 Computer Cover 150201 #10-32 x 1/4”... -
Page 7: Coin Chute Assembly
Illus. No. Part No. Qty. Description 882715 Coin Chute 882937 Control Panel Lock Plate 354180 Control Panel Lock Bracket 152002 1/4-20 Hex Nut 152014 1/4-20 Free Spin Wash Nut 450558 - 3 Coin Chute Assembly www.amdry.com... -
Page 8: Coin Box / Vault Assembly (Left And Right)
Coin Box / Vault Assembly (Left and Right) Illus. No. Part No. Qty. Description 882740 Black Left / Right Coin Box Faceplate ONLY 882745 Left Coin Box with Black Faceplate (less lock) 882672 Coin Box Lock Kit (includes 2 locks “keyed alike”) 160136* Coin Box Lock Key ONLY 882742... -
Page 9: Main Door "Steel" Assembly
Illus. No. Part No. Qty. Description 881150 Black Main Door Assembly Complete (includes illus. nos. 1, 2, and 8 through 15) 881207 Stainless Steel Main Door Assembly Complete (includes illus. nos. 1, 2, and 8 through 15) 102354 Door Gasket 170730 Clear Glass Adhesive (10.3 oz. -
Page 10: Main Door Switch Assembly
Main Door Switch Assembly Illus. No. Part No. Qty. Description 153566 #6-32 x 7/8” Clinch Stud 152013 #6-32 Hex Nut 153010 #6 Star Washer 137005 Door Switch 122636 Flag Terminal 881211 Black Main Door Switch Housing ONLY 353209 Stainless Steel Main Door Switch Housing ONLY 881153 Black Main Door Switch Housing Complete (includes illus. -
Page 11: Tumbler / Support Assemblies
Illus. No. Part No. Qty. Description 154210 5/32” x 3/16” Pop Rivet 354217 Spacer Plate 153048 Inner Friction Teflon 116332 94” x 2-1/2” x 1/8” Felt Collar 882765 One Arm Tumbler Support Assembly (includes illus. nos. 2, 3, and 5) 882766 Tumbler Assembly for One Arm Tumbler Support (includes illus. -
Page 12: Top Locking Lint Basket Assembly
Top Locking Lint Basket Assembly Illus. No. Part No. Qty. Description 115904 Lint Basket Felt 154210 5/32” x 3/16” Pop Rivet 160140 Key ONLY for XX4451 882787 Top Locking Lint Basket with Lock (white) (includes illus. nos. 1 through 5) 882794 Top Locking Lint Basket with No Lock (bisque) (includes illus. -
Page 13: Bottom Locking Lint Basket Assembly
Illus. No. Part No. Qty. Description 115904 Lint Basket Felt 154210 5/32” x 3/16” Pop Rivet 160140 Key ONLY for XX4451 882797 Bottom Locking Lint Basket Assembly with Lock (black) (includes illus. nos. 1 through 6) 882796 Bottom Locking Lint Basket Assembly with No Lock (black) (includes illus. -
Page 14: Separator Assembly
Separator Assembly Illus. No. Part No. Qty. Description 152014 1/4-20 Free Spin Wash Nut 882926 Inner Ring Separator Bracket 882717 Inner Ring Separator Assembly (includes illus. nos. 1 through 3) 115903 Tumbler Separation Felt American Dryer Corporation 450558 - 3... -
Page 15: Rotational Sensor / Sail Switch And Teflon Backup Washer Plate
Rotational Sensor / Sail Switch and Teflon Illus. No. Part No. Qty. Description 882747 Teflon (includes illus. nos. 1 through 5) 153047 Outer Friction Pad 354203 Teflon 102102 Magnet 153012 #8 Internal Star Washer 152001 #8-32 x 3/8” Hex Nut 153002 5/16”... -
Page 16: Lint Coop And Adjustment Wheel Bracket Assembly
Lint Coop and Adjustment Wheel Bracket Assembly Illus. No. Part No. Qty. Description 150220 3/8-24 Hex Nut 122002 Lint Drawer Switch 150309 #10-16 x 1/2” Hex Head TEK Crimptite Screw 882927 Lint Coop ONLY 882716 Lint Coop Assembly Complete (includes illus. nos. 1 through 8) 152014 1/4-20 Free Spin Wash Nut 154210... -
Page 17: Left Rear Wheel Bracket (3-Bolt)
Illus. No. Part No. Qty. Description 150220 3/8-24 Hex Nut 150510 1/4-20 x 3/4” Hex Head Machine Bolt 153007 1/4” Split Lock Washer 883004 Left Rear Roller Wheel Bracket ONLY (3-bolt) 884244 Left Rear Roller Wheel Bracket Assembly with Hardware (3-bolt) 884242 Thruster Wheel 450558 - 3... -
Page 18: Right Rear Wheel Bracket (3-Bolt)
Right Rear Wheel Bracket (3-Bolt) Illus. No. Part No. Qty. Description 883005 Right Rear Roller Wheel Bracket ONLY (3-bolt) 884243 Right Rear Roller Wheel Bracket Assembly with Hardware (3-bolt) 150220 3/8-24 Hex Nut 150510 1/4-20 x 3/4” Hex Head Machine Bolt 153007 1/4”... -
Page 19: Microprocessor Temperature Sensor Bracket Assembly
Microprocessor Temperature Sensor Bracket Assembly Illus. No. Part No. Qty. Description 882682 Temperature Sensor Bracket Assembly Complete (includes illus. nos. 1 through 6 and 9 through 12) 354117 Sensor Bracket ONLY 883025 Microprocessor Temperature Sensor Probe Assembly Complete (includes illus. nos. 2 through 6) 154007 1/4”... -
Page 20: Top Burner Box Assembly
Top Burner Box Assembly Illus. No. Part No. Qty. Description 141138 Burner Manifold 141137 Stainless Steel Burner Tube 128927 1/2” 24 VAC (natural gas) Gas Valve 880960 1/2” 24 VAC Liquid Propane Gas Valve 140411 1/2” Liquid Propane Conversion Kit (per tumbler) 883933* –... -
Page 21: Bottom Burner Box Assembly
Illus. No. Part No. Qty. Description 141138 Burner Manifold 128935 Direct Spark Ignition Module with 3 Tries 141137 Stainless Steel Burner Tube 128927 1/2” 24 VAC (natural gas) Gas Valve 880960 1/2” Liquid Propane Gas Valve Conversion Kit (per tumbler) 140411 1/2”... -
Page 22: Blower Motor Assembly
Blower Motor Assembly Illus. No. Part No. Qty. Description 181038 1/4 hp 115/230v/60 Hz Blower Motor 802029 12-1/2” Riveted Impellor with 1/2” Bore 153050 1/2” x 1-1/16” Flat Washer 152006 1/2-20 Left Hand Jam Nut 100731 1/8” x 3/32” x 1-1/8” Key 153007 1/4”... -
Page 23: Rear Electrical Panel
Illus. No. Part No. Qty. Description 150301 #8-18 x 7/16” Phillips Pan Head TEK Screw 141403 Transformer – 24 VAC 881763 Termination Kit 882928 Rear Electrical Panel with Stud 136049 3/4-Amp Slo-Blo Fuse (fuse 1) 136008 Fuse Holder 136106 2-Amp Slo-Blo Fuse (fuse 2) 152002 1/4-20 Hex Nut 153021... -
Page 24: Drive Motor / Motor Mount Assemblies
Drive Motor / Motor Mount Assemblies Illus. No. Part No. Qty. Description 154279 5/16-18 x 3/4” Carriage Bolt 154277 3/8” x 1/2” Shoulder Screw 154274 3/8-16 x 2” Long Spade Bolt 154276 1/4-20 x 5/16” x 5/8” Shoulder Bolt 157010 1-7/8”... -
Page 25: Exhaust Duct Assembly
Illus. No. Part No. Qty. Description 354078 Exhaust Access Plate 150309 #10-16 x 1/2” Hex Head TEK Crimptite Screw 354171 Harness Stiffener 150103 #8-32 x 3/4” Phillips Round Head Machine Screw 151001 #8-32 Pal Nut 154210 5/32” x 3/16” Pop Rivet ––––––... -
Page 26: Rear Back Guard Assembly
Rear Back Guard Assembly Illus. No. Part No. Qty. Description 103500 Leveling Leg 883070 Back Guard Short 150300 #10-16 x 1/2” TEK Screw 883071 Top Pocket Flex Gas Line Bracket 883160 Bottom Pocket Flex Gas Line Pivot Support 883073 Rear Right Side Panel Support Assembly 143118 60”... -
Page 27: Wrapper Gasket
Illus. No. Part No. Qty. Description 102310 Wrapper Gasket (sold by the foot) 450558 - 3 www.amdry.com Wrapper Gasket... - Page 28 ADC Part No. 450558 3 - 09/22/08 - 0...
